Replace a Boot Drive in the Verde 4U Master Node
14. Orient the array cover over the chassis with the tabs facing toward the
15. Insert the tabs into the slots in the chassis and rotate the cover down.
16. Using a #1 Phillips screwdriver, install the four screws to secure the
Reinstall the Array in a Rack
Use the instructions in this section to reinstall the array in a rack.
The Spectra nTier Verde array weighs between 57 lb (25.8 kg) and 136 lb (61.9 kg)
Warning
depending on how many drives are installed. Use extreme caution when moving it.
Always use two people, one on each side, when lifting or moving it.
WARNUNG
nachdem, wie viele Laufwerke installiert sind. Seien Sie besonders vorsichtig, wenn
Sie es bewegen. Immer zwei Personen, eine auf jeder Seite, beim Heben oder
Bewegen.
1. Pull the center section of the outer rails out of the rack until they are
October 2013
front of the array.
Figure 12 Orient the cover with the tabs facing to the front of
the array.
cover to the array (see Figure 7 and Figure 8 on page
Die Spectra nTier Verde wiegt zwischen 25,8 kg und 61,9 kg je
fully extended (see Figure 13 on page
Boot Drive Replacement—Spectra nTier Verde Array
Replace a Boot Drive
Front of array
10).
14).
