Spectra nTier Verde Array Manual page 21

Complete the Replacement
C
OMPLETE THE
1.
2. From the menu bar, select Status > Hardware. The Hardware screen
3. Click System. The screen refreshes to show the status for the system.
Figure 23 The Hardware screen showing the boot drives.
4. Examine the status of the boot drives:
5.
October 2013
R
EPLACEMENT
Log into the StrataView web interface as described in the Spectra nTier
Verde User Guide.
displays.
nTier Verde 4U master node Confirm both boot drives indicate a good
status (a check mark in a green circle). If a boot drive does not indicate a
good status, contact Spectra Logic Technical Support (see Contacting
Spectra Logic on page
nTier Verde 2U master node Confirm the replacement boot drive
shows as "Rebuilding" with a warning status (an exclamation point in
yellow triangle). After approximately 30 minutes, the replacement
drive finishes rebuilding and indicates a good status (a check mark in a
green circle). If the replacement boot drive does not indicate a good
status after 60 minutes, contact Spectra Logic Technical Support (see
Contacting Spectra Logic on page
Continue to Returns on page
Boot Drive Replacement—Spectra nTier Verde Array
3).
3).
22.
Replace a Boot Drive
21
