Spectra nTier Verde Array Manual page 15

Replace a Boot Drive in the Verde 4U Master Node
5. Using a #2 Phillips screwdriver, secure the chassis to the rack using one
6. Connect all power, Ethernet, and SAS cables that you disconnected
7. Power on the nTier Verde array by pressing the power button on the
8. Install the front bezel.
9.
October 2013
screw through each mounting bracket on the sides of the chassis.
Mounting
bracket
Screw
Figure 15 Secure the chassis to the rack.
before removing the array from the rack.
front panel. The power LED illuminates indicating that power is on.
Power
button
Power LED
Figure 16 Press the power button.
Wait while the array completes its power‐on sequence, which takes
approximately four minutes, depending on the configuration.
Skip to Complete the Replacement on page
Boot Drive Replacement—Spectra nTier Verde Array
Replace a Boot Drive
21.
