8.2.4 The Y home sensor was replaced

When the Y home was exchanged, an electric adjustment is executed by the following procedure.

8.2.5 The registration mark sensor was replaced

When the registration mark sensor was exchanged, an electric adjustment is executed by the following
procedure.

8.2.6 The X or Y motor was replaced

When the X or Y motor was exchanged, an electric adjustment is executed by the following procedure.
FC2250-UM-251-9370
8.5 Set the DIP Switches setting to the adjustment mode
8.9 Adjusting the Home Position
8.12 Adjusting the Distance Accuracy and the perpendicularity
8.5 Set the DIP Switches setting to the normal mode
End of Adjustment
8.5 Set the DIP Switches setting to the adjustment mode
8.14 Adjusting the Registration Mark Sensor Sensitivity
8.15 Adjusting the Offset of the Registration Mark Sensor
8.5 Set the DIP Switches setting to the normal mode
End of Adjustment
8.5 Set the DIP Switches setting to the adjustment mode
8.9 Adjusting the Home Position
8.12 Adjusting the Distance Accuracy and the perpendicularity
8.5 Set the DIP Switches setting to the normal mode
End of Adjustment
8. ELECTRICAL ADJUSTMENTS
8-4
