  • Page 1 Spectra BlackPearl NAS Solution User Guide SpectraLogic.com...
  • Page 2 Information furnished in this manual is believed to be accurate and reliable. However, no  responsibility is assumed by Spectra Logic for its use. Due to continuing research and  development, Spectra Logic may revise this publication from time to time without notice,  and reserves the right to change any product specification at any time without notice. Trademarks BlackPearl, BlueScale, CC, Spectra, SpectraGuard, Spectra Logic, TeraPack, TFinity, and  TranScale are registered trademarks of Spectra Logic Corporation. Eon Protect, SeeVault,  and MigrationPass are trademarks of Spectra Logic Corporation. All rights reserved  worldwide. All other trademarks and registered trademarks are the property of their  respective owners. Part Number 90990143 Revision A Revision History Revision Date Description October 2019 Initial release. Note: To make sure you have the most current version of this guide check the  Spectra Logic Technical Support portal at support.spectralogic.com/documentation/user‐guides/.  To make sure you have the release notes for the most current version of  the BlackPearl NAS solution Release Notes, check the Spectra Logic  Technical Support portal at support.spectralogic.com/documentation/ release‐notes/. You must sign into the portal before viewing Release  Notes. The release notes contain updates to the User Guide since the last  time it was revised. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 3 Software Product. 3. GENERAL The Software Product is licensed, not sold, to you by Spectra for use only under  the terms of this EULA. The Software Product is protected by copyright laws and  international copyright treaties, as well as other intellectual property laws and  treaties. The rights granted herein are limited to Spectraʹs and its licensorsʹ  intellectual property rights in the Software Product and do not include any other  patents or intellectual property rights. The terms of this EULA will govern any  software upgrades provided by Spectra that replace and/or supplement the  original Software Product, unless such upgrade is accompanied by a separate  license in which case the terms of that license will govern. 4. SOFTWARE PRODUCT The Software Product, as used in this EULA, means, collectively and/or as  applicable:  The Software Product package;  Any and all contents, components, attachments, software, media, and code with which  this Agreement is provided and delivered;  Any and all images, photographs, art, art work, clip art, fonts or other artistic works  (the ʺArt Workʺ);  Related explanatory written materials and instructions, and any other possible  documentation related thereto (ʺDocumentationʺ); and  Upgrades, modified versions, updates, additions and copies of the Software Product  (the ʺUpgradesʺ), if any, licensed to by Spectra under this EULA. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 4 6. DESCRIPTION OF OTHER RIGHTS AND LIMITATIONS A. Spectra will provide you with support services related to the Software  Product (ʺSupportʺ). Such Support will be provided in accordance with  the Spectra Master Support Agreement, available for download and  viewing on the Spectra Corporate Web site. Use of Support is governed by  this EULA and Spectraʹs Master Support Agreement.  B. Any supplemental software, code, content, or media provided to you in  the course of Support shall be considered part of the Software Product and  subject to the terms and conditions of this EULA. C. Spectra retains all right, title, and interest in and to the Software Product,  and any rights not granted to you herein are reserved by Spectra. You  hereby expressly agree not to extract information, reverse engineer,  disassemble, decompile, or translate the Software Product, or otherwise  attempt to derive the source code of the Software, except to the extent  allowed under any applicable law. In the event that such activities are  permitted by applicable law, any information you, or your authorized  agent, discover shall be promptly disclosed to Spectra and shall be  deemed the confidential information of Spectra. D. You shall not modify, sublicense, assign, or transfer the Software Product  or any rights under this EULA, except as expressly provided in this EULA.  Any attempt to sublicense, assign, or transfer any of the rights, duties, or  obligations will be void. E. You may permanently transfer all of your rights under this EULA,  provided you retain no copies. The other party must agree to accept the  terms and conditions of the EULA. 7. ALL RESERVED All rights not expressly granted herein are reserved by Spectra. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 5 Documentation, as a result of its responsibilities hereunder. B. B. End User acknowledges Spectraʹs exclusive rights in the Software  Product and that the Software Product is unique and original to Spectra  and that Spectra is owner thereof. Unless otherwise permitted by law, End  User shall not, at any time during or after the effective Term of the  Agreement, dispute or contest, directly or indirectly, Spectraʹs exclusive  right and title to the Software Product or the validity thereof. 10. U.S. GOVERNMENT END USERS The Software Product and related documentation are ʺCommercial Items,ʺ as that  term is defined at 48 C.F.R. §2.101, consisting of ʺCommercial Computer  Softwareʺ and ʺCommercial Computer Software Documentation,ʺ as such terms  are used in 48 C.F.R. §12.212 or 48 C.F.R. §§227.7202‐1 through 227.7202‐4, as  applicable. The Commercial Computer Software and Commercial Computer  Software Documentation are being licensed to U.S. Government end users (a)  only as Commercial Items and (b) with only those rights as are granted to all other  End Users pursuant to the terms and conditions herein. Unpublished rights  reserved under the copyright laws of the United States. 11. EXPORT LAW ASSURANCES You may not use or otherwise export or re‐export the Software Product except as  authorized by United States law and the laws of the jurisdiction in which the  Software Product was obtained. In particular, but without limitation, the Software  Product may not be exported or re‐exported (a) into (or to a nation or resident of)  any U.S. embargoed countries or (b) to anyone on the U.S. Treasury Departmentʹs  list of Specially Designated Nationals or the U.S. Department of Commerce  Denied Persons List or Entity List. By installing or using any component of the  Software Product, you represent and warrant that you are not located in, under  control of, or a national or resident of any such country or on any such list. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 6 AUTHORIZED REPRESENTATIVE SHALL CREATE A WARRANTY. SOME  JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF IMPLIED  WARRANTIES OR LIMITATION ON APPLICABLE STATUTORY RIGHTS OF A  CONSUMER, SO THE ABOVE EXCLUSION AND LIMITATIONS MAY NOT  APPLY TO YOU. 13. LIMITATION OF LIABILITY TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO  EVENT SHALL SPECTRA, ITS AFFILIATES OR LICENSEES, BE LIABLE FOR  ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES  WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS  OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS  INFORMATION, OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE  USE OF OR INABILITY TO USE THE SOFTWARE PRODUCT OR THE  PROVISION OF OR FAILURE TO PROVIDE SUPPORT SERVICES, EVEN IF  SPECTRA HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.  IN ANY CASE, SPECTRAʹS ENTIRE LIABILITY UNDER ANY PROVISION OF  THIS EULA SHALL BE LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU  FOR THE SOFTWARE PRODUCT; PROVIDED HOWEVER, IF YOU HAVE  ENTERED INTO A MASTER SUPPORT AGREEMENT, SPECTRAʹS ENTIRE  LIABILITY REGARDING SUPPORT SERVICES SHALL BE GOVERNED BY THE  TERMS OF THAT AGREEMENT. BECAUSE SOME STATES AND  JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF  LIABILITY, THE ABOVE LIMITATION MAY NOT APPLY TO YOU. 14. CONTROLLING LAW AND SEVERABILITY This EULA will be governed by and construed in accordance with the laws of the  State of Colorado, as applied to agreements entered into and to be performed  entirely within Colorado between Colorado residents. This EULA shall not be  governed by the United Nations Convention on Contracts for the International  Sale of Goods, the application of which is expressly excluded. If for any reason a  court of competent jurisdiction finds any provision, or portion thereof, to be  unenforceable, the remainder of this EULA shall continue in full force and effect. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 7: Contacting Spectra Logic

    Mexico, Central and South America, Asia, Australia, and New Zealand Phone:  1.303.449.0160 Spectra Logic Sales Website: shop.spectralogic.com United States and Canada Europe Phone: 1.800.833.1132 or 1.303.449.6400 Phone: 44 (0) 870.112.2150 Fax: 1.303.939.8844 Fax: 44 (0) 870.112.2175 Email: sales@spectralogic.com Email: eurosales@spectralogic.com To Obtain Documentation Spectra Logic Website: support.spectralogic.com/documentation October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 8: Table Of Contents

    Contents About This Guide  A  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NTENDED UDIENCE  U  I  S   . . . . . . . . . . . . . . . . . . LACK EARL NTERFACE CREENS  I  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ELATED NFORMATION Related Publications  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  16 Chapter 1 – Product Overview   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VERVIEW    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EATURES   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OMPONENTS Front View of Master Nodes  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  21 Rear View of Master Nodes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...
  • Page 9  S    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . REATE HARE Create a CIFS Share   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  63 Create an NFS Share  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  67  NAS S   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ONFIGURE ERVICES Configure the CIFS Service  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  69 Configure the NFI Service  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  70 Configure the NFS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  70  R   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ONFIGURE EPLICATION Configure the NAS Replication Service . . . . . . . . . . . . . . . . . . . . . . . .  72 Configure the Target System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  73 Configure Volumes for Replication  . . . . . . . . . . . . . . . . . . . . . . . . . . .  73 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 10  C    S   . . . . . . ONFIGURE ETWORK ONNECTIONS ETTINGS Configure Ethernet Ports  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  102 Configure DNS Settings  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  108 Configure SMTP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  109 Configure Date and Time   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  110 Edit the System Name   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  111  N  S    . . . . . . . . . . . . . . . . . . . . ONFIGURE ETWORKING ERVICES Configure the Active Directory Service . . . . . . . . . . . . . . . . . . . . . . .  113 Configure the SNMP Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  118 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 11 Chapter 7 – Using AutoSupport  A   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BOUT UPPORT  C  I   . . . . . . . . . . . . . . . . . . . . . . . . NTER ONTACT NFORMATION  M  R  . . . . . . . . . . . . . . . . . . . . . . . . . . ONFIGURE ECIPIENTS Create a New Recipient  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  150 Edit a Mail Recipient   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  151 Send a Test Email   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  152 Delete a Mail Recipient   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  153 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 12  S  T    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ETWORK ETUP Configuration   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  176 Connectivity to the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  177 Troubleshooting   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  179 Tools  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  180  L  T  S   . . . . . . . . . . . . . . . . . . . PECTRA OGIC ECHNICAL UPPORT Before Contacting Support   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  181 Determine the System Serial Number  . . . . . . . . . . . . . . . . . . . . . . . .  181 Open a Support Ticket  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  182 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 13 APACITY  S    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . YSTEM PECIFICATION BlackPearl NAS 2U Master Node  . . . . . . . . . . . . . . . . . . . . . . . . . . . .  206 BlackPearl NAS 4U Master Node  . . . . . . . . . . . . . . . . . . . . . . . . . . . .  206    W    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EIGHT BlackPearl NAS 2U Master Node   . . . . . . . . . . . . . . . . . . . . . . . . . .  207 BlackPearl NAS 4U Master Node and BlackPearl Enterprise Expansion  Node   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  207 BlackPearl Archive Expansion Node   . . . . . . . . . . . . . . . . . . . . . . .  208 107‐Drive Disk Solution   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  208 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 14 Appendix D – Open Source Code Acknowledgements & Package List  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PACHE BSD  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AMBA   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GINX    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .    R  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AILS ZFS   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  P    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NCLUDED ACKAGES October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 15: About This Guide

    About This Guide ®  This guide describes how to configure, monitor, and maintain the Spectra ®  BlackPearl NAS (Network Attached Storage) solution master node, which  is referred to as the master node in these instructions.  This guide also describes the Spectra BlackPearl enterprise expansion  node, and the BlackPearl archive expansion node, which are referred to as  expansion nodes in these instructions. The expansion nodes are used in  conjunction with the master node and cannot be used as a stand‐alone  product.  When instructions in this guide apply to both the BlackPearl NAS solution  master node and expansion nodes, the solution is used to refer to both. This guide also describes how to use the Spectra Network File Interface,  which is based on the BlackPearl Converged Storage System platform.  NTENDED UDIENCE This guide is intended for data center administrators and operators who  maintain and operate file storage systems. The information in this guide  assumes a familiarity with computing terminology, RAID technology, SAS  connectivity, and Ethernet networking. You also need to be familiar with  installing, configuring, and using data file storage and archival software. LACK EARL NTERFACE CREENS The BlackPearl user interface changes as new features are added or other  modifications are made. Therefore, the screens you see in the BlackPearl  user interface may differ from those shown in this guide.
  • Page 16: Related Information

    Note: Read text marked with “Note” for additional information or  suggestions about the current topic. Related Publications The following documents related to the Spectra BlackPearl NAS solution  are available on the Support Portal website at support.spectralogic.com,  and from the Documentation screen on the BlackPearl user interface.  The Spectra BlackPearl Network Setup Tips document provides helpful  instructions for troubleshooting common connectivity problems.  The Spectra Verde NAS Solution Quick Start Guide provides basic  instructions for the essential installation and configuration steps.  The Spectra Verde NAS Solution Command Line Interface Guide describes  how to configure, monitor, and maintain the Spectra Verde NAS  solution through the command line interface.  The Spectra Verde NAS Solution Site Preparation Guide provides  important information that you should know before installing a Verde  NAS solution in your storage environment.  The Spectra Verde NAS Solution Installation Guide provides instructions  for installing a Verde NAS solution.  The Spectra BlackPearl & Verde HotPair Installation & Configuration Guide  provides detailed information on installing and using a Verde NAS  solution in a HotPair configuration. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 17  The Spectra 12‐ & 36‐Drive Chassis Boot Drive Replacement Guide provides  instructions for replacing a failed boot drive in the system.  The Spectra 12‐, 36‐ & 45‐Drive Chassis Drive Replacement Guide provides  instructions for replacing a failed data drive after the system is  installed.  The Spectra 12‐, 36‐ & 45‐Drive Chassis Fan Replacement Guide provides  instructions for replacing a failed fan in the system.  The Spectra 12‐, 36‐ & 45‐Drive Chassis Power Supply Replacement Guide  provides instructions for replacing a failed power supply after the  system is installed.  The Spectra 12‐Drive Chassis HBA Replacement Guide and Spectra 36‐Drive  Chassis HBA Replacement Guide provide instructions for replacing a  failed HBA in the system.  The Spectra 96‐Drive Chassis Drive Replacement Guide provides  instructions for replacing a failed data drive in the BlackPearl archive  expansion node.  The Spectra 96‐Drive Chassis Fan Replacement Guide provides instructions  for replacing a failed fan in the archive expansion node.  The Spectra 96‐Drive Chassis Power Supply Replacement Guide provides  instructions for replacing a failed power supply in the archive  expansion node.  The Spectra 96‐Drive Chassis I/O Module Replacement Guide provides  instructions for replacing a failed I/O module in the archive expansion  node. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 18: Chapter 1 - Product Overview

    HAPTER Product Overview This chapter provides an overview of the Spectra BlackPearl NAS Solution  features and components. Topic Overview page 19 Features page 19 Components page 21 Front View of Master Nodes page 21 Rear View of Master Nodes page 23 Rear Panel of Master Nodes page 25 Front View of the BlackPearl Enterprise Expansion  page 27 Node Rear View of the BlackPearl Enterprise Expansion  page 28 Node Front View of the BlackPearl Archive Expansion  page 29 Node Rear View of the BlackPearl Archive Expansion Node page 30 Software page 33 Operating System...
  • Page 19: Overview

    Line Interface Guide.  Easy Network-Based Administration The BlackPearl NAS solution can be  configured over an Ethernet network using a standard web browser. Expansion Nodes The BlackPearl enterprise expansion node  accommodates up to 44 disk drives with an active bezel, and 45 disk drives  with a passive bezel, and can be connected to a master node to increase  overall capacity of the system. The BlackPearl archive expansion node  holds up to 96 disk drives. The 107‐drive disk solution holds up to 107  drives. HotPair Two BlackPearl master nodes can be connected to multiple  expansion nodes in a failover configuration. One master node acts as the  primary controller, and the other acts as the secondary. In the event that the  secondary controller detects a failure of the primary controller, it  automatically takes over to provide uninterrupted operation, without  administrative intervention. File Sharing Connectivity for Major Operating Systems The Network File  System (NFS) and Common Internet File System (CIFS) protocols provide  connectivity to most major operating systems, including Microsoft  Windows, macOS, UNIX, and Linux. Solid state disk drives may be  installed in your system to improve NFS performance. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 20 Replicated System Configuration The BlackPearl master node mirrors its  boot drives on to an existing storage pool on the system’s data disks. If one  or both boot drives fail, the system recovers automatically when  replacement boot drives are installed. Write Performance Drives The BlackPearl NAS solution supports even  numbers of solid state drives as Write Performance drives. The drives  increase write speed to shared NFS volumes on the system. 10 Gigabit Ethernet A dual port, 10 Gigabit Ethernet (10 GigE) network  interface card, optional in a 2U master node and standard in a 4U master  node, provides high‐speed data connections between hosts and the  BlackPearl NAS solution. 10GBase-T Ethernet Connectivity Two onboard 10 gigabit copper ports  (10GBase‐T) provide Ethernet connectivity for the system with one  dedicated port used to access the BlackPearl user interface. The second  10GBase‐T port can be used for data transfer. 40 Gigabit Ethernet An optional dual port, 40 Gigabit Ethernet (40 GigE)  network interface card can be installed to provide high‐speed data  connections between hosts and the BlackPearl NAS solution. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 21: Components

    Figure 1 The front view of the BlackPearl NAS solution 4U master node (front bezel removed). Latch Data drive status LEDs Data drives Power button and system status LEDs Figure 2 The front view of the BlackPearl NAS solution 2U master node (front bezel removed). October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 22 System status LEDs The status LEDs indicate power status, disk and network activity, as well as  hardware faults. See System Status LEDs on page 135 for more information. The BlackPearl NAS solution 4U master nodes support up to 23 high‐ Data drives performance disk drives mounted on individual drive sleds in the front of the  system. The BlackPearl NAS solution 2U master nodes support up to 12 data  drives.  Depending on your order configuration, the BlackPearl NAS solution may  optionally contain solid state drives to improve write performance. See Write  Performance Drives on page 20 for more information. Note: If the BlackPearl NAS solution 4U master node uses a bezel without a  Visual Status Beacon, 24 disk drives are installed in the front of the system. The drive sleds slide into bays in the front of the BlackPearl enclosures and lock  in place. The front of each drive sled has a handle for removing the sled from  the system and a latch for locking the drive sled in place. Two LEDs on each drive sled indicate the status of the drive. One LED is for  Data drive status drive status while the other shows drive activity. LEDs Empty drive sleds Empty drive sleds are installed in the unused drive bays to prevent  contaminants from entering the enclosure and to maintain proper air flow. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 23: Rear View Of Master Nodes

    Figure 3 The rear view of the BlackPearl NAS solution 4U master node. Rear panel Power supplies Boot drives Figure 4 The rear view of the BlackPearl NAS solution 2U master node. Component Description The BlackPearl NAS solution master nodes include two power supplies to  Power supplies provide N+1 redundancy and fail‐over protection.  Each power supply has its own AC power connector.   Each power supply has a single LED that lights to indicate when the power is  on and functioning normally. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 24 25  for a detailed description. The boot drives provide storage for the operating system and BlackPearl user  Boot drives interface. The boot drives are hot swappable which allows for uninterrupted  operation during replacement.  The BlackPearl NAS solution 4U master nodes support up to 12 data drives in  Data drives the rear of the system.  (BlackPearl 4U master nodes only) Depending on your order configuration, the BlackPearl NAS solution may  optionally contain solid state drives to improve write performance. See Write  Performance Drives on page 20 for more information. Note: The BlackPearl 2U master node does not have data drives in the rear of  the system. Empty drive sleds Empty drive sleds are installed in the unused drive bays to prevent  (BlackPearl 4U contaminants from entering the enclosure and to maintain proper air flow. master nodes only) October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 25: Rear Panel Of Master Nodes

    Ethernet ports 10GBase‐T ports can be used for network connectivity on a 10GBase‐T network.  The left port of the two 10GBase‐T ports is dedicated as the BlackPearl  management port and cannot be used for data transfer. Notes:  The 10GBase‐T ports auto‐negotiate down to 1000Base‐T.   Spectra Logic recommends using the 40 GigE ports, or the 10 GigE ports  for data transfer to ensure maximum performance. Monitor connector If necessary, you can connect a monitor to the SVGA connector on the  BlackPearl NAS solution system for troubleshooting purposes. Only connect a  monitor for initial configuration of the BlackPearl management port, or as  directed by Spectra Logic Technical Support.  The two 10 Gigabit Ethernet (10 GigE) ports can be used for network  10 GigE ports connectivity on a 10 GigE network.  Note: The 10 GigE is optional in the BlackPearl 2U master nodes. SAS ports Depending on your configuration, there may be SAS cards installed in available  (Optional) expansion slots. Each four port SAS card provides connectivity between the  master node and up to two BlackPearl enterprise expansion nodes. Each two  port SAS card provides connectivity between the master node and up to two  BlackPearl archive expansion nodes.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 26 Expansion slots The expansion slots accommodate optional interface cards to provide  additional connectivity.  The BlackPearl management port is used to connect to the browser‐based user  BlackPearl interface to configure, manage, and monitor the BlackPearl NAS solution. The  management port BlackPearl management port cannot be used for data transfer. USB ports If necessary, you can use these ports to connect a USB drive, or USB mouse and  USB keyboard to the system for troubleshooting purposes, or to configure the  IP addressing for the BlackPearl management port. The serial port is used to connect a primary master node to a secondary master  Serial port node in a HotPair configuration. The two master nodes are connected using a  null modem cable. For information on connecting cables for a HotPair  configuration, see the Spectra BlackPearl & Verde HotPair Installation &  Configuration Guide. 40 GigE ports The two 40 Gigabit Ethernet (40 GigE) ports can be used for network  (Not shown, connectivity on a 40 GigE network.  optional) Note: The 40 GigE card is not supported in 2U master nodes. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 27: Front View Of The Blackpearl Enterprise Expansion Node

    Status Beacon. A disk drive cannot be installed in this position.  If the expansion node uses a passive bezel, a disk drive is installed in this  position. Power button The power button controls the AC power for the enterprise expansion node. System status LEDs The status LEDs indicate power status, disk and network activity, as well as  hardware faults. See System Status LEDs on page 135 for more information. Data drives The front of the BlackPearl enterprise expansion node supports up to 23  enterprise disk drives, or 24 drives if the expansion node uses a passive bezel,  mounted on individual drive sleds in the front of the chassis. The drive sleds  slide into bays in the front of the enclosure and lock in place. The front of each  drive sled has a handle for removing the sled from the system and a latch for  locking the drive sled in place. Data drive status Two LEDs on each drive sled indicate the status of the drive. One LED is for  drive status while the other shows drive activity. LEDs When fewer than the maximum number of drives are installed, empty drive  Empty drive sleds sleds are installed in the unused drive bays to prevent contaminants from  entering the enclosure and to maintain proper air flow.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 28: Rear View Of The Blackpearl Enterprise Expansion Node

    Figure 7 The rear view of the BlackPearl enterprise expansion node. Component Description The BlackPearl enterprise expansion node includes two power supplies to  Power supplies provide N+1 redundancy and fail‐over protection.  Each power supply has its own AC power connector.   Each power supply has a single LED that lights to indicate when the power is  on and functioning normally. SAS connectors The rear panel of the BlackPearl enterprise expansion node has four SAS ports  used to connect an expansion node to a master node. Two ports are for primary  connections and two ports are for secondary connections. Labels next to each  port identify if the port is a primary or secondary connection.  Data drives Up to 21 data drives can be installed in the rear of the expansion node. Empty drive sleds When fewer than the maximum number of drives are installed, empty drive  sleds are installed in the unused drive bays to prevent contaminants from  entering the enclosure and to maintain proper air flow.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 29: Front View Of The Blackpearl Archive Expansion Node

    Front View of the BlackPearl Archive Expansion Node Figure 8 shows the major components on the front of the BlackPearl  archive expansion node. Figure 8 The front view of the BlackPearl archive expansion node (front bezel removed). Component Description The front bezel mounts on the front of the expansion node, and contains the  Front bezel Visual Status Beacon light bar, if included, which provides status information  (not shown) for the expansion node. See Front Bezel Visual Status Beacon on page 133 for  more information. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 30: Rear View Of The Blackpearl Archive Expansion Node

    SAS connectors Power supplies Figure 9 The rear view of the BlackPearl archive expansion node. Component Description Five hot‐swappable fans provide the cooling for the BlackPearl archive  Fans expansion node. The BlackPearl archive expansion node includes two power supplies to provide  Power supplies N+1 redundancy and fail‐over protection.  Each power supply has its own AC power connector.   Each power supply has a single LED that lights to indicate when the power is  on and functioning normally.  SAS connectors The rear panel of the BlackPearl archive expansion node has two SAS ports  used to connect an expansion node to a BlackPearl master node. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 31: Front View Of The 107-Drive Disk Solution

    Figure 10 The front view of the 107-drive disk solution (front bezel removed). Component Description Front bezel The front bezel mounts on the front of the disk solution, and contains the Visual  (not shown) Status Beacon light bar, if included, which provides status information for the  expansion node. See Front Bezel Visual Status Beacon on page 133 for more  information. Data drive activity Numbered LEDs indicate drive activity for each drive in the disk solution. LEDs Mute button The mute button silences the chassis alarm. System status LEDs The status LEDs indicate power status, as well as hardware faults for fans,  power supplies, and temperature. The power button controls the main AC power for the 107‐drive disk solution. Power button October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 32: Rear View Of The 107-Drive Disk Solution

    Power supplies Figure 11 The rear view of the 107-drive disk solution. Component Description SAS and Ethernet The rear panel of the 107‐drive disk solution has one or two expander panels  connectors which include one Ethernet port and four SAS ports used to connect a 107‐drive  disk solution to a BlackPearl NAS solution. Fans Eight hot‐swappable fans, in banks of two, provide the cooling for the 107‐drive  disk solution. Power supplies The 107‐drive disk solution includes two power supplies to provide N+1  redundancy and fail‐over protection.  Each power supply has its own AC power connector.   Each power supply has a single LED that lights to indicate when the power is  on and functioning normally.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 33: Software

     NFS and CIFS servers Operating System The operating system, running on the integrated application server,  provides the foundation for all software and applications running on the  system. Logical Volume Manager and File System The BlackPearl NAS solution features a combined logical volume manager  and file system which controls the structure and management of the data  storage on the system. The BlackPearl NAS solution includes data  verification to protect against corruption. NFS and CIFS Servers The NFS and CIFS servers running on the BlackPearl NAS solution provide  network file system access to host computers over an Ethernet network.  NFS and CIFS shares can be accessed by most major operating  environments, including Microsoft Windows operating system, macOS  operating system, UNIX, and Linux. LACK EARL NTERFACE The BlackPearl user interface provides browser‐based configuration,  management, and monitoring of the BlackPearl NAS solution. The  following sections describe the common features that appear in all screens  in the user interface. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 34: Menus

    BlackPearl User Interface Menus The menu bar displays along the top edge of each screen. Use the menu bar  drop‐down menus to navigate through the interface. Menu Status Alerts Power Figure 12 The Dashboard screen of the BlackPearl NAS solution. The following table provides an overview of the screens available under  each menu. The previously selected screen remains displayed until you  select another option.  Menu Available Options Dashboard The Dashboard navigation link returns you to the Dashboard screen from any other  screen in the interface. The Dashboard screen displays the general status of the NAS  solution, storage pools, volumes, and network connections on the system. Clicking  any of the panes on the Dashboard takes you to a details screen for that selection. The  Dashboard screen also displays performance metrics of the system. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 35  Mail Recipients—Provides controls for configuring mail recipient accounts to  receive emails when a message severity threshold is reached, or when  AutoSupport Log sets (ASLs) are generated by the system.  Users—Provides controls for creating new user accounts for accessing the  BlackPearl user interface, as well as changing the password of existing accounts. Status The Status menu provides access to the tools for monitoring the BlackPearl NAS  solution in your environment.  Hardware—Displays information about the system and its components. Selecting  the tabs on the Hardware screen displays detailed component status information.  NAS > Pools—Displays information about any currently configured storage  pools.  NAS > Volumes—Displays information about any currently configured volumes  on an existing storage pool.  Messages—Displays system messages for the NAS solution.  Performance—Displays performance metrics for storage pools, individual drives,  and the CPUs in the integrated server.  Reports—Provides controls for generating reports about the configuration and  status of the NAS solution. Reports can be generated in XML or JSON (JavaScript  Object Notation) formats. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 36  Contact Information—Displays contact information for Spectra Logic Technical  Support, as well as the part and serial numbers for the NAS solution.  Tools—Displays tools to troubleshoot any internal or external server cabling errors. Logout Logs out the current user of the BlackPearl user interface and returns to the login  screen. The information in the following table can be found on the Status bar,  located at the bottom of all screens. Status Bar Available Options Hardware Provides an at‐a‐glance status of the overall health of the BlackPearl NAS solution.  Clicking this link takes you to the Hardware screen. For more information see View  the Status of Hardware Components on page 137. Messages Displays the severity, date, and time of the last warning, error, or informational  message that was generated. Clicking this link takes you to the Messages screen. For  more information see View System Messages on page 136. Note: This link does not display if there are no current system messages. Power Provides controls for rebooting and shutting down the system. For more  information see Reboot or Shut down a BlackPearl NAS Solution on page 146. The connection to the user interface is lost after running the reboot command.  Note: Wait while the system reboots before attempting to reconnect to the user interface. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 37: Status Icons

     Chrome™ version 22 or later  Mozilla ® ®  FireFox  version 27 or later  Apple ®  ® Safari  version 7 or later  Microsoft ® ®  Internet Explorer  version 11 or later  Spectra Logic recommends using Google Chrome to access  Notes: the BlackPearl user interface. OMMAND NTERFACE The command line interface provides text‐based configuration,  management, and monitoring of the BlackPearl NAS solution. Use the  command line interface to perform many of the tasks that are available  through the BlackPearl user interface such as configuring storage pools,  volumes, and shares; network administration; and monitoring the status of  the NAS solution. For a full list of the features available in the command  line interface, see the Spectra Verde NAS Solution Command Line Interface  Guide. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 38: Chapter 2 - Initial Configuration

    HAPTER Initial Configuration This chapter describes the initial setup and configuration steps for the  BlackPearl NAS solution. Note: If your NAS solution is a HotPair configuration, see the Spectra  BlackPearl & Verde HotPair Installation & Configuration Guide for  specific instructions on how to setup your NAS solution. Topic Before You Begin page 39 Connect Ethernet Cables page 39 Power On the BlackPearl NAS Solution page 39 BlackPearl NAS Solution with Archive Expansion  page 40 Nodes or 107‐Drive Disk Solution BlackPearl Master Nodes and BlackPearl Enterprise  page 40 Expansion Nodes Configure the BlackPearl Management Port page 42 Configure the BlackPearl Management Port page 42 Automatically Import Activation Keys page 43 Log In to the BlackPearl User Interface page 44 Configure the Data Connection page 46 Create a User...
  • Page 39: Before You Begin

    Before You Begin EFORE EGIN Make sure the NAS solution is installed in accordance with the Spectra  Verde NAS Solution Installation Guide. ONNECT THERNET ABLES Before proceeding with the below sections, you must connect Ethernet  cables to the management and data ports on the BlackPearl master node  rear panel. See Rear Panel of Master Nodes on page 25 for the location of  the Ethernet ports on the rear of the system. NAS S OWER N THE LACK EARL OLUTION Use the instructions in this section to power on a BlackPearl NAS solution.  During the power‐on sequence, the BlackPearl NAS solution initializes all  of its installed components and starts the BlackPearl web server. How you power on the solution depends on the hardware in your  configuration:  BlackPearl Master Nodes and BlackPearl Enterprise Expansion  Nodes on page  BlackPearl NAS Solution with Archive Expansion Nodes or 107‐ Drive Disk Solution on page October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 40: Disk Solution

    Figure 13 Press the power button. Wait while the BlackPearl NAS solution completes its power‐on sequence,  which takes approximately four minutes, depending on the configuration.  Note: Do not use the system’s front panel power button to power off  the NAS solution. See Reboot or Shut down a BlackPearl NAS  Solution on page 146 to reboot or shut down the system. BlackPearl NAS Solution with Archive Expansion Nodes or 107- Drive Disk Solution If your configuration includes one or more BlackPearl archive expansion  nodes or 107‐drive disk solutions, power on the expansion node(s) or  solution(s) before powering on the master node.  To power on a BlackPearl archive expansion node, plug both power cables  on the BlackPearl archive expansion node into power outlets near the rear  of the chassis. The BlackPearl archive expansion node immediately powers  on. Wait approximately five minutes while the expansion node initializes  before powering on a BlackPearl NAS solution master node. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 41 Power On the BlackPearl NAS Solution To power on a 107‐drive disk solution, remove the front bezel and reach  into the left side (as viewed from the front) and press the power  button.Wait approximately five minutes while the 107‐drive disk solution  initializes before powering on a BlackPearl NAS solution master node. To power on a BlackPearl NAS solution, remove the front bezel, and then  gently press the power button on the front panel. The power LED  illuminates indicating that power is on. See System Status LEDs on  page 135 for more information Power button Power LED Figure 14 Press the power button. Wait while the BlackPearl NAS solution completes its power‐on sequence,  which takes approximately four minutes, depending on the configuration.  Do not use the system’s front panel power button to power off  Note: the NAS solution. See Reboot or Shut down a BlackPearl NAS  Solution on page 146 to reboot or shut down the system. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 42: Onfigure The

    IP address for the management port. Using the BlackPearl NAS solution master node console is the  Note: recommended way to change the BlackPearl management port  IP address. If you cannot use the console, see Resolving a  Management Port IP Address Conflict on page 174 for  information on alternate methods. 1. Connect a monitor and USB keyboard to the BlackPearl master node.  See Rear Panel of Master Nodes on page 25 to locate the monitor and  USB connectors. The Console screen displays. Figure 15 The Console screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 43: Automatically Import Activation Keys

    3. Select either DHCP or Static as the addressing method. If you select static addressing, enter the following information:  IP Address—Enter a valid IPv4 address.   Netmask—Enter the subnet mask.   Default Gateway—Enter the default network gateway.  4. Select OK. The console screen displays showing the new IP address. Note: If a new IP address does not display, you may need to manually  refresh the console screen by pressing CTRL-R. 5. Connect a cable from your network to the BlackPearl management port  on the BlackPearl NAS solution master node. You are now able to  connect to the BlackPearl user interface with the IP address displayed  in Step 6. Disconnect the monitor and USB keyboard from the BlackPearl NAS  solution master node. UTOMATICALLY MPORT CTIVATION Activation keys enable features on the BlackPearl NAS solution. They are  tied to the serial number of the system for which they are issued, and  cannot be used on another NAS solution. Renewals of expired activation  keys are obtained by contacting Spectra Logic Technical Support (see  Contacting Spectra Logic on page 7).  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 44: Black

    Remove the USB device.  b. On the menu bar, select Status > Messages. The messages  screen displays. c. Select the message about safely removing the USB device, and  then select Action > Mark as read. The informational message  closes. N TO THE LACK EARL NTERFACE Use the following instructions to log into the BlackPearl user interface. Note: There is no limit to the number of users who can log in to the  user interface. Spectra Logic recommends only one person use  the interface at a time to avoid conflicting operations. 1. Using a standard web browser, enter the IP address for the BlackPearl  management port configured in Configure the BlackPearl Management  Port on page Note: The BlackPearl user interface uses a secure connection. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 45 Spectra Logic recommends that you change the default  Note: password for the primary administrator (see Edit a User on  page 126). Figure 17 The BlackPearl user interface Login screen. 4. Click > to log in.  The remainder of this guide assumes you are logged in to the BlackPearl user Important interface. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 46: Data

    5 on page 25). Optionally, a 40 GigE card or  10GBase‐T card can be installed in the NAS solution. The configuration  steps are the same for all port types.  You can create one or more data connections to the NAS  Notes: solution.   You can configure link aggregation for better performance.  While different types of Ethernet network interface cards can  be installed in the same BlackPearl NAS solution, only one  type port can be used in each link aggregation configuration.  You can only use the BlackPearl management port to access  the BlackPearl user interface. You cannot use this port for  data transfer.  For a HotPair configuration, see the Spectra BlackPearl & Verde  HotPair Installation & Configuration Guide for information on  configuring data connections. Configure an Aggregate Port Data Connection Link aggregation uses multiple Ethernet ports, configured with a single  MAC address, to improve data transfer speeds. See Link Aggregation  Notes on page 285 for more information. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 47 Use the following instructions to configure an aggregate port data  connection. 1. From the menu bar, select Configuration > Network, or select the  Network pane from the Dashboard screen. The Network screen  displays with information about the network connections of the NAS  solution. Figure 18 The Network screen. 2. From the menu bar, select Action > New Aggregate Interface. The New  Aggregate Interface dialog box displays. Note: Depending on your hardware configuration, the New Aggregate  Interface dialog box may look different than what is shown  below Figure 19 The New Aggregate Interface dialog box. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 48 Step  Prefix Length—Enter the subnet mask. If desired, you can enter Aliases, multiple IP and prefix lengths  Note: assigned to the data port. Use the + button to configure  additional IP and Netmask addresses. You can configure a  maximum of 16 aliases. 6. If applicable, enter the IPv4 Default Gateway.  Notes: If you selected DHCP in Step 4, this option is unavailable.  The gateway entered for the last configured IPv4 connection  sets the default gateway for the BlackPearl NAS solution. 7. If applicable, enter the IPv6 Default Gateway. Note: The gateway entered for the last configured IPv6 connection sets  the default gateway for the BlackPearl NAS solution. 8. Change the MTU (Maximum Transmission Unit) value, if desired. If you  set the MTU value to something other than 1500, ensure that your  switch configuration supports larger MTU settings, as well as all the  hosts on the network. 9. Click Save. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 49: Configure A Single Port Data Connection

    Configure a Single Port Data Connection Use the following instructions to configure a single port data connection. 1. From the menu bar, select Configuration > Network, or click the  Network pane on the Dashboard screen. The Network screen displays  with information about the network connections of the NAS solution. Figure 20 The Network screen. 2. Double‐click the Data # row in the Network Interfaces pane for the port  you want to configure, or select the Data # row and select Action > Edit  from the menu bar. The Edit Data # dialog box displays. Note: Depending on your hardware configuration, the Edit Data #  dialog box may look different than what is shown below. Figure 21 The Edit Data # dialog box. 3. Select DHCP to configure the system to automatically acquire an IPv4  address using DHCP. This setting does not apply to IPv6. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 50: Configure A Static Route

    6. If applicable, enter the IPv6 Default Gateway. The gateway entered for the last configured IPv6 connection sets  Note: the default gateway for the BlackPearl NAS solution. 7. Change the MTU (Maximum Transmission Unit) value, if desired. If you  set the MTU value to something other than 1500, ensure that your  switch configuration supports larger MTU settings, as well as all the  hosts on the network. 8. Click Save. Configure a Static Route The BlackPearl NAS solution only supports communication with one  default gateway. When configuring a BlackPearl NAS solution with  multiple data connections, each connection communicates via the gateway  entered when the connection was configured. The gateway entered for the  last configured connection sets the default gateway for the BlackPearl NAS  solution.  When configuring a system with multiple data connections, if each data  connection only communicates with its own network, a static route is not  required. When an additional network or external network is only  available from one, but not all, of the data connections configured on the  BlackPearl NAS solution, a static route is required in order for the solution  to communicate to the additional network. For example, if one data connection is on the 10.2.2.x network and another  connection is on the 10.2.4.x network, when the 10.2.3.x network is  connected externally to the 10.2.4.x network, a static route must be  configured on the BlackPearl NAS solution to route communication with  the 10.2.3.x network through the data connection on the 10.2.4.x network. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 51 1. From the menu bar, select Configuration > Network, or select the  Network pane from the Dashboard screen. The Network screen  displays (see Figure 18 on page 47). 2. From the menu bar, select Action > New Static Route. The Static Route  dialog box displays. Figure 22 The Static Route dialog box. 3. In the Destination field, enter either an IPv4 host address or network  address that you want to access through the data connection. 4. Enter the Gateway of the data connection used to communicate with the  isolated network. 5. Click Create. Repeat Step 2 on page 51 through Step 5 for each host computer on the  isolated network. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 52: Description Of User Types

    Administrator account can access the BlackPearl user interface and has  full control over all user interface functions.  Spectra Logic recommends changing the password  Note: for the primary administrator. See Edit a User on page 126. Monitor User A monitor user account is created by default. This account  can access all screens of the BlackPearl user interface. This  account is useful to view the status of the entire NAS  solution. Notes:  A monitor user can open any menu or function and  attempt to edit settings, but these changes are ignored  when the monitor user attempts to save the changes.  The default username and password are both monitor  using all lowercase letters.   Spectra Logic recommends that you change the  default password for the monitor account. See Edit a  User on page 126. A user with Login permissions is able to log into the  Login User BlackPearl user interface. Note: All users must have Login access to be able to log  on to the BlackPearl user interface. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 53: Create A User

    1. From the menu bar, select Configuration > Users. The Users screen  displays. Figure 23 The Users screen. 2. Select Action > New from the menu bar. The New User dialog box  displays. Figure 24 The New User dialog box. 3. Enter the desired Username for the user. The Username is limited to  16 characters and cannot contain capital letters, spaces, or special  characters. 4. Enter the user’s Full Name. 5. Enter and confirm the desired Password for the user. 6. If desired, enter a value for the Session Timeout in minutes. This value  cannot exceed 999 minutes. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 54: Next Steps

    Next Steps Access permissions. See Description of User  7. Select one or more User Types on page 52 for information on each level of user access  permission. Note: All users must have Login access to be able to log on to the  BlackPearl user interface. 8. Click Create to create the new user. TEPS The next steps depend on if you are configuring a BlackPearl NAS solution  as a standalone product, or if you plan to use your NAS solution in  conjunction with a BlackPearl Converged Storage system.  If you have a standalone BlackPearl NAS solution, continue to  Configuring Network Attached Storage on page  If you plan to use your BlackPearl NAS solution with a BlackPearl  Converged Storage system, skip to Network File Interface on  page 187. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 55: Attached Storage

    HAPTER Configuring Network Attached Storage This chapter describes using the BlackPearl user interface to configure  Network Attached Storage storage pools, volumes, and shares on a  BlackPearl NAS solution.  Topic Overview of NAS Storage Pools, Volumes, and Shares page 56 Storage Pools page 56 Volumes and Shares page 56 Create a Storage Pool page 57 Create a Volume  page 60 Create a Share page 63 Create a CIFS Share page 63 Create an NFS Share page 67 Configure NAS Services page 69 Configure the CIFS Service page 69 Configure the NFI Service page 70 Configure the NFS Service page 70...
  • Page 56: Storage Pools

    OOLS OLUMES HARES Storage pools, volumes, and shares are the logical components used to  interact with the data storage capacity provided by the BlackPearl NAS  solution.  Storage Pools A storage pool groups a set of physical drives together to create a virtual  drive that the operating system treats as a single physical drive. Depending  on how it is configured, a storage pool can provide mirrored, single‐parity,  double‐parity, or triple‐parity data protection. Higher levels of protection  allow for more individual drives to fail before the data is compromised.  The costs of higher protection are reduced storage availability and reduced  performance. Volumes and Shares Volumes are located on each storage pool. Volumes can be configured with  a minimum size and thin provisioned with a maximum size. When you  create a volume, you can specify whether it uses compression, and whether  the time stamp for files is updated when the file is read (access time). After the volume is created, it can be shared (made available for use by  other computers on the network) via either the NFS service or the CIFS  service. Naming Considerations When a volume is shared, the volume mount path uses a combination of  the storage pool name and volume name. The combined name must be less  than 78 ASCII characters, or the volume fails to mount. Additionally,  storage pool names are limited to 48 characters, and volume names are  limited to 62 characters. Even if the storage pool name is a single character,  you are still restricted to 62 characters in the volume name.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 57: Pool

    When creating a new storage pool, keep the following in mind:  Each storage pool requires a minimum of one drive. Spectra Logic  recommends using eight drives or more in a storage pool to reduce the  impact of the overhead. Overhead is the space on the storage pool used  to store parity data, and not used for data storage.  Drives can only be associated with one storage pool. To create a new  storage pool using drives that are already configured in an existing  storage pool, you must first delete the existing storage pool as  described in Delete a Storage Pool on page 99. You can then create a  new storage pool using newly available drives.  Any drives not configured in storage pools act as global spare drives. If  a drive failure occurs, the system immediately activates a global spare.  When the failed drive is replaced it becomes a spare.  Spectra Logic recommends leaving at least one drive for a global spare. Use the following steps to create a new storage pool.  1. From the menu bar, select Configuration > NAS > Pools, or click the  Pools pane on the Dashboard. The NAS Pools screen displays. Figure 25 The NAS Pools screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 58 Create a Storage Pool 2. Select Action > New. A dialog box opens to show the default  configuration options for the new pool. Note: The Storage Pool Preview pane does not display until you have  selected the disks you want to use in the storage pool Figure 26 The New Pool dialog box. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 59 Use the drop‐down menu to select the number of drives to include in the pool.  Select Drives To If your system contains more than one type of disk drive, multiple drop‐down  menus are present, but only one type can be assigned to a pool.  Any drive not in a storage pool acts as a global spare. A global spare drive is  activated as soon as a drive configured in a storage pool fails. Select Protection Use the radio buttons to select the protection level for the pool. Only one option  Level can be selected. Use the Storage Pool Preview information to compare the fault  tolerance and required overhead for each configuration. None—The pool is not configured to provide data protection. Any drive failure  results in data loss. Mirror—Data is striped across two mirrors. Any detected data corruption is  corrected using checksums. This type of RAID offers the best performance for  small random reads and writes. Single parity—Data is striped across multiple single‐parity arrays, which can  tolerate one drive failure without data loss. This type of RAID has faster  performance than double‐ and triple‐parity based RAIDs. Double parity—Data is striped across multiple double‐parity arrays, which can  tolerate two drive failures without data loss. In most cases, double‐parity  provides the best balance between data protection, performance, and storage  capacity. Triple parity—Data is striped across multiple triple‐parity arrays, which can  tolerate three drive failures without data loss. This type of RAID provides the  most data protection. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 60: Create A Volume

    Use the drop‐down menu to select the number of drives to use to increase write  Performance performance when the pool is shared using NFS. This feature is only intended  for storage pools with NFS shares and typically has little impact on CIFS share  performance. 4. Click Create. The NAS Pools screen displays. The storage pool is  automatically created and is available for use immediately. REATE A OLUME Before you begin using a storage pool to store data, you must create one or  more volumes to organize how the information is stored on the pool. After  you create a volume, you can share the volume using NFS or CIFS, but not  both.  Note: If you want to configure the volume to use the NFI service to  automatically transfer files from the NAS storage to a BlackPearl  system, configure the NFI service before configuring the volume.  See Configure the NFI Service on page Use the following steps to create a volume on a storage pool. 1. From the menu bar, select Configuration > NAS > Volumes, or click the  Volumes pane on the Dashboard. The Volumes screen displays. Figure 27 The Volumes screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 61 2. Select Action > New. The New Volume dialog box displays. Figure 28 The New Volume dialog box. 3. Configure the volume as required for your environment. For this option..Do the following... Name Enter a name for the new volume. Volume names are limited to 62 characters or  fewer.   The combined storage pool and volume name must be 78 characters or  fewer.  NFS does not allow spaces in share names. As a result, any spaces in the  volume name are replaced by underscores in the corresponding NFS share  name. The BlackPearl user interface displays the volume name without the  underscores. For example, for a volume named Share One, the  corresponding NFS share is named Share_One to external network  computers, but it is named Share One in the BlackPearl user interface. Pool Select the storage pool on which to create the volume. If there are multiple  storage pools configured on the BlackPearl NAS solution, use the drop‐down  menu to select the Pool where you want to create the volume. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 62 DO NOT enable this setting if you plan to share the volume using NFS. If desired, select the check box to enable the BlackPearl NAS solution to  Compression compress stored data. If the data being written is compressible there is an  increase in write performance to the volume, which is dependent on how much  compression occurs on the data being written. The data compression process  uses CPU cycles to perform the compression. If compression is enabled and  non‐compressible data is written to the volume, the compression process may  use an excessive number of CPU cycles, slowing the overall performance of  the system. If desired, select the check box to configure the system to update the time stamp  Access Time of a file when it is read from the volume. Selecting Access Time may slow  performance. Note: The options for the NFI Volume Policy are only used in  conjunction with a BlackPearl system. To configure NFI, see  Appendix A Network File Interface on page 187. 4. Click Create. The Volumes screen refreshes to show the new volume.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 63: Create A Cifs Share

    Create a CIFS Share Spectra Logic recommends using Active Directory to control access to CIFS  shares on the BlackPearl NAS solution. However, if your Windows  operating system environment does not use Active Directory, you can  enable local administrator status on the system to allow a specified user to  access the CIFS shares in a Windows workgroup environment. The  username and password configured on the BlackPearl NAS solution are  used to access the CIFS shares when using a Windows workgroup  environment. Join an Active Directory Domain If your Windows environment uses Active Directory, you must join an  Active Directory domain before creating a CIFS share. See Configure the  Active Directory Service on page 113 for more information. After joining  the Active Directory domain, continue with Create a CIFS Share on  page Enable Local Administrator Status If your Windows environment does not use Active Directory and you have  not previously done so, you must edit a user to enable local administrator  status. If you have previously enabled local administrator status for a user,  continue with Create a CIFS Share on page Note: Alternatively, you can create a new user with local administrator  status. See Create a User on page October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 64 Create a Share 1. From the menu bar, select Configuration > Users. The Users screen  displays.  Figure 29 The Users screen. 2. Double‐click the row for the user for which you want to enable local  administrator status, or select the user, and then select Action > Edit.  The Edit User dialog box displays. Figure 30 The Edit User dialog box. 3. Select the CIFS check box to configure the user with local administrator  status on the system. If desired, change other settings as described in Edit a User on  page 126. 5. Click Save. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 65 Figure 32 The New CIFS Share dialog box. 3. Use the drop‐down menu to select the Volume you want to share. 4. Set the Name for the CIFS share. This is the name that is displayed in  Active Directory configurations. 5. The network address displayed for Path is the address of the share you  are currently configuring. The default path allows access to the root of  the volume.  After creating the CIFS share, you can connect to it using your  Note: Windows‐based host and create subdirectories in the share. You  can then edit the share and use the Path field to allow access to  specific directories by specifying the exact subdirectory (see Edit  a Share on page 111). For example, if you enter /home/user in the path field, any  user that connects to this CIFS share only has access to the  “user” directory, even if the “home” volume contains other  directories. 6. If desired, select Read-only to configure the CIFS share as read only. 7. Click Create. The newly created share is listed on the CIFS Shares screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 66 Create a Share Set Permissions for CIFS Share When a CIFS share is created, the default permission is “Everyone”. This  allows a user creating the initial shares to easily set the proper permissions  for additional users without requiring the Active Directory Domain  administrator password. 1. Mount the new CIFS share to your Microsoft Windows operating  system host. 2. Using Windows Explorer, right‐click on the CIFS share, and select  Properties. The General tab of the Properties window displays. You cannot use the Computer Management panel to set  Note: permissions on CIFS shares. Figure 33 The Properties window. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 67: Create An Nfs Share

    Create a Share 3. Click Security. The Security tab displays. Figure 34 The Security tab. 4. Add, or remove users, or modify permissions for users as needed for  your storage environment. 5. Click OK. Create an NFS Share Use the following steps to create an NFS share. 1. From the menu bar, select Configuration > NAS > Shares > NFS. The  NFS Shares screen displays.  Figure 35 The NFS Shares screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 68 5. If desired, enter a comment in the Comment field. This comment only  displays on the BlackPearl user interface. 6. In the Host Access Control pane, enter the IP address and permission  level of all hosts that you want to access the volume. Hosts not listed are  not able to access the volume. In addition to the host IP address, you  must include one of the following permission parameters for each host  you add to the BlackPearl NAS solution. Parameter Description Root Access—The host can access the NFS share with root access to the share.  norootsquash This host is used to set permissions for rootsquash users. rootsquash Standard Access—The host can access the NFS share, but does not have root  access. Standard access allows write permission to the share, but does not allow  the user to delete, modify, or rename files for which they do not have write  permission. Read Only—The host can access the NFS share, but cannot write data to the  shared volume. For example, entering “192.168.32.25 rootsquash” allows the  specified host to access the share with standard access. If you want to allow all hosts to access the share, type * and include the  permission parameter. For example, entering “* norootsquash” allows all hosts to access the share with root access. 7. Click Create. The newly created share is listed on the NFS Shares screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 69: Onfigure Nas Services

    Improperly configuring advanced parameters can expose security vulnerabilities Caution and other serious issues. Advanced parameters should not be configured without a full understanding of the consequences. 1. From the menu bar, select Configuration > Services. The Services  screen displays (see Figure 37 on page 69). 2. Double‐click the CIFS row, or select the CIFS row and select Action > Show Details. The CIFS details screen displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 70: Configure The Nfi Service

    4. Enter the desired Parameter and Value. 5. Click Create. Configure the NFI Service The NFI service is only used in conjunction with a BlackPearl Converged  Storage system. For information on configuring the NFI service, see  Appendix A Network File Interface on page 187. Configure the NFS Service The BlackPearl user interface lets you configure the transmission protocols  and number of threads used by the NFS service. Use the following steps to  edit the NFS service. 1. Select Configuration > Services to display the Services screen (see  Figure 37 on page 69). 2. Double‐click the NFS service, or select the service, and then select  Action > Show Details. The NFS service details screen displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 71: Onfigure Replication

    5. Set the number of Threads for use by the service. The default setting is sufficient for most network configurations. Note: 6. Click Save. ONFIGURE EPLICATION If the BlackPearl NAS solution is on a network with other BlackPearl NAS  solutions or BlackPearl Converged Storage systems with NAS enabled, you  can select to replicate data from the NAS volumes on the NAS solution to  one or multiple NAS replication targets. Replication uses the same data  interface that the system uses for normal file storage operations, so  replication to multiple targets may decrease transfer speeds. Once you configure the Replication service, you need to configure each  volume on the system that you want to replicate. Use the instructions in  this section to configure the Replication service and to configure folders for  replication.  This replication service is only for replicating NAS volumes  Notes: on the system to other systems with NAS enabled. To  replicate NAS volumes to BlackPearl Converged Storage  systems other than NAS, use NFI replication (see Configure  the NFI Service on page 70).  There must be enough space on the target to hold the  replicated data, or the replication fails.  Multiple volumes on the source system cannot replicate to a  single volume on the target. Each volume on the source  system must replicate to a different volume on the target. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 72: Configure The Nas Replication Service

    1. In the source system’s BlackPearl user interface, select Configuration > Services to display the Services screen (see Figure 37 on page 69). 2. Double‐click the Replication service, or select the service, and then  select Action > Show Details. The Replication service details screen  displays. Figure 40 The Replication service details screen. 3. Select Action > Create. The Add Replication Target dialog box  displays. Figure 41 The Add Replication Target dialog box. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 73: Configure The Target System

    Any data in the specified target volume is deleted each time the source system replicates data to the target system. Configure Volumes for Replication 1. In the source system’s user interface, select Configuration > NAS > Volumes. The Volumes screen displays. 2. Double‐click the volume name you want to configure to replicate, or  select the folder and select Action > Show Details. The details screen  for the volume displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 74 You cannot use this volume for normal data storage operations, it can only be used Caution as a replication target. Any data in the specified target volume is deleted each time the source system replicates data to the target system.  If the volume does not exist on the target, it is created.  If the volume exists on the target, a warning message displays  informing you that any data currently in the target folder is erased  each time data is replicated. Confirm the warning message to  continue. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 75 3. Click Create. Create a Daily Schedule 1. Select Daily as the interval for the replication schedule. The dialog box  changes to display options for the daily interval setting. Figure 43 The Configure Replication dialog box showing the daily interval options. 2. Enter a time value for Start Time, and include AM or PM after the value.  This field is not case sensitive. 3. Enter a number for Every _ days. This value specifies the interval, in  days, between replicating data. For example, if this value is set to 2, the  system replicates data every two days at the time specified in Step 4. Click Create. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 76 Create a Weekly Schedule 1. Select Weekly as the interval for the replication schedule. The dialog  box changes to display options for the weekly interval setting. Figure 44 The Configure Replication dialog box showing the weekly interval options. 2. Enter a time value for Start Time, and include AM or PM after the value.  This field is not case sensitive. 3. Select one or more days for Every week on:. This determines the day(s)  of each week the system replicates data. For example, based on the  selections in Figure 44, the system replicates data every Monday,  Wednesday, and Friday at 5:00 AM. 4. Click Create. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 77: Chapter 4 - Managing Network Attached Storage

    HAPTER Managing Network Attached Storage This chapter describes using the BlackPearl user interface to manage NAS  storage pools, volumes, and shares on the BlackPearl NAS solution after  initial configuration. For initial configuration steps, see Chapter 3 –  Configuring Network Attached Storage on page 55.  Topic Managing Storage Pools page 78 Edit a Storage Pool page 78 Expand a Storage Pool page 79 Delete a Storage Pool page 80 Managing Volumes page 80 Move a Volume page 81 Cancel a Volume Move page 81 Edit a Volume page 82 Delete a Volume page 84 Volume Snapshots page 84 Create a Snapshot...
  • Page 78: Managing Storage Pools

    Figure 45 The Edit Pool Name dialog box. Note: The Name field is greyed out and cannot be changed. 3. If desired, enter a percentage for the High Water Mark. When the used  space on the pool reaches this percentage, an alert is generated. Enter 0  if you do not want to set an alert level. 4. If desired, enable or disable Power Saving Mode for the storage pool.  Enabling this feature configures the standby timer to 60 minutes. When  there is no I/O to the storage pool for 60 minutes, the drives in the pool  spin down and use minimal power. Note: All drives in the storage pool must be power‐saving compatible. 5. If desired, use the Write Performance Drives drop‐down menu to select  the number of write performance drives to allocate to the storage pool. 6. Click Save. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 79: Expand A Storage Pool

    Use the following steps to expand a storage pool. 1. From the menu bar, select Configuration > NAS > Pools, or click the  Pools pane on the Dashboard. The NAS Pools screen displays (see  Figure 18 on page 50). 2. From the list of existing storage pools, select the storage pool you want  to expand, and then select Action > Expand. The Expand pool name  dialog box displays options for adding additional drives to the storage  pool. Figure 46 The Expand pool name dialog box. 3. Use the slider to increase the number of drives to use in the storage  pool. As you make changes, the graphics beneath the slider update to  show the impact your changes have on the storage pool. 4. When you are satisfied with the new configuration, click Save. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 80: Delete A Storage Pool

    1. From the menu bar, select Configuration > NAS > Pools, or click the  Pools pane on the Dashboard. The NAS Pools screen displays (see  Figure 18 on page 50). 2. From the list of existing storage pools, select the storage pool you want  to delete, and then select Action > Delete. A dialog box displays asking  you to confirm the deletion. Figure 47 Confirm the storage pool deletion. 3. Type DELETE POOL in the entry field and click Delete to delete the  storage pool. 4. If desired, create a new storage pool that includes the disks no longer in  use, as described in Create a New Storage Pool on page ANAGING OLUMES After creating one or more volumes, use the instructions in this section to  move, edit, or delete a volume. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 81: Move A Volume

    3. Use the drop‐down menu to select the destination pool for the volume. 4. Click Move. The volume is moved to the selected pool. Cancel a Volume Move If desired, you can cancel the move of a volume from one storage pool to  another. 1. From the menu bar, select Configuration > NAS > Volumes, or click the  Volumes pane on the Dashboard. The Volumes screen displays (see  Figure 27 on page 60). 2. Select the volume you want to cancel moving to a different storage  pool, and then select Action > Cancel Move. The Cancel Move Volume  dialog box displays. 3. Confirm cancelling the in‐progress volume move.  The data on the target pool is deleted. Data on the source pool is  Note: unaffected and persists on the source pool after canceling the  move. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 82: Edit A Volume

    Managing Volumes Edit a Volume After creating a volume, you can edit it to change the volume  configuration. Use the following steps to edit a volume. 1. From the menu bar, select Configuration > NAS > Volumes, or click the  Volumes pane on the Dashboard. The Volumes screen displays (see  Figure 20 on page 53). 2. Double‐click the volume you want to edit, or select the volume and  then select Action > Edit. The Edit volume name dialog box displays. Figure 49 The Edit volume name dialog box. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 83  Volumes are thin provisioned, so it is possible for the combined allocated  maximum storage of all volumes to exceed the physical space available. Compression If desired, select the check box to enable the BlackPearl NAS solution to  compress data stored on the system. Note: Changing the compression setting only affects data written to the  volume after the compression setting is changed. It does not affect data already  on the volume. Access Time If desired, select the check box to configure the system to update the time stamp  of a file when it is read from the volume. Selecting Access Time may slow  performance. Read Only If desired, select the check box to configure the volume so that data can be read,  but not written to the volume. The options for the NFI Volume Policy are only used in  Note: conjunction with a BlackPearl Converged Storage system. To  configure NFI, see Appendix A Network File Interface on  page 187. 4. Click Save. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 84: Delete A Volume

    Deleting a volume deletes all data in the volume. This action cannot be undone. Caution Figure 50 Confirm the volume deletion. 3. Type DELETE VOLUME in the entry field and click Delete to delete the  volume. OLUME NAPSHOTS Volume Snapshots are images of a volume’s configuration and data  makeup as they were when the snapshot was generated. Restoring to a  previously created snapshot allows you to go “back in time” and restore  the volume to the state it was in when the snapshot was created. Snapshots  can be useful in restoring a file that was accidentally deleted. Snapshots  can be created manually or on a schedule. Volume snapshots are retained  on the system until they are manually deleted, or the set Maximum  Number of Snapshots limit is reached. When the limit is reached, the oldest  snapshot is deleted freeing up capacity held by that snapshot. Snapshots are created instantly without any impact to system  performance. Snapshots initially occupy very little space on the storage  pool, but grow as data is deleted, because this data must be retained by the  snapshot. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 85: Create A Snapshot

    1. From the menu bar, select Configuration > NAS > Volumes, or click the  Volumes pane on the Dashboard. The Volumes screen displays (see  Figure 20 on page 53). 2. Double‐click the volume you want to use to create a snapshot, or select  the volume, and then select Action > Show Details. The details screen  for that volume displays. Figure 51 The Volume details screen. 3. On the Volume details screen, select Action > New Snapshot. The New  Snapshot dialog box displays. Figure 52 The New Snapshot dialog box. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 86: Create A Snapshot Schedule

    Figure 53 The New Snapshot Schedule dialog box showing the hourly interval options. 3. Change the default name of the snapshot schedule, if desired. 4. Enter a number for the Maximum Number of Snapshots. When the  maximum number is reached, the system deletes the oldest snapshot. 5. Enter a number for Every _ hours on the hour. This value specifies the  interval, in hours, between generating snapshots. For example, if this  value is set to 4, the system creates a snapshot every four hours. The  maximum setting for this field is 48, where the system creates a  snapshot every two days. 6. Click Create. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 87 3. Change the default name of the snapshot schedule, if desired. 4. Enter a number for the Maximum Number of Snapshots. When the  maximum number is reached, the system deletes the oldest snapshot. 5. Enter a time value for Start Time, and include AM or PM after the value.  This field is not case sensitive. 6. Enter a number for Every _ days. This value specifies the interval, in  days, between generating snapshots. For example, if this value is set to  2, the system creates a snapshot every two days at the time specified in  Step 7. Click Create. Create a Weekly Schedule On the Volume details screen (see Figure 51 on page 85), select Action > New Snapshot Schedule. The New Snapshot Schedule dialog box  displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 88: Delete A Snapshot Schedule

    55, the system creates a snapshot every  Monday, Wednesday, and Friday at 5:00 AM. 7. Click Create. Delete a Snapshot Schedule If desired, you can delete a previously created snapshot schedule. Note: Deleting a snapshot schedule does not delete the snapshots  previously created by the snapshot schedule. To delete  snapshots, see Delete a Snapshot on page Use the instructions in this section to delete a snapshot schedule. 1. From the menu bar, select Configuration > NAS > Volumes, or click the  Volumes pane on the Dashboard. The Volumes screen displays (see  Figure 27 on page 60). 2. Double‐click the volume for which you want to delete the snapshot  schedule, or select the volume, and then select Action > Show Details.  The details screen for that volume displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 89: Delete A Snapshot

    4. Click Delete. Delete a Snapshot Use the following steps to delete a snapshot. 1. From the menu bar, select Configuration > NAS > Volumes, or click the  Volumes pane on the Dashboard. The Volumes screen displays (see  Figure 20 on page 53). 2. Double‐click the volume for which you want to delete a snapshot, or  select the volume, and then select Action > Show Details. The details  screen for that volume displays. Figure 57 The Volume details screen showing a snapshot. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 90: Restore To A Snapshot

    A confirmation window displays. Figure 58 Confirm the snapshot deletion (Delete Snapshot window shown). 4. Type the indicated text in the entry field and click Delete to delete the  selected snapshot, or all snapshots. Restore to a Snapshot Use the following instructions to restore a volume to its previous state  using a previously generated snapshot. If you only want to restore a single file in the snapshot, see  Note: Retrieve a Single File from a Snapshot on page 1. From the menu bar, select Configuration > NAS > Volumes, or click the  Volumes pane on the Dashboard. The Volumes screen displays (see  Figure 20 on page 53). October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 91 Caution any snapshots that were saved after the one you are using for the restore process. This action cannot be undone. 4. A dialog box displays, asking you to confirm the rollback. Select  Rollback to restore the volume to its state when the snapshot was  created. Figure 60 Confirm the volume snapshot rollback. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 92: Retrieve A Single File From A Snapshot

    Use the instructions in this section to retrieve a single file from a snapshot. 1. Using a remote host that has access to the shared volume for which you  need to restore a single file, map the share containing the snapshot to  the remote host (for example “Z:\”) 2. You cannot browse to the snapshots directory using Windows explorer,  you must enter the full path of the snapshot from which you want to  retrieve a file in the Windows explorer address bar. Snapshots are  organized as follows: Z:\zfs\snapshot\snapshot name 3. The specified directory displays. All files contained in the snapshot  display. 4. Locate the file you want to restore and copy it to the appropriate  location.  ANAGING HARES After creating one or more shares, use the instructions in this section to edit  or delete a share. Edit a CIFS Share After creating a CIFS share, you can edit it to change the configuration. 1. From the menu bar, select Configuration > Shares > CIFS. The CIFS  Shares screen displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 93: Edit An Nfs Share

    3. Select or clear the Read-only check box. You cannot change the name  once the CIFS share is created. 4. Click Save. Edit an NFS Share After creating an NFS share, you can edit it to change the configuration. 1. From the menu bar, select Configuration > Shares > NFS. The NFS  Shares screen displays. 2. Select the share you want to edit, and then select Action > Edit. The  Edit NFS Share dialog box displays. Figure 62 The Edit NFS Share dialog box. Make the desired changes (see Create an NFS Share on page 67 for  more information), and click Save. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 94: Delete A Share

    Configuration > Shares > CIFS. The CIFS Shares screen displays. —OR— If you need to delete an NFS share, from the menu bar, select  Configuration > Shares > NFS. The NFS Shares screen displays. 2. Select the share you want to delete, and then select Action > Delete. 3. A dialog box displays asking you to confirm the deletion. Click Delete  to remove the share. Note: Clicking Delete does not delete the volume. It only removes the  volume from the list of shares and makes it inaccessible to  remote hosts. The volume is still present on the system and listed  on the Volumes screen. Figure 63 Confirm removing the share. NAS R ANAGING EPLICATION After configuring replication, use the instructions in this section to  manually start or cancel a volume replication, edit or delete the NAS  replication configuration, and to restore replicated files. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 95: Manually Start Nas Replication

    Figure 64 The Replicate Now confirmation window. 4. Click Replicate Now to begin manual replication. Cancel a NAS Replication In Progress If desired, you can cancel any NAS replications currently in progress.  Canceling a replication stops the replication and deletes any data the target  received during the replication. Use the steps in this section to cancel a  NAS replication. 1. On the source system user interface, select Configuration > NAS > Volumes. The Volumes screen displays. 2. Double‐click the volume name for which you want to cancel  replication, or select the volume and select Action > Show Details. The  details screen for the volume displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 96: Restoring Files From A Nas Replication Target

    Restoring Files from a NAS Replication Target If the source BlackPearl NAS solution in a replication configuration fails,  you can restore files from the replication target. Use the instructions in this  section to restore files from a replication target. 1. On the source system user interface, clear the write‐protected status of  the replicated volume. Note: You cannot add a share while the volume has write‐protection  enabled. a. From the menu bar, select Configuration > NAS > Volumes. The  Volumes screen displays. b. Select the replicated volume and select Action > Edit. The Edit  volume name dialog box displays. c. Clear the Read Only check box. d. Click Save. 2. Depending on your operating system environment, create either a CIFS  or NFS share, selecting the replicated volume during the creation  process. See Create a Share on page 63 for instructions. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 97: Disable A Nas Replication For A Volume

    Click Save. 4. Using your host machine, connect to the new share on the replication  target. 5. Copy the needed files from the replication target share to the source  system. 6. If desired, delete the share once you have restored the needed files. See  Delete a Share on page 111. Disable a NAS Replication for a Volume Use the instructions in this section to prevent any further replication from  a volume currently configured to use NAS replication. 1. On the source system user interface, select Configuration > NAS > Volumes. The Volumes screen displays. 2. Double‐click the volume name you want to stop replicating, or select  the volume and select Action > Show Details. The details screen for the  volume displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 98: Edit The Nas Replication Service

    Figure 66 The Configure Replication dialog box. 4. Clear the Enabled check box. The other options on the dialog box grey  out and become un‐editable.  5. Click Configure. The volume no longer replicates to the target. Edit the NAS Replication Service 1. On the source system’s BlackPearl user interface, select Configuration > Services to display the Services screen (see Figure 37 on page 69). 2. Double‐click the Replication service, or select the service, and then  select Action > Show Details. The Replication service details screen  displays. Figure 67 The Replication service details screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 99: Delete The Nas Replication Service Configuration

    Replication Target Data IP Address field. Note: Do not use http:// or https:// to precede the IP address or  hostname. 6. If desired, modify the username of a user configured on the target in  the Username field. 7. Enter the user password in the Password field, if one is set. Otherwise,  leave the field blank. 8. If desired, select the Enable Secure Transfer check box to configure the  source system to encrypt the replicated data before transferring it to the  target system, or clear the check box to transfer data without  encryption. Data is encrypted using Secure Socket Layer (SSL). 9. Click Save. Delete the NAS Replication Service Configuration 1. On the source system select Configuration > Services to display the  Services screen (see Figure 37 on page 69). October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 100 Managing NAS Replication 2. Double‐click the Replication service, or select the service, and then  select Action > Show Details. The Replication service details screen  displays. Figure 69 The Replication service details screen. 3. Select the replication target in the Replication service details screen,  and select Action > Delete. The Delete Replication Target dialog box  displays. 4. Click Delete to remove the replication target. The source system no  longer replicates data to the target system. Repeat Step 3 and Step 4 to delete additional replication targets, if  desired. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 101: Chapter 5 - Configuring A Blackpearl Nas Solution

    HAPTER Configuring a BlackPearl NAS Solution This chapter describes using the BlackPearl user interface to configure  additional options for the BlackPearl NAS solution.  Task Configure Network Connections and Settings page 102 Configure Ethernet Ports page 102 Configure DNS Settings page 108 Configure SMTP Settings page 109 Configure Date and Time page 110 Edit the System Name page 111 Configure Networking Services page 112 Configure the Active Directory Service page 113 Configure the SNMP Service page 118 Configure Users page 126 Description of User Types page 126 Create a User page 126...
  • Page 102: Configure Network Connections And Settings

    Figure 70 The Network screen. Configure Ethernet Ports This section describes using the BlackPearl user interface to configure the  IP addressing for the Ethernet ports in the BlackPearl NAS solution master  node. The BlackPearl NAS solution includes two 10GBase‐T ports and two  10 GigE ports on the rear panel (see Figure 5 on page 25). Optionally, a  two‐port 40 GigE card can be installed.  You can create one or more data connections to the system.  Notes:  You can configure link aggregation for better performance.  While different types of Ethernet network interface cards can  be installed in the same BlackPearl NAS solution, only one  type port can be used in each link aggregation configuration.  You can only use the BlackPearl management port to access  the BlackPearl user interface. You cannot use this port for  data transfer.  The data connection(s) and BlackPearl management port are  initially configured in Chapter 2 – Initial Configuration on  page 38. Use the instructions in this section to configure  network settings after initial setup is complete. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 103 If you select DHCP, you are not able to see the IP address assigned by DHCP before Important you are logged out of the BlackPearl user interface. Contact your system administrator to determine the DHCP address for the management port. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 104  The gateway entered for the last configured IPv4 connection  sets the default gateway for the BlackPearl NAS solution. 6. If applicable, enter the IPv6 Default Gateway. Note: The gateway entered for the last configured IPv6 connection sets  the default gateway for the BlackPearl NAS solution. 7. Change the MTU value, if desired. If you set the MTU value to  something other than 1500, ensure that your switch configuration  supports larger MTU settings, as well as all the hosts on the network. 8. Click Save. Note: When you change the IP address of the BlackPearl management  port, you lose your connection to the user interface when you  save your changes. To re‐establish the connection, enter the new  IP address in your browser and log in again. Edit an Aggregate Data Connection If desired, you can edit an aggregate data connection after it is created. 1. From the menu bar, select Configuration > Network, or click the  Network pane from the Dashboard screen. The Network screen displays  (see Figure 70 on page 102). October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 105  IP Address—Enter a valid IPv4 or IPv6 address.  Note: You cannot enter an IPv4 address if you selected DHCP in  Step  Prefix Length—Enter the subnet mask. Note: If desired, you can enter Aliases, multiple IP and prefix lengths  assigned to the data port. Use the + button to configure  additional IP and Netmask addresses. You can configure a  maximum of 16 aliases. To remove an existing static address, click the - button. 6. If applicable, enter the IPv4 Default Gateway.  Notes: If you selected DHCP in Step 4, this option is unavailable.  The gateway entered for the last configured IPv4 connection  sets the default gateway for the BlackPearl NAS solution. 7. If applicable, enter the IPv6 Default Gateway. Note: The gateway entered for the last configured IPv6 connection sets  the default gateway for the BlackPearl NAS solution. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 106 Figure 73 The Edit Data # dialog box. 3. Select DHCP to configure the system to automatically acquire an IPv4  address using DHCP. This setting does not apply to IPv6. 4. To configure a static IP address, click the + button and enter the  following information:  IP Address—Enter a valid IPv4 or IPv6 address.  Note: You cannot enter an IP address if you selected DHCP in Step  Prefix Length—Enter the subnet mask. If desired, you can enter Aliases, multiple IP and prefix lengths  Note: assigned to the data port. Use the + button to configure  additional IP and Netmask addresses. You can configure a  maximum of 16 aliases. To remove an existing static address, click the - button. 5. If applicable, enter the IPv4 Default Gateway.  If you selected DHCP in Step 4, this option is unavailable. Notes:  The gateway entered for the last configured IPv4 connection  sets the default gateway for the BlackPearl NAS solution. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 107 8. Click Save. Edit a Static Route Use the instructions in this section to edit a static route. 1. From the menu bar, select Configuration > Network, or select the  Network pane from the Dashboard screen. The Network screen  displays (see Figure 70 on page 102). 2. Double‐click the static route you want to edit. The Static Route dialog  box displays. Figure 74 The Static Route dialog box. 3. If desired, in the Destination field, edit the network address that you  want to access through the data connection. 4. If desired, edit the Gateway of the data connection used to communicate  with the isolated network.  5. Click Create. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 108: Configure Dns Settings

    (see Figure 70 on page 102). 2. Select the row of the configuration you want to clear and then select  Action > Clear from the menu bar. A confirmation window displays. 3. Click Delete to clear the Ethernet configuration. Configure DNS Settings The DNS settings on the BlackPearl NAS solution are used to allow  domain name lookup on the system. Use the following instructions to  enter DNS information on the system. 1. From the menu bar, select Configuration > Network, or click the  Network pane on the Dashboard screen. The Network screen displays  (see Figure 70 on page 102). 2. In the DNS pane of the Network screen, double‐click the DNS row, or  select the DNS row and then select Action > Edit. The Edit DNS screen  displays. Figure 75 Edit DNS information. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 109: Configure Smtp Settings

    4. If the BlackPearl management port is configured with a static IP  address, or if you selected Manual, enter the following information: a. Enter the IP address of one or more name servers in the Name Servers field. b. Enter the URL of one or more search domains in the Search Domains  field. 5. Click Save. Configure SMTP Settings Use the SMTP settings to associate the BlackPearl NAS solution with a mail  server. The system uses this SMTP server to send emails whenever ASLs or  certain types of messages are generated. 1. From the menu bar, select Configuration > Network, or select the  Network pane on the Dashboard screen. The Network screen displays. Figure 76 The SMTP pane of the Network screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 110: Configure Date And Time

    3. Enter the SMTP Server and SMTP Port information. 4. Using the drop‐down menu, select the SMTP Authentication Type required by your mail server. 5. If your SMTP server uses TLS (Transport Layer Security)  authentication, select the Enable TLS Authentication check box and enter  the required Username and Password information. 6. Enter an email address in the From Address field. This is the email  address that displays as the sender whenever the system generates an  email. This email address should uniquely identify the BlackPearl NAS  solution to assist in troubleshooting and be recognized by the SMTP  server as a valid domain address. 7. Click Save. Configure Date and Time The date and time can be set manually or using NTP (Network Time  Protocol). The NTP settings are used to automatically control the current  time on the BlackPearl NAS solution.  If you plan to join an Active Directory domain, you must  Note: configure the BlackPearl NAS solution to use NTP. If the system  time and the Active Directory time are more than 5 minutes  apart, joining the domain fails. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 111: Edit The System Name

    Figure 79 The Time Settings dialog box. 3. Select Manual or NTP. a. If you select Manual, enter the current time in the Time field. Enter  either 12‐hour time values and include AM or PM, or use 24‐hour  time values. Click the Date field. A calendar displays. Select the  current date. b. If you select NTP, enter the NTP server information for the Primary NTP Server. If desired, enter the NTP server information for the Secondary NTP Server.  4. Click Save. Edit the System Name 1. From the menu bar, select Configuration > Network, or click the  Network pane from the Dashboard screen. The Network screen  displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 112: Configure Networking Services

    Figure 80 The Edit System Name dialog box. 3. Enter the desired Name for the system. The system only allows letters,  numbers, the period character (.), and the hyphen character (‐) in the  system name.  The first section of the system name, up to a delimiter cannot  Notes: be longer than 15 characters:  Valid ‐ BlackPearl.domain.com  Invalid ‐ BlackPearlSystem.domain.com  If your system is using firmware BlackPearl 3.2.2, or earlier,  there are no character restrictions on system names.  However, Spectra Logic recommends limiting system names  to letters, numbers, and hyphens to maintain compatibility  with the RFC 1123 standard.  The system does not change previously configured system  names using special characters when upgrading to  BlackPearl 3.3, or later. 4. Click Save. ONFIGURE ETWORKING ERVICES Use the following instructions to configure networking services on the  BlackPearl NAS solution. For instructions on configuring NAS services, see Configure Network  Connections and Settings on page 102. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 113: Configure The Active Directory Service

    Join Domain 1. From the menu bar, select Configuration > Services. The Services  screen displays. Figure 81 The Services screen. 2. Double‐click the Active Directory row, or select the Active Directory row  and select Action > Show Details. The Active Directory details screen  displays. 3. On the Active Directory service details screen, select Action > Join Domain. The Join Domain dialog box displays. Figure 82 The Join Domain dialog box. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 114  You must enter the user name and password each time the  BlackPearl NAS solution joins an Active Directory domain.  The system does not save this information. 8. If desired, select Allow Trusted Domains if the Active Directory domain  you want to join is a trusted domain. 9. Click Join Domain. Edit Domain If desired, you can edit your Active Directory configuration to enable or  disable support for trusted domains. 1. From the menu bar, select Configuration > Services. The Services  screen displays (see Figure 81 on page 113). 2. Double‐click the Active Directory row, or select the Active Directory row  and select Action > Show Details. The Active Directory service details  screen displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 115 Advanced parameters should not be configured without a full understanding of the consequences. 1. From the menu bar, select Configuration > Services. The Services  screen displays (see Figure 81 on page 113). 2. Double‐click the Active Directory row, or select the Active Directory row  and select Action > Show Details. The Active Directory service details  screen displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 116 Advanced parameters should not be configured without a full understanding of the consequences. 1. From the menu bar, select Configuration > Services. The Services  screen displays (see Figure 81 on page 113). 2. Double‐click the Active Directory row, or select the Active Directory row  and select Action > Show Details. The Active Directory service details  screen displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 117 Action > Delete Advanced Parameter. The Edit Advanced Parameter  confirmation window displays. 4. Click Delete. Leave Domain 1. From the menu bar, select Configuration > Services. The Services  screen displays (see Figure 81 on page 113). 2. Double‐click the Active Directory row, or select the Active Directory row  and select Action > Show Details. The Active Directory service details  screen displays. 3. Select Action > Leave Domain. A confirmation window displays. 4. Click Leave Domain.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 118: Configure The Snmp Service

    SNMP Service dialog box displays. Figure 86 The Edit SNMP Service dialog box. 4. If desired, change the value of the Community String. Any incoming  SNMP queries that use a different community string than the one set  here fail. If no community string is specified, then the BlackPearl NAS  solution responds to all SNMP queries. 5. Enter the primary contact for the BlackPearl NAS solution in the  Contact field. 6. Enter the physical location of the system in the Location field. 7. If desired, add clients that are allowed to access the system using  SNMP. Figure 87 The Edit SNMP Service dialog box. a. Click the + sign to add a client.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 119: October

    If you want to communicate with the system using SNMP, you must first  download the BlackPearl NAS solution MIB (Management Information  Base) file, and load the file into compatible network node manager  ® ® programs, such as HP  OpenView 1. Select Configuration > Services to display the Services screen (see  Figure 81 on page 113). 2. Double‐click the SNMP service row, or select the SNMP service row  and select Action > Show Details. The SNMP service details screen  displays. 3. Click Download MIB. Using your web browser, save the file to your local  host. Figure 88 Download the MIB file. 4. Load the file into the network node manager program. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 120: Configure And Use Encryption

    If your BlackPearl NAS solution includes Self Encrypting Drives (SEDs),  use the encryption service to set the level of encryption, configure  passwords, and unlock the drives so that they are usable for data transfer. Configure the Encryption Service Use the encryption service to set the level of encryption and create a  password to unlock the drives following a system power cycle. You can  select to store the password on the system, so that the drives are unlocked  automatically, or to save the password to a USB key that is used when  needed to unlock the drives, and is otherwise stored in a safe location. 1. From the menu bar, select Configuration > Services to display the  Services screen (see Figure 81 on page 113). 2. Double‐click the Encryption service, or select the service, and then  select Action > Show Details. The details screen for the Encryption  service displays. Figure 89 The Encryption service details screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 121 Encrypt and Store The self‐encrypting drives encrypt data transferred to them, and the password  Password to unlock the drives is stored on the NAS solution. The drives are automatically  unlocked when the BlackPearl NAS solution initializes. Encrypt and Don’t The self‐encrypting drives encrypt data transferred to them, but the system  Store Password does not store the password to unlock the drives. You must manually enter the  password each time the BlackPearl NAS solution initializes. This setting also allows you to create a USB device with the encryption  password. You can use the USB device when the system initializes to unlock the  drives. Store the USB device in a safe location, not attached to the BlackPearl  NAS solution, at all other times. 5. Enter a Password to unlock the self‐encrypting drives, and then Confirm  the password. 6. Enter the User Password of the user currently logged in to the  BlackPearl user interface. 7. Enter ENCRYPT into the confirmation dialog box. 8. Click Save. You may need to navigate away from the encryption details  Note: screen and then back for the system to view updated  information on the details screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 122: Change The Encryption Password

    4. Enter the (current) Old Password. 5. Enter the desired New Password, and then Confirm the new password. 6. Enter the User Password of the user currently logged in to the  BlackPearl user interface. 7. Click Save. Unlock the Self-Encrypting Drives If the encryption service is configured to not store the password on the  NAS solution, use the instructions below to manually unlock the self‐ encrypting drives after the system initializes. 1. From the menu bar, select Configuration > Services to display the  Services screen (see Figure 81 on page 113). 2. Double‐click the Encryption service, or select the service, and then  select Action > Show Details. The details screen for the Encryption  service displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 123: Create An Encryption Password Usb Key

    4. Enter the encryption Password. 5. Enter the User Password of the user currently logged in to the  BlackPearl user interface. 6. Click Save. Create an Encryption Password USB Key If the encryption service is configured to not store the password on the  system, use the instructions below to create a USB key to store the  encryption password that unlocks the self‐encrypting drives after the  system initializes. Insert the USB key when the system initializes to unlock  the drives, and remove it from the system USB port and store it in a safe  location at all other times. 1. From the menu bar, select Configuration > Services to display the  Services screen. 2. Double‐click the Encryption service, or select the service, and then  select Action > Show Details. The details screen for the Encryption  service displays. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 124: Psid Erase An Encryption Drive

    Performing a PSID Erase on a drive permanently erases all data on the drive. Caution Use the instructions in this section to perform a PSID erase on the drive. 1. From the menu bar, select Status > Hardware or click the Hardware  pane on the Dashboard, or click the Hardware link on the status bar.  The Hardware screen displays (see Figure 104 on page 138). 2. Click Data Drives. The hardware screen refreshes and displays all disk  drives present in the system.  3. Record the slot number and serial number for each drive you want to  PSID erase. Power down the system as described in Reboot or Shut down a  BlackPearl NAS Solution on page 146. 5. Locate the drive(s) in the chassis using the slot number and verify the  serial number(s) you recorded in Step October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 125 Figure 94 The PSID Erase dialog box. Enter the PSID value you recorded in Step 6 in the PSID entry field. 14. Type ERASE ALL DATA in the confirmation entry field. Performing a PSID Erase on a drive permanently erases all data on the drive. Caution 15. Click Erase. Repeat Step 12 through Step 15 for any additional drives you want to  erase. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 126: Configure Users

    52 for information about each user  type. Create a User To create a user, see Create a User on page Edit a User 1. From the menu bar, select Configuration > Users. The Users screen  displays a list of all configured users (see Figure 23 on page 53). 2. Double‐click the name of the user you want to edit, or select the user  and then select Action > Edit. The Edit Users dialog box displays. Figure 95 The Edit User dialog box. 3. The Username is unavailable and cannot be changed. 4. If desired, edit the user’s Full Name. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 127: Delete A User

    1. From the menu bar, select Configuration > Users. The Users screen  displays a list of all configured users (see Figure 23 on page 53). 2. Select the user you want to delete, and then select Action > Delete. A  confirmation window displays. 3. Click Delete to delete the user. ONFIGURE ERTIFICATES The BlackPearl NAS solution ships with a non‐signed SSL certificate for the  management port on the system. Because the certificate is not signed, you  must pass a security check every time you attempt to access the  management port to view the BlackPearl user interface. If desired, you can install a signed, trusted SSL certificate for the  management port so that you no longer need to pass the security check  when accessing this port. The BlackPearl NAS solution accepts intermediate (chain) SSL certificates,  and accepts RSA, DSA, and ECC certificates. Use the instructions in this section to install an SSL certificate. 1. From the menu bar, select Configuration > Certificates. The Certificates  screen displays. Figure 96 The Certificates screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 128: Manually Enter Activation Keys

    2. Select the Management row, and then select Action > Import Certificate.  The Import Certificate dialog box displays. Figure 97 The Import Certificate dialog box. 3. From your source SSL certificate file, copy the certificate portion of the  file into your host’s cache, and then paste the contents into the  Certificate entry box. The certificate must be in PEM format. Note: 4. From your source SSL certificate file, copy the private key portion of the  file into your host’s cache, and then paste the contents into the Private Key entry box. The private key must be in PEM format. Note: 5. Click Save. ANUALLY NTER CTIVATION If this is an initial installation and your BlackPearl documentation kit  included a USB device, see Automatically Import Activation Keys on  page 43 for instructions for importing activation keys. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 129 Capacity keys ‐ There are three types of capacity keys. Key Type Description EM_S3_SAS_COUNT Enables the specified number of SAS drives  present in the BlackPearl master node, BlackPearl  expansion node, or 107‐drive disk solution. EM_S3_SATA_COUNT Enables the specified number of SATA drives  present in the ArcticBlue or 107‐drive disk  solutions. EM_S3_SSD_COUNT Enables the specified number of SSD drives  present in the BlackPearl 4U master node or  107‐drive disk solution. b. All other keys ‐ Any additional keys included on the Software  Activation Key Certificate, such as the Software Update key, can be  entered in any order. 2. Select Support > Activation Keys to display the Activation Keys screen.  Any previously entered keys are listed Figure 98 The Activation Keys screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 130 Manually Enter Activation Keys 3. Select Action > New. The Enter Activation Key dialog box displays. Figure 99 The Enter Activation Key dialog box. 4. Enter the key, exactly as provided, in the Activation Key field and click  Create to save the key on the system. The Activation Keys screen  displays with the newly entered key listed. If necessary, repeat Step 3 and Step 4 to enter any additional keys. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 131: Chapter 6 - Monitoring A Blackpearl Nas Solution

    HAPTER Monitoring a BlackPearl NAS Solution This chapter describes procedures for day‐to‐day monitoring and  operation of a Spectra BlackPearl NAS solution. Topic Monitor the BlackPearl NAS Solution page 132 Front Bezel Visual Status Beacon page 133 Configure the Visual Status Beacon Color page 134 System Status LEDs page 135 View System Messages page 136 View the Status of Hardware Components page 137 View the Status of Pools page 139 View the Status of Volumes page 141 View the Status of Shares page 141 View the Status of Services page 142 View Performance Metrics page 143 View Reports...
  • Page 132: Monitor The Blackpearl Nas Solution

    136  for more information).  Icons on the System screen provide overall status of the hardware  components in each group (see View the Status of Hardware  Components on page 137 for more information). Clicking the text next to each icon displays detailed status information  for the components in the group.  The system status LEDs provide information about the status of the  NAS solution, its fans, network connections, and power supplies (see  System Status LEDs on page 135 for more information).   You can also use the BlackPearl user interface to do the following on the  BlackPearl NAS solution:  View the status of services (see View the Status of Services on  page 142).   View performance metrics for the drives, CPUs, storage pools, and  network (see View Performance Metrics on page 143).  View the current network configuration settings (see Configure  Network Connections and Settings on page 102).  Reboot or shut down the system (see Reboot or Shut down a  BlackPearl NAS Solution on page 146). October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 133: Front Bezel Visual Status Beacon

    The system is experiencing a Warning condition. Log in  Yellow Scroll to the BlackPearl user interface to determine the cause of  the warning. The system is experiencing an Error condition. Log in to  Red Scroll the BlackPearl user interface to determine the cause of  the error. The system is currently powering on and performing  Rainbow self‐tests. The beacon feature was activated for this system. This  Flashing Blue can help you identify a specific system when you have  more than one BlackPearl NAS solution in your  environment. See View the Status of Hardware  Components on page 137 for instructions on activating  the beacon. The Visual Status Beacon lost communication with the  Pulsing Red system. This can occur if the system experiences a  software hang. The BlackPearl NAS solution is powered off. No Light Note: Other patterns may display if the front bezel is not properly  seated on the system. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 134: Configure The Visual Status Beacon Color

    Figure 100 Use the color picker to set the color displayed on the Visual Status Beacon when the system is operating normally. 4. Use the color picker to select the color to display when the system is  operating normally. Optionally, you can enter an HTML color code in  the entry field. Spectra Logic recommends against using yellow or red, so that  Note: you can more easily determine if the system is in a warning or  error state. 5. Click Choose to set the color of the Visual Status Beacon. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 135: System Status Leds

    Figure 101 System status LEDs. Function Power Indicates if the unit is powered on. Hard Drive Indicates boot drive activity. To see the activity of a data drive, see Data  drive status LEDs on page Network 1 Indicates network activity on the BlackPearl management port. Network 2 Indicates network activity on data interface 1. This LED also shows  network activity if data interface 1 is configured in link aggregation  mode.  If the LED is blinking red, it indicates a fan failure. Log into the  Fan Failure / Overheat BlackPearl user interface to determine which fan failed.  If the LED is solid red, it indicates an overheat condition. Log into the  BlackPearl user interface to view the status of the system. If the  problem persists, contact Spectra Logic Technical Support. See  Contacting Spectra Logic on page Power Failure Indicates a power supply failure. Log into the BlackPearl user interface  to determine which power supply failed. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 136: View System Messages

    Description Notifies the user about an event that requires no action and  Information does not fit the other categories. Notifies the user of successful completion of an event. Success Alert Notifies the user that a failure occurred which requires some  sort of user interaction, and until this occurs, operation of the  BlackPearl NAS solution may be impacted. Notifies the user of a failure that may adversely impact the  Warning operation of the BlackPearl NAS solution. Critical Notifies the user of a failure that caused significant adverse  impact to the BlackPearl NAS solution. The status bar displayed at the bottom of all BlackPearl user interface  screens shows the highest severity and generation date and time for all  unread messages. If there are no system messages, this text does not  display. Figure 102 A system message displayed on the BlackPearl user interface status bar. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 137: View The Status Of Hardware Components

    You cannot delete messages. The BlackPearl NAS solution  automatically deletes the oldest messages on a first‐in, first‐out  basis as space is required, retaining the most recent messages.  The system holds 10,000 messages. 2. If desired, use the Page Length drop‐down menu to limit the Messages  screen to the specified number of messages. 3. To mark a single message as read, select the message and then select  Action > Mark as read. To mark all messages as read, select Action >  Mark all as read. Note: Messages can also be marked as Unread using the Action menu. View the Status of Hardware Components The BlackPearl user interface lets you monitor the status of hardware  components without having direct physical access to the BlackPearl NAS  solution. This is especially useful when your NAS solution is operating in a  “lights out” data center. Check the BlackPearl user interface regularly to  ensure that you always know the status of the hardware components. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 138  Status of each drive  Drive size, serial number, and firmware level  The name of the storage pool to which the drive is assigned  Status of midplane fans Fans  Power supply status and wattage Power Supplies  CPU status and temperature System  System memory status and size  Status, manufacturer, model, size, and serial number for each  boot drive Turn Beacon On Click Turn Beacon On to cause the Visual Status Beacon light on a  (below chassis BlackPearl NAS solution to flash blue. This is useful when you  graphic) have multiple systems and need to locate a specific one, for  example to replace a component. Click the button a second time  to stop the light from flashing. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 139: View The Status Of Pools

    2. The status of each storage pool is indicated by the status icons on the  left side of the screen. Figure 105 The Pools screen. The Pools screen displays the following information.  This column... Shows... Name The name of each NAS pool.  The current health of each pool. Health  Online—The cache is operating normally.  Degraded—One or more drives in the cache is  missing, or failed. Raw Size The total amount of storage space assigned to each pool. Available The amount of unused storage space in each pool. Used The amount of used storage space in each pool. Overhead The amount of disk space used for overhead, such as  parity data. Fault Tolerance The fault tolerance setting for each pool. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 140 High Water Mark When the used space on the pool reaches this  percentage, an alert is generated. No alert is generated  when the percentage is set to zero. Power Saving Mode Indicates if power saving mode is enabled or disabled. Data Configuration The protection level for the pool. Fault Tolerance The number of drives that can fail before data is lost. Raw Size The total amount of storage space assigned to the pool. Available The amount of available (unused) storage space in the  pool. Used The amount of used storage space in the pool. Overhead The amount of disk space used for overhead, such as  parity data. Drives The size, RPM, type, and number of drives assigned to  the pool. Write Performance The number of write performance drives assigned to the  pool. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 141: View The Status Of Volumes

    Figure 107 The Volumes screen. View the Status of Shares The Shares screen provides status information about all shares that are  configured on the system. 1. From the menu bar, select Configuration > NAS > Shares > CIFS to  display the CIFS Shares screen, or select Configuration > NAS > Shares > NFS to display the NFS Shares screen. 2. The status of each share is indicated by the status icons on the left side  of the screen. Figure 108 The CIFS Shares screen. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 142: View The Status Of Services

    View the Status of Services The Services screen provides status information about services that are  currently installed on the BlackPearl NAS solution. From the menu bar, select Configuration > Services to display the Services  screen. Figure 109 The Services screen. This column... Shows... Name The name of the service running on the system. State The status of the service on the BlackPearl NAS solution.  Starting—The service is starting up.  Operational—The service is running.  Stopped—The service is not running. Enabled Whether or not the service is enabled at system startup.   Yes—Service automatically starts when the system  is powered on.   No—Service does not start when the system is  powered on. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 143: View Performance Metrics

    1. From the menu bar, select Status > Performance or click the  Performance pane on the Dashboard. The Performance screen displays.  Figure 110 The Performance screen. 2. Select Pools, Drives, CPUs, or Network to display performance  information about the selected component. Note: If you select Pools, Drives, or Network, use the Pool, Disk, or  Interface drop‐down menu to select a specific storage pool, disk  drive, or network connection to display. 3. Select the time interval using the Resolution drop‐down menu. The data  can be displayed in 5 second increments (5 minutes total) or 60 second  increments (25 hours total). 4. Select or clear options under Select elements to plot to indicate which  graph lines to display. The graph updates as soon as you select or clear  an option. 5. Set the performance graph’s time values to your local time zone using  the Time zone menu. All entries are listed in +/‐ GMT. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 144 The range indicator graph continues to display the original range of  data, with the section that is currently being shown on the main graph  highlighted. Main graph Range indicator graph Highlighted section currently displayed on main graph Figure 111 Highlight a section of data to show in greater detail. 8. Click Reset View to reset the main graph to the default view. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 145: View Reports

    Monitor the BlackPearl NAS Solution View Reports The Reports screen lets you generate reports on all aspects of the  BlackPearl NAS solution, including component status and configuration.  Reports can be saved in either JSON or XML format. 1. From the menu bar, select Status > Reports to display the Reports  screen. Figure 112 The Reports screen. 2. Select check boxes next to the report(s) you want to generate.  Note: You can use the All or None buttons at the bottom of each report  group to select or clear that group of reports. The All and None  buttons at the bottom of the screen select or clear all reports  shown on the screen. 3. Select the Format for the report(s). Only one format can be selected. 4. Click Save. The system saves the selected reports to your local host. 5. Open a report using a compatible program. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 146: Reboot Or Shut Down A Blackpearl Nas Solution

    NAS S EBOOT OR HUT DOWN A LACK EARL OLUTION This section discusses rebooting or shutting down a NAS solution. Using the BlackPearl User Interface Use the following instructions to reboot or shut down a system using the  BlackPearl user interface.  1. Click the power icon in the lower right‐hand corner of any screen in the  BlackPearl user interface. The Power screen displays.  Power icon Figure 113 The Power icon. 2. Click either Reboot or Shutdown.  3. A confirmation screen displays. Confirm the selection to perform the  reboot or shutdown.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 147: Power-Cycle Reset

    (Figure 101 on page 135) until the button’s LED turns off. After a few  moments, press the button again to turn the system back on. Do not use the power button to turn off a BlackPearl NAS solution unless you are Caution specifically instructed to do so by Spectra Logic Technical Support. XIT THE LACK EARL NTERFACE To exit the BlackPearl user interface, close the browser or click Logout on  the right side of the menu bar. This ends the session.
  • Page 148: Chapter 7 - Using Autosupport

    HAPTER Using AutoSupport This chapter describes using the BlackPearl user interface to configure the  support features of the BlackPearl NAS solution.  Task About AutoSupport page 149 Enter Contact Information page 149 Configure Mail Recipients page 150 Create a New Recipient page 150 Edit a Mail Recipient page 151 Send a Test Email page 152 Delete a Mail Recipient page 153 Log Sets page 153 Configure a Log Set Schedule page 154 Manually Generate Log Sets page 155 Email a Log Set page 155 Download a Log Set page 156 Delete a Log Set page 156...
  • Page 149: About Auto Support

    UPPORT AutoSupport lets the BlackPearl NAS solution master node automatically  contact mail recipients when the system generates certain kinds of  messages. You can also use it to generate AutoSupport Log (ASL) sets for  use by Spectra Logic Technical Support. The system can email ASL sets to  Spectra Logic or mail recipients when critical events occur, or on a monthly  basis. NTER ONTACT NFORMATION Contact information helps Spectra Logic to contact the administrator of the  BlackPearl NAS solution during troubleshooting. Entering the contact  information is typically a one‐time‐only process.  1. From the menu bar, select Support > Contact Information to display the  Contact Information screen.  2. Click New in the Customer Contact Information pane. The New Contact  Information dialog box displays.  Figure 114 The New Contact Information dialog box. 3. Enter the requested information and click Create. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 150: Configure Mail Recipients

    You can configure AutoSupport to email system messages and log sets as  they are generated, to selected recipients. All log sets and messages are  sent to a previously configured mail recipient. You cannot send log sets or  messages directly to an email address. Use the Mail Recipients screen to  add, edit, or delete mail recipient accounts.  Figure 115 The Mail Recipients screen. Create a New Recipient Use these instructions to add a new mail recipient. 1. From the menu bar, select Configuration > Mail Recipients. The Mail  Recipients screen displays. 2. Select Action > New. The New Mail Recipient dialog box displays. Figure 116 The New Mail Recipient dialog box. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 151: Edit A Mail Recipient

    Message Severity on page 136. Note: For the mail recipient to receive all messages generated by the system,  select all boxes. 4. Click Create to save the information. The Mail Recipients screen re‐ displays with the new mail recipient added to the list of mail recipients.  Repeat Step 1 on page 150 through Step 4 to configure additional mail  recipients. Edit a Mail Recipient Use the following steps to edit a mail recipient. 1. From the menu bar, select Configuration > Mail Recipients. The Mail  Recipients screen displays with any already configured mail recipients  listed. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 152: Send A Test Email

    3. Change the information for the recipient as required and then click  Save. See Create a New Recipient on page 150 for a explanation of the  options. Send a Test Email Use the following steps to send a test email to a mail recipient. 1. From the menu bar, select Configuration > Mail Recipients. The Mail  Recipients screen displays with any already configured mail recipients  listed. 2. From the list of mail recipients, select the name of the recipient you  want to send a test email, and then select Action > Send test email.  Figure 118 The Mail Recipients screen. The BlackPearl NAS solution master node immediately sends a test  email to the selected account. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 153: Delete A Mail Recipient

    2. From the list of mail recipients, select the name of the recipient you  want to delete, and then select Action > Delete. A dialog box displays  asking you to confirm the deletion of the mail recipient. Note: The default Spectra mail recipient cannot be deleted. Figure 119 Delete the selected mail recipient. 3. Click Delete to confirm the deletion. The BlackPearl NAS solution automatically generates log sets when errors  occur. Log sets can also be generated manually, or generated on a schedule.  The BlackPearl NAS solution generates three types of log sets:   Log Sets contain information about the configuration and status of  the BlackPearl NAS solution and are used for general  troubleshooting. Log sets can be mailed to configured mail  recipients or to Spectra Logic Technical Support.  Statistic Log Sets contain performance data about the system and  are used by Spectra Logic Technical Support for in‐depth  troubleshooting. Statistic log sets are too large to mail directly from  the system and must be downloaded.  Kernel Log Sets are generated whenever a process on the system  fails. This log set cannot be generated manually. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 154: Configure A Log Set Schedule

    1. From the menu bar, select Support > Logs. The Logs screen displays. 2. Select Action > New Log Set Schedule. The New Log Set Schedule  dialog box displays. Figure 121 The New Log Set Schedule dialog box. 3. Enter a time value for Start Time, and include AM or PM after the value.  This field is not case sensitive. 4. Select one or more days for Every week on:. This determines the day(s)  of the week the system generates log sets. 5. Click Create. The Logs screen displays showing the newly created Log  Set Schedule. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 155: Manually Generate Log Sets

    Note: You must configure the SMTP settings on the system before you  can send emails. See Configure SMTP Settings on page 109 to  configure the SMTP settings. 1. From the menu bar, select Support > Logs. The Logs screen displays  (see Figure 120 on page 154). 2. Select the log set you want to email, and then select Action > Email.  The Email Log Set dialog box displays. Note: Statistic Log Sets are too large to email from the system, and  must be downloaded. See Download a Log Set on page 156. Figure 122 The Email Log Set dialog box. 3. Select the mail recipients you want to receive the log set, and click  Email. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 156: Download A Log Set

    2. Select the log set you want to delete, and select Action > Delete. A  confirmation window displays asking you to confirm the action. 3. Click Delete to delete the log set. 4. Optionally, use one of the following commands to delete log sets in  bulk: Command Description Action > Delete All Log Sets Deletes all log sets present on the system. Action > Delete All Statistic Log Sets Deletes all statistic log sets on the system. Action > Delete All Kernel Logs Deletes all kernel log sets on the system. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 157: Chapter 8 - Maintaining A Blackpearl Nas Solution

    HAPTER Maintaining a BlackPearl NAS Solution This chapter describes the maintenance procedures for a BlackPearl NAS  solution.  Task Data Integrity Verification page 158 Cancel Data Integrity Verification page 158 Initiate an RSC Backup page 159 Accessing the Technical Support Portal page 159 Create an Account page 159 Log Into the Portal page 161 Configuring Automated Software Upload page 162 Updating Software page 163 Check the Current Software Version page 163 Check the Currently Released BlackPearl Software  page 164 Version Download and Stage the Updated Software page 165 Install the Update...
  • Page 158: Data Integrity Verification

    2. Select the disk pool for which you want to start the data integrity  verification, and select Action > Start. A confirmation screen displays.  Note: While the verification is in progress, the disk pool may  experience degraded performance. However, client access and  rebuilds have priority over data integrity verification. 3. Click Start Data Verification to start the scan. Cancel Data Integrity Verification If desired, you can stop a data integrity verification while it is in progress.  1. From the menu bar, select Support > Tools > Data Integrity Verification. The Data Integrity Verification screen displays. 2. Select the pool for which you want to stop verification in the Data  Integrity Verification screen, and then select Action > Cancel. 3. A confirmation screen displays. Click OK to stop the verification. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 159: Initiate An Rsc Backup

    2. Select Action > Initiate RSC Backup. A confirmation screen displays. 3. Click Initiate RSC Backup to manually save the current system  configuration. CCESSING THE ECHNICAL UPPORT ORTAL The Spectra Logic Technical Support portal provides access to the  Knowledge Base, the current version of BlackPearl software for the NAS  solution, and additional service and support tools. You can also open or  update a support incident and upload log files. Create an Account Access to User Guides and compatibility matrices does not require you to  create an account. You must create a user account and log in to access  Release Notes or repair documents, to download the latest version of  BlackPearl software, or to open a support incident. Note: If you have multiple Spectra Logic products, the serial numbers  for all products are associated with your account. If you do not  see the serial numbers for all of your products when you log in,  contact Technical Support (see Contacting Spectra Logic on  page 1. Access the Technical Support portal login page at  support.spectralogic.com. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 160 Accessing the Technical Support Portal 2. On the home page, click create an account.  Figure 124 The Spectra Logic Technical Support portal home page. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 161: Log Into The Portal

     If you have an invitation, follow the link and enter the invitation  code. Figure 125 Follow the link to enter your invitation code or enter your registration information.  If you do not have an invitation, enter the requested information to  create your account. When you are finished, click Sign Up. When the account is approved, you receive an email with a link to setup  your initial password. Use your email address and the password provided  in the email to log in to your account. After you log in, you can change  your password if desired. Log Into the Portal Access the Technical Support login page at support.spectralogic.com. Use  your email address and password to log into the Technical Support Portal. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 162: Configuring Automated Software Upload

    4. Use the drop‐down menu to select the Check for updates frequency. 5. Optionally, select the Email Notifications Only check box to only receive  an email when an updated software package is available instead of  automatically downloading the file. 6. Select either Spectra Logic or Use Proxy as the Upload From location. Important Spectra Logic recommends using the Spectra Logic package server. If you select Use Proxy, enter the following information:  Proxy IP Address—Enter a valid IPv4 address.   Proxy Port—Enter the port used to access the proxy server. 7. Click Save. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 163: Updating Software

     If you were notified that an update is required, but the update did  not download automatically, skip to Download and Stage the  Updated Software on page 165.  If you do not know if the system needs an update installed, continue  with Check the Current Software Version, below. Check the Current Software Version Use the following steps to determine the current software version running  on your BlackPearl NAS solution master node.  1. From the menu bar, select Support > Software. The Software screen  displays. 2. The current software version is listed next to Current Version in the  Software Update pane. Figure 127 The current BlackPearl user interface software version. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 164: Check The Currently Released Blackpearl Software Version

    Check the Currently Released BlackPearl Software Version Follow these steps to check the currently recommended BlackPearl  software version: 1. Log into your user account on the Technical Support portal at  https://support.spectralogic.com. Note: See Create an Account on page 159 for information about  creating an account and accessing the Technical Support portal. 2. Select Downloads > Product Software.  3. On the Product Software page, locate the BlackPearl row in the Spectra  Product column. The currently released BlackPearl version is listed in  the Current Version column. Figure 128 The Product Software screen. 4. Compare the Current Version available for the BlackPearl NAS solution  to the version installed on the system. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 165: Download And Stage The Updated Software

    Updating Software Download and Stage the Updated Software Use the instructions in this section to download and install the updated  software for the BlackPearl NAS solution. 1. Log into your account on the Technical Support portal at  https://support.spectralogic.com. 2. Select Downloads > Product Software. The Product Software Screen  displays.  Figure 129 The Product Software screen. 3. Locate the BlackPearl row in the Spectra Product column. The currently  released BlackPearl software version is listed in the Current Version  column. 4. Click the name of the BlackPearl package. The package begins  downloading through your web browser. Do not unzip the  downloaded file.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 166: Install The Update

    2. From the menu bar, select Support > Software to display the Software  screen. The Software screen displays with the software upload file  staged to the system. Figure 131 The Software Update screen with a software package staged to the system. 3. Click Update. A progress bar shows the progress of the update.  Figure 132 The Software Update screen showing the progress of an update. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 167: Installing A New Data Drive

     Leave the drive in its anti-static bag until you are ready to install it.  Do not place the un-bagged drive on any metal surfaces. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 168: Install The Drive

    Remove the Empty Drive Sled Use the following steps to remove an empty drive sled. 1. Put on an anti‐static wristband and attach it to the anti‐static mat or an  unpainted metallic surface. Continue to wear the wristband throughout  the entire replacement procedure. 2. Locate the empty drive bays where you want to install a new drive.  Note: If your system includes an active bezel, do not install a drive in  slot 1, which is the top left drive in the front of the system. This  slot is reserved for the Visual Status Beacon control sled. The  images below show a normal drive sled in slot 1 for clarity. 3. Slide the drive sled locking tab to the right to release the drive sled  handle. Handle Figure 133 Slide the tab to the right to release the drive sled handle. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 169 Figure 134 Pull the sled out of the system. 5. Dispose of the empty sled in accordance with your company’s  guidelines. Install the New Drive 1. New drives are shipped installed in a drive sled. Slide the locking tab  on the front of the drive sled to the right to release the handle.  2. With the drive handle in the open position, slide the drive sled into the  chassis until the front of the drive sled is flush against the chassis. The  drive sled slides in easily; do not force it. Figure 135 Install the drive into the BlackPearl NAS solution system. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 170: Replacing A Failed Component

    3. When the drive sled is in position, push the handle inward and to the  right until the locking tab secures it in place. An audible click indicates  that the drive sled is locked into position. 4. If necessary, reinstall the front bezel. EPLACING A AILED OMPONENT If a component in a BlackPearl NAS solution is not functioning properly,  the system generates a message and the hardware icon on the status bar of  the BlackPearl user interface changes to an error icon (see Status Icons on  page 37).  Identify the Failed Component 1. From the menu bar, select Status > Hardware. The Hardware screen  displays. The malfunctioning component is indicated by an error icon.   Figure 136 The Hardware screen showing a failed component. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 171 Replacing a Failed Component 2. If you have multiple BlackPearl NAS solutions, you can use the beacon  feature to help locate which system has the failed component. On the  Hardware screen, click the system name. The screen refreshes to show  the main Hardware screen Note: The front bezels in some BlackPearl NAS solution master nodes  do not include a Visual Status Beacon light bar. However, when  the beacon feature is activated, the drive lights blink blue,  making it easier to locate the system with a failed component. Figure 137 The Hardware screen. 3. Click Turn Beacon On. The BlackPearl NAS solution Visual Status  Beacon light bar flashes blue, making it easy to find. After you locate the unit in your data center, click Turn Beacon Note: Off to stop the lights from flashing. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 172  The Spectra 12‐ & 36‐Drive Chassis Boot Drive Replacement Guide provides  instructions for replacing a failed boot drive in the system.  The Spectra 12‐, 36‐ & 45‐Drive Chassis Drive Replacement Guide provides  instructions for replacing a failed data drive after the system is  installed.  The Spectra 12‐, 36‐ & 45‐Drive Chassis Fan Replacement Guide provides  instructions for replacing a failed fan in the system.  The Spectra 12‐, 36‐ & 45‐Drive Chassis Power Supply Replacement Guide  provides instructions for replacing a failed power supply after the  system is installed.  The Spectra 12‐Drive Chassis HBA Replacement Guide and Spectra 36‐Drive  Chassis HBA Replacement Guide provide instructions for replacing a  failed HBA in the system.  The Spectra 96‐Drive Chassis Drive Replacement Guide provides  instructions for replacing a failed data drive in the BlackPearl archive  expansion node.  The Spectra 96‐Drive Chassis Fan Replacement Guide provides instructions  for replacing a failed fan in the BlackPearl archive expansion node.  The Spectra 96‐Drive Chassis Power Supply Replacement Guide provides  instructions for replacing a failed power supply in the BlackPearl  archive expansion node.  The Spectra 96‐Drive Chassis I/O Module Replacement Guide provides  instructions for replacing a failed I/O module in the BlackPearl archive  expansion node. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 173: Chapter 9 - Troubleshooting And Support

    HAPTER Troubleshooting and Support Use the information in this chapter to troubleshoot problems as they arise,  before contacting Spectra Logic Technical Support. Task Resolving a Management Port IP Address Conflict page 174 Using the Console page 174 Using a Separate Computer page 174 Network Setup Tips page 176 Configuration page 176 Connectivity to the Network page 177 Troubleshooting page 179 Tools page 180 Spectra Logic Technical Support page 181 Before Contacting Support page 181 Open a Support Ticket page 182 Remote Support...
  • Page 174: Resolving A Management Port Ip Address Conflict

    Using the Console Using the BlackPearl NAS solution master node console is the  recommended way to change the BlackPearl management port IP address.  For instructions on using the console to configure the management port IP  address, see Configure the BlackPearl Management Port on page Using a Separate Computer If you cannot use the console, use a computer or laptop disconnected from  any existing network, to change the BlackPearl management port IP  address. 1. Gather a laptop or desktop computer not currently on any network.  Disable any wireless networking, if necessary. 2. Using a standard Ethernet cable, connect the Ethernet port on the  computer to the BlackPearl management port on the BlackPearl NAS  solution master node. See Rear Panel on page 29 to locate the  management port. 3. Open a web browser on the computer. For a list of compatible  browsers, see Supported Browsers on page 4. Enter the IP address below in the browser address bar: https://10.0.0.2  The netmask for the default IP address is 255.255.255.0. Notes:  The BlackPearl user interface uses a secure connection. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 175 BlackPearl user interface. Contact your system administrator to determine the DHCP address for the management port. 10. To configure a static IP address, click the + button and enter the  following information:  IP Address—Enter a valid IPv4 or IPv6 address.  Note: You cannot enter an IPv4 address if you selected DHCP in  Step  Prefix Length—Enter the subnet mask. Note: If desired, you can enter Aliases, multiple IP and prefix lengths  assigned to the data port. Use the + button to configure  additional IP and Netmask addresses. You can configure a  maximum of 16 aliases. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 176: Network Setup Tips

    When you change the IP address of the BlackPearl management  port, you lose your connection to the user interface when you  save your changes. To re‐establish the connection, enter the new  IP address in your browser and log in again. 15. Disconnect the Ethernet cable from the BlackPearl management port. 16. Connect a cable from your network to the management port on the  BlackPearl NAS solution master node. You are now able to connect to  the system with the IP address configured in Step 9 on page 175. ETWORK ETUP The BlackPearl management port is separated from the data ports. The  management port and data ports have their own default routes. This does  not prevent a user from having the management and data ports utilizing  the same network, if desired. The basic steps for configuring the management and data ports for access  to the network are simple and straight‐forward. However, each network  environment is unique and may require some additional troubleshooting  in order to properly connect to the BlackPearl NAS solution and utilize the  10GBase‐T, 10 GigE, or 40 GigE interfaces correctly. Configuration The first step is to configure the management and data ports using the  BlackPearl user interface (see Configure Network Connections and  Settings on page 102), or the command line interface (see the Spectra Verde  Command Line Interface Guide). Do not attempt to access the system directly  using the root console to modify interfaces. The user interface and  command line interface are tightly integrated with the base operating  system and configure additional features based on network changes. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 177: Connectivity To The Network

     For the 40 GigE optical card:  Single 40 GigE logical connection using one of the 40 GigE physical  ports —OR—   Single 80 GigE logical connection using two 40 GigE physical ports  (link aggregation)  For the 10GBase‐T card:  Single 20 gigabit logical connection using two 10GBase‐T physical  ports (link aggregation) —OR—   Single 30 gigabit logical connection using three 10GBase‐T physical  ports (the two ports on the card and the one spare onboard port)  (link aggregation) Not Recommended:  Single gigabit logical connection utilizing one of the 10GBase‐T  physical ports and a Category 5e Ethernet cable —OR—   Single 10 gigabit logical connection utilizing one of the 10GBase‐T  physical ports and a Category 6 Ethernet cable Assign the appropriate IP address to the management and data ports  either statically or using DHCP. If you are setting the MTU to something  other than 1500, ensure that your switch configuration, as well as all the  hosts on the network, support larger MTU settings. The BlackPearl NAS  solution master node can support jumbo frames (MTU=9000), but all  switches and hosts on the network must be configured to support jumbo  frames if this is selected, or performance might be degraded. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 178 IP address 1 IP address 2 Up to 16 static IP addresses Link aggregation - two 10 GigE ports BlackPearl system Figure 139 Connection example utilizing two IP addresses assigned to a single share. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 179: Troubleshooting

    NAS solution master node only supports auto‐negotiation. Make sure  the switch is configured to match speeds on both ends of the  connection.  Check the cables that connect the port to the other device. Make sure  that they are connected. Verify that you are using the correct cable type  and connectors. This is especially critical for 10 GigE and 40 GigE  connections utilizing SFPs.  Verify that the switch ports are not administratively disabled. Consult  the switch User Guide for more information. Port Link LED is Lit, But I Cannot Ping the BlackPearl NAS solution  Check the LACP settings on the switch. If you are using link  aggregation on the BlackPearl NAS solution, the switch MUST be  configured to use LACP on those ports. If you are not using link  aggregation, the switch must be configured NOT to use LACP on those  ports.  Check the VLAN (Virtual Local Area Network) settings on the switch.  Ensure that the ports are assigned to the correct VLAN. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 180: Tools

    Reply. Like a regular IP packet, an ICMP packet is forwarded, based on the  intermediate routersʹ routing table, until it reaches the destination. After it  reaches the destination, the ICMP Echo Reply packet is generated and  returned to the originating node. For example, to verify the connectivity from the switch to the IP address  192.168.2.10, run the command shown below from the switch command  line or client: ping 192.168.2.10  All ICMP Echo requests should receive replies including information  about the round trip time it took to receive the response. A response of 0  msec means that the time was less than 1 ms. If the request times out, then  check the settings on the switch to which the BlackPearl NAS solution  master node is connected.  Traceroute You can use the traceroute command, if it is available, or something similar  to not only verify connectivity to a remote network node, but to track the  responses from intermediate nodes as well. The traceroute command sends  a UDP packet to a port that is likely to not be used on a remote node with a  TTL of 1. After the packet reaches the intermediate router, the TTL is  decremented, and the ICMP time‐exceeded message is sent back to the  originating node, which increments the TTL to 2, and the process repeats.  After the UDP packet reaches a destination host, an ICMP port‐ unreachable message is sent back to the sender. This action provides the  sender with information about all intermediate routers on the way to the  destination.  For example, in the output of the command shown below,  traceroute 192.168.2.10 displays a numbered list indicating how many hops, on the way from the  switch to the BlackPearl NAS solution master node, are encountered when  tracing the packet. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 181: Spectra Logic Technical Support

    Support by Product and Knowledge Base tabs for additional troubleshooting  information. Contact Support If the problem persists, open a support ticket (see Open a  Support Ticket below). Determine the System Serial Number If you have more than one BlackPearl NAS solution, it is necessary to  determine the serial number of the system before contacting Spectra Logic  Technical Support. Use the following steps to determine the system serial  number. 1. From the menu bar, select Support > Contact Information. The Contact  Information screen displays. 2. The system serial number is listed in the Product Information pane. Figure 140 The system serial number. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 182: Open A Support Ticket

    Note: See Create an Account on page 134 if you did not previously  create an account on the Technical Support portal. b. Select Incidents & Inventory > Open or View Incidents, or on the  Home page, click Open a Support Incident. Figure 141 Select Incidents & Inventory > Open or View Incidents to open a support incident. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 183 Spectra Logic Technical Support c. On the Open or View Incidents page, you are given an  opportunity to search for existing support content that may help  you solve your problem immediately. If the search does not  provide an answer, click Open a New Incident. Note: You must perform a search before you are able to open a new  support incident. Figure 142 The Open or View Incidents page. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 184: Support

    Remote Support d. On the Create Incident page, enter the requested information  providing as much detail as possible. When you are finished,  click Create Incident. Figure 143 The Create Incident page.  If it is within the hours of coverage provided by your support  contract, you can also contact Spectra Logic Technical Support by  telephone. See Contacting Spectra Logic on page EMOTE UPPORT Remote Support is an option that allows Spectra Logic Technical Support  personnel to access the root console of the system. This option is for  troubleshooting purposes only. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 185: Enable Remote Support

    The Enable Remote Support check box does not display until  Note: you enter a Remote Support activation key. 5. Click Save. After Spectra Logic Technical Support informs you that they no longer require root Important access to the system, you should disable Remote Support to prevent any potential unauthorized access to your system. See Disable Remote Support on page 186 more information.
  • Page 186: Disable Remote Support

    Remote Support Disable Remote Support Use the instruction in this section to disable Remote Support. 1. From the menu bar, select Configuration > Users. The Users screen  displays a list of all users configured on the system. 2. Double‐click the Administrator account in the Primary Administrators  pane, or select the Administrator account, and then select Action > Edit. The Edit User dialog box displays. Figure 145 The Edit User dialog box. 3. Clear the Enable Remote Support check box. 4. Click Save. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 187: Verview

    PPENDIX Network File Interface VERVIEW The Network File Interface (NFI) service allows you to automatically move  data from your BlackPearl NAS solution to one or more BlackPearl  Converged Storage systems, without the need to use a Spectra S3 client.  Data is transferred on a schedule and data copied from the BlackPearl NAS  solution to the system can be configured to be kept on the NAS solution or  deleted.  When a user needs access to data deleted from the BlackPearl NAS  solution, they can use the Spectra Eon Browser or an API client to retrieve  the files from the BlackPearl system. EQUIREMENTS The Network File Interface service has the following requirements:  Files being stored as objects to a BlackPearl Converged Storage system  must follow the Amazon S3 naming restrictions. See http:// docs.aws.amazon.com/AmazonS3/latest/dev/UsingMetadata.html for  more information.  If the target BlackPearl system is running software version 3.0 or later,  then the system has Advanced Bucket Management (ABM) capabilities.  When using an ABM‐enabled system with NFI, you must first  configure buckets on the BlackPearl system, and configure data policies  for the user using NFI to transfer data to the system. See the Spectra  BlackPearl User Guide for instructions on creating buckets and  configuring data policies.   If you plan to modify files on the BlackPearl NAS share configured for  NFI replication, you must configure the target BlackPearl system as  described in Configure a BlackPearl System for Versioning on page 189.  If you do not plan to modify files on the BlackPearl NAS share, skip to  Configure Network File Interface on page 192. ...
  • Page 188: Onsiderations For Black Earl

     The LTFS file name option must be set to Object Name when  configuring a storage domain. This setting configures LTFS file names  to use the format {bucket name}/{object name}, for example bucket1/ video1.mov. If the tapes are ejected from the BlackPearl system and  loaded into a non‐BlackPearl system, the file names match the object  names. If you do not configure this option, object names are assigned a  UUID string, which is not human readable.  Object names must comply with LTFS file naming rules:  The colon character (:) is not allowed in LTFS file names and  therefore not allowed in BlackPearl object names. The slash  character (/) is also technically not allowed in LTFS file names;  however, the BlackPearl software can accommodate a slash in  the object name and translates it as a directory in the LTFS file  system (for example, directory1/directory2/video1.mov).  Directory names have a limit of 255 characters.  File names have a variable character limit. If you are using  English ASCII characters, the limit is 1024 characters. If you are  using a graphical language, such as Japanese, the limit is 512  characters.  Spectra Logic does not recommend the following characters in  LTFS file names or BlackPearl object names for reasons of cross‐ platform compatibility: control characters such as carriage  return (CR) and line feed (LF), double quotation mark (“),  asterisk (*), question mark (?), less than sign (<), greater than  sign (>), backslash (\), forward slash (/) vertical line (|).  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 189: Earl  S Ystem   For  V Ersioning

    ONFIGURE A LACK EARL YSTEM FOR ERSIONING If you plan to modify files on the BlackPearl NAS share that is configured  for NFI replication, you must configure the target BlackPearl system with a  storage domain and data policy that allow versioning as described in this  section. If you do not plan to modify files on the BlackPearl NAS share,  skip to Configure Network File Interface on page 192. Once you create the required storage domain and data policy, you can then  either:   Create a bucket using the required data policy and specify that  bucket when configuring the NFI service.   Create a user and specify the required data policy as the default  data policy. Then when the NFI service creates a bucket specifying  that user as the owner, the bucket is created using the required data  policy. Use the instructions below to create a storage domain and data policy that  allow versioning. 1. If you have not done so already, follow the instructions in the “Initial  Configuration” chapter of the Spectra BlackPearl User Guide. You may find it helpful to read the information in the  Note: “Understanding Spectra Advanced Bucket Management  Concepts” chapter of the Spectra BlackPearl User Guide. Log into the BlackPearl user interface as described in the Spectra  BlackPearl User Guide. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 190 > Show Details from the menu bar. b. Select Action > New Data Persistence Rule. The New Data  Persistence Rule dialog box displays. c. Use the Storage Domain drop‐down menu to select the storage  domain you created in Step 5, above. Configure the data persistence rule as desired. See the Spectra  BlackPearl User Guide for instructions. e. Click Create. The new data persistence rule displays on the Data  Policy details screen. 8. Once you create the data policy, you must either create bucket(s) using  that data policy, or create a new user with the data policy you created  selected as the default for that user. Choose the corresponding  instructions below:  Create a Bucket Using the Required Data Policy on page 191  ‐OR‐  Create a User Using the Required Data Policy on page 191  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 191 Create a User Using the Required Data Policy Use the instructions in this section to create a user on the BlackPearl system  with a default data policy that allows versioning. 1. In the BlackPearl user interface, select Configuration > Users. The  Users screen displays. 2. From the menu bar, select Action > New. The New User dialog box  displays. a. Configure the user as desired. See the Spectra BlackPearl User Guide  for instructions.  b. Using the Default Data Policy drop down menu, select the data  policy you created in Step 6 on page 190. 3. Click Create. The new user displays on the Users Screen. Note: You must enter the name and S3 credentials for this user when  configuring the NFI service so that buckets created for this user  use the specified default data policy. 4. Continue to Configure Network File Interface below. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 192: Onfigure

    1. From the menu bar, select Configuration > Services to display the  Services screen. 2. Double‐click the NFI service, or select the service, and then select Action > Show Details. The details screen for the NFI service displays. Figure 146 The NFI service details screen. 3. Select Action > Configure. The Configure dialog box displays. Figure 147 The Configure dialog box. 4. Enter the IP address or the DNS name of the data port of the target  BlackPearl system to which you want to connect in the BlackPearl System entry field. If you do not know the IP address or DNS name of  the BlackPearl system, consult the Spectra BlackPearl User Guide for  instructions. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 193: Configure A Volume

    49, if necessary. The combined length of the names of both the storage pool and volume used for Important NFI cannot exceed 52 bytes, or the NFI job fails. Most english characters are 1 byte. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 194 Configure Network File Interface 1. From the menu bar, select Configuration > NAS > Volumes, or click the  Volumes pane on the Dashboard. The Volumes screen displays. Figure 148 The Volumes screen.  Double‐click the volume you want to edit, or select the volume and  then select Action > Edit. The Edit volume name dialog box displays —OR—  Select Action > New. The New Volume dialog box displays. Figure 149 The New Volume dialog box. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 195 Case Insensitive If desired, select this option to configure the volume to treat all names as case  (CIFS) insensitive, which can improve performance, especially in situations where  directories contain a large number of files. Note: This option should only be used for volumes shared using CIFS and  cannot be changed after creating the volume. CAUTION: DO NOT enable this setting if you plan to share the volume using NFS. Compression If desired, select the check box to enable the BlackPearl NAS solution system to  compress stored data. If the data being written is compressible there is an  increase in write performance to the volume, which is dependent on how much  compression occurs on the data being written. The data compression process  uses CPU cycles to perform the compression. If compression is enabled and  non‐compressible data is written to the volume, the compression process may  use an excessive number of CPU cycles, slowing the overall performance of the  system. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 196 For example, the BlackPearl buckets 'Index' and 'index' both map to the cloud bucket 'index' , causing possible data collision and bucket ownership/permission problems. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 197 Create an Hourly Schedule 1. In the New Volume dialog box, select Hourly as the interval for the  policy schedule. The dialog box changes to display options for the  hourly interval setting Figure 150 The New Volume dialog box showing the hourly interval options. 2. Enter a number for Every _ hours on the hour. This value specifies the  interval, in hours, between transferring data to the BlackPearl system.  For example, if this value is set to 4, the system copies data every four  hours. The maximum setting for this field is 48, where the system  copies data every two days. 3. Click Create. Continue to Next Steps on page 199. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 198 Create a Weekly Schedule 1. In the New Volume dialog box, select Weekly as the interval for the  policy schedule. The dialog box changes to display options for the  weekly interval setting. Figure 152 The New Volume dialog box showing the weekly interval options. 2. Enter a time value for Start Time, and include AM or PM after the value.  This field is not case sensitive. 3. Select one or more days for Every week on:. This determines the day(s)  of each week the system copies data to the BlackPearl system.  4. Click Create. Continue to Next Steps on page 199. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 199: Restore Files Using The Eon Browser

    NFI T ESTORING ILES ROM AN ARGET LACK EARL YSTEM If files copied to the BlackPearl system using the NFI service are deleted  from the BlackPearl NAS solution, or the BlackPearl NAS solution fails,  you can retrieve files from the BlackPearl system using the Spectra Eon  Browser, Spectra Deep Storage Browser, or a Spectra S3 client. If you only  need to retrieve a small number of files, Spectra Logic recommends using  the Eon Browser. Restore Files Using the Eon Browser For instructions for installing, configuring, and using the Eon Browser, see  the BlackPearl Eon Browser User Guide. Restore Files Using a Spectra S3 Client Consult the documentation for your Spectra S3 client to restore files from  an NFI target BlackPearl system.  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 200 This appendix provides instructions for configuring IPMI for the  BlackPearl NAS solution using the system BIOS. DO NOT make any changes in the BIOS other than changing the IPMI settings as Caution described below. Changing any other setting is not supported by Spectra Logic and may cause adverse system performance. 1. If the BlackPearl NAS solution is currently powered on, shut down the  system as described in Reboot or Shut down a BlackPearl NAS Solution  on page 146.
  • Page 201 5. Using the keyboard, navigate to the IPMI tab and then select BMC Network Configuration. The current settings of the BMC configuration  display. Figure 153 The BMC Configuration screen. 6. Using the keyboard, select Update IMPI LAN Configuration. A  confirmation window displays. Select YES to continue. The current  IMPI settings display. Figure 154 Current IPMI settings. October 2019 User Guide—Spectra BlackPearl Converged Storage System...
  • Page 202 8. If desired, select VLAN to enable or disable VLAN as needed. 9. To change the IPMI address settings, select Configuration Address source. The current address source information displays. 10. Select Static or DHCP addressing.   If you select DHCP, skip to Step  If you select Static, IP addressing fields display. Figure 155 Enter Static IP information. 11. Configure the Station IP address, Subnet mask, and Router IP address  with the desired address values. Only IPv4 addresses are valid. Note: 12. Press F4 to exit the BIOS and save the entered settings. The BlackPearl  NAS solution reboots. October 2019 User Guide—Spectra BlackPearl Converged Storage System...
  • Page 203: Specifications

    PPENDIX Specifications This appendix provides specifications for BlackPearl master nodes, the  BlackPearl enterprise expansion node, the BlackPearl archive expansion  node, and the 107‐drive disk solution. All specifications are subject to change without notice. Note: Specification Data Storage Specifications page 204 BlackPearl NAS 2U and 4U Master Nodes page 204 BlackPearl Enterprise Expansion Node page 204 BlackPearl Archive Expansion Node page 204 Capacity page 205 System Specification page 206 BlackPearl NAS 2U Master Node page 206 BlackPearl NAS 4U Master Node page 206 Size and Weight page 207 BlackPearl NAS 2U Master Node page 207 BlackPearl NAS 4U Master Node and BlackPearl  page 207 Enterprise Expansion Node BlackPearl Archive Expansion Node page 208...
  • Page 204: Torage Specifications

    1 TB is defined as 1,000,000,000,000 bytes. 107-Drive Disk Solution Drive Purpose Specification Storage Pools or NAS 400 GB Solid‐State SAS  4, 8, 12 TB Spinning‐Disk SAS  12 or 16 TB Spinning‐Disk SATA a. 1 GB is defined as 1,000,000,000 bytes. b. 1 TB is defined as 1,000,000,000,000 bytes. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 205: Capacity

    A BlackPearl expansion node with an active bezel requires a Visual Status Beacon control sled installed in one drive storage slot. d. A BlackPearl expansion node with a passive bezel does not require a Visual Status Beacon control sled and can hold one additional data storage drive. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 206: Pecification

    Each optional two-port SAS card is used to connect the BlackPearl master node to up to two BlackPearl archive expansion nodes. If your installation does not include an expansion node, the card is not installed. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 207: Blackpearl Nas 2U Master Node

    7 in. (17.8 cm) 17.5 in. (44.5 cm)  Width 19 in. (48.3 cm) 27 in. (68.6 cm)  Depth 29.5 in. (75 cm)  39 in. (99.0 cm) Weight   Empty chassis 57 lb (25.8 kg) 91.3 lb   Additional for each disk drive 1.8 lb (0.8 kg) 1.8 lb (0.8 kg) a. Includes chassis and packaging. b. Includes the front bezel. c. Weights are approximate. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 208: Blackpearl Archive Expansion Node

    Includes the front bezel. b. Weights are approximate. OWER EQUIREMENTS The BlackPearl NAS solution, BlackPearl enterprise expansion nodes,  BlackPearl archive expansion nodes, and 107‐drive disk solution node have  the following power requirements. Failure to meet the cabling and power specifications could damage your system, Caution result in data loss, or both. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 209: Input Power Requirements

    180–240 VAC, 8–6 A, 1280 watts maximum Input Frequency 50–60 Hz BlackPearl Enterprise Expansion Node Parameter Requirements Input Voltage 100–140 VAC, 13.5–9.5 A, 1100 watts maximum 180–240 VAC, 9.5–7 A, 1400 watts maximum Input Frequency 50–60 Hz BlackPearl Archive Expansion Node Parameter Requirements Input Voltage 90‐264 VAC, 1100 watts maximum Input Frequency 47–63 Hz 107-Drive Disk Solution Parameter Requirements Input Voltage 100‐240 VAC Input Frequency   October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 210: Power Cords

    Power cordage Three‐conductor, 14 AWG  Male: NEMA 5‐15P or IEC‐60320 C14 Power input connectors  Female: IEC 60320 C13 NEMA 5-15P IEC 60320 C14 IEC 60320 C13 male connector male connector female connector North American 220 Volt-AC Power Cord The criteria for a 220‐volt power  cord for use in the United States and Canada are as follows: Parameter Specification Power cordage SJT type, three‐conductor, 14 AWG minimum  October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 211: Interface Specifications

    This section provides information about the interfaces used to connect a  BlackPearl NAS solution to expansion nodes, and host systems. BlackPearl NAS Solution Interface Connectors Interface Type Number of Ports and Connector Type Ethernet (1000BaseT,  Two RJ‐45 sockets. or 10GBase‐T) Ethernet (10 GigE) Two SFP+ optical modules with a duplex LC  connector per optional 10 GigE NIC. Ethernet (40 GigE) Two QSFP+ optical modules with a duplex LC  connector per optional 40 GigE NIC. SAS (6 Gbps) Four SFF‐8644 sockets per optional 6 Gbps SAS card  provide connections to two BlackPearl expansion  nodes, using two ports for each expansion node. SAS (12 Gbps) Two SFF‐8644 sockets per optional 12 Gbps SAS card  provide connections to two BlackPearl archive  expansion nodes, or two 107‐drive disk solutions,  using one port per expansion node or solution. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 212: Expansion Node Interface Connectors

    Cable Requirements Ethernet (10GBase‐T  10GBase‐T ‐ Shielded Category 6A data‐grade cable with a RJ‐45  or 10/100/1000Base‐T) connector. 10/100/1000Base‐T ‐ Shielded Category 5 data‐grade cable with a  RJ‐45 connector. Cables provided by the customer. Note: Ethernet (10 GigE)  Multimode optical cable with duplex LC connectors. Note: Cables provided by the customer. Ethernet (40 GigE)  QSFP+ transceiver MPT optical cables with duplex LC connectors,  or copper cables with duplex LC connector. Note: Cables provided by the customer. BlackPearl enterprise expansion node: 6 Gbps 4 lane cable with  SFF‐8644 and SFF‐8088 connectors. Two SAS cables are required  for each BlackPearl expansion node. Two SAS cables are included with each BlackPearl  Note: expansion node. BlackPearl archive expansion node: 12 Gbps cable with SFF‐8644  connectors. One SAS cable is required for each BlackPearl archive  expansion node. 107‐Drive disk solution: 12 Gbps cable with SFF‐8644 connectors.  One SAS cable is required for each 107‐drive disk solution. Note: One SAS cable is included with each BlackPearl expansion  node or disk solution. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 213: Universal Serial Bus (Usb) Support

    Specifications are for the BlackPearl chassis in its original packaging. The packaging protects the BlackPearl NAS solution from condensation caused by extreme temperature variations (27° F per hour or 15° C per hour, or more). October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 214: Blackpearl Archive Expansion Node

    Specifications are for the 107-drive disk solution is in its original packaging. The packaging is designed to protect the 107-drive disk solution from condensation caused by extreme temperature variations (27° F per hour or 15° C per hour, or more). October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 215: Appendix C - Regulatory & Safety Standards

    PPENDIX Regulatory & Safety Standards When installed in accordance with this guide, the Spectra BlackPearl NAS  solution master nodes, the BlackPearl expansion nodes, and 107‐drive disk  solution comply with the safety and regulatory agency standards listed in  this appendix.  EU D ECLARATION OF ONFORMITY Spectra Logic Corporation  6101 Lookout Road Boulder, CO 80301 USA declare under sole responsibility that the Spectra BlackPearl NAS solution to which this declaration relates, meets the essential health and safety  requirements and is in conformity with the EU Directives listed below  using the relevant section of the EU standards and other normative  documents listed in the following table. Nicole Gallego Senior Director of Manufacturing and Quality Operations Directive Compliance EU EMC Directive Essential health and safety requirements relating to electromagnetic  89/336/EEC compatibility. EN 55022  Limits and methods of measurements of radio interference characteristics of  (CISPER 22) Class A information technology equipment. EN 55024 1998, Information Technology Equipment ‐ Immunity Characteristics Limits  and Methods of Measurement. EN 61000‐4‐2 1995 + A1:1998+A2: 2001, Electrostatic Discharge EN 61000‐4‐3...
  • Page 216: Eu Declaration Of Conformity

    Covers Canada System China Power supply only System Mexico Supermicro 2U and 4U chassis, Sanmina chassis Taiwan BSMI Power supply only UL, FCC System Japan VCCI System The BlackPearl NAS solution complies with all safety‐relevant provisions  referring to:  Protection against electrical hazards  Protection against hazards such as:  Mechanical hazards  Fire hazards  Noise  Vibration The safety issues of this information technology equipment type have been  evaluated by a government‐accredited European third‐party organization,  such as Nemko. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 217: Ce Marking

    AFETY TANDARDS AND OMPLIANCE The Spectra BlackPearl NAS solution master nodes, the BlackPearl  expansion nodes, and 107‐drive disk solution comply with the following  domestic and international product safety standards.  EN 60950‐1 Second Edition  UL 60950‐1 Second Edition  CSA‐C22.2 No. 60950‐1‐03  Low Voltage Directive (EU: CE Mark) Waste of Electronic and Electrical Equipment (WEEE) Directive The following symbol on the back of this product  indicates that this product meets the European Directive  2000/96/EC on Waste Electrical and Electronic Equipment  known as the WEEE directive. This directive, only  applicable in European Union countries, indicates that this  product should not be disposed of with normal unsorted  municipal waste. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 218: Restriction Of Hazardous Substances In Electrical And Electronic

    Equipment (RoHS) The RoHS marking indicates that this product is in  compliance with European Council Directive 2011/65/2008,  on the restriction of the use of certain hazardous substances  in electrical and electronic equipment. NAS S ECYCLING LACK EARL OLUTION For information on recycling your Spectra product, check the Spectra Logic  website at: http://www.spectralogic.com/environment. ONFLICT INERALS OLICY Spectra Logic is committed to complying with the OECD Due Diligence  Guidance for Responsible Supply Chains of Minerals from Conflict‐ Affected and High‐Risk Areas, as well as the applicable requirements of  Section 1502 of the Dodd‐Frank Act, which aims to prevent the use of  minerals that directly or indirectly finance or benefit armed groups in the  Democratic Republic of the Congo (DRC) or in adjoining countries  (“conflict minerals”).  Affected suppliers to Spectra Logic will be required to commit to being or  becoming “conflict‐free” (which means that such supplier does not source  conflict minerals) and sourcing, where possible, only from conflict‐free  smelters. Each affected supplier to Spectra Logic will be required to  provide completed EICC‐GeSI declarations evidencing such supplierʹs  commitment to becoming conflict‐free and documenting countries of  origin for the tin, tantalum, tungsten, and gold that it purchases.  For more information on Spectra Logicʹs conflict minerals program contact  conflictminerals@spectralogic.com. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 219: Appendix D - Open Source Code Acknowledgements & Package List

    PPENDIX Open Source Code Acknowledgements & Package List Copyright © 2010 ‐ 2019 Spectra Logic Corporation. All rights reserved. This appendix contains the licenses and notices for open source software  used in the BlackPearl NAS solution product. If you have any questions or  want to receive a copy of the free/open source software to which you are  entitled under the applicable free/open source license(s) (such as the  Common Development and Distribution License (CCDL)), contact Spectra  Logic Technical Support (see Contacting Spectra Logic on page PACHE Licensed under the Apache License, Version 2.0 (the “License”); you may  not use this file except in compliance with the License. You may obtain a copy of the License at: http://www.apache.org/licenses/LICENSE‐2.0 Unless required by applicable law or agreed to in writing, software  distributed under the License is distributed on an “AS IS” BASIS,  WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either  express or implied. See the License for the specific language governing  permissions and limitations under the License. Copyright © 1992‐2019 The FreeBSD Project. All rights reserved. Redistribution and use in source and binary forms, with or without  modification, are permitted provided that the following conditions are  met: 1. Redistributions of source code must retain the above copyright notice,  this list of conditions and the following disclaimer.
  • Page 220: Java

    NOT LIMITED TO, THE IMPLIED WARRANTIES OF  MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE  ARE DISCLAIMED. IN NO EVENT SHALL THE FREEBSD PROJECT OR  CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT,  INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL  DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF  SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS;  OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY  THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,  OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN  ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED  OF THE POSSIBILITY OF SUCH DAMAGE. The views and conclusions contained in the software and documentation  are those of the authors and should not be interpreted as representing  official policies, either expressed or implied, of the FreeBSD Project. ORACLE AMERICA, INC. (ʺORACLEʺ), FOR AND ON BEHALF OF  ITSELF AND ITS SUBSIDIARIES AND AFFILIATES UNDER COMMON  CONTROL, IS WILLING TO LICENSE THE SOFTWARE TO YOU ONLY  UPON THE CONDITION THAT YOU ACCEPT ALL OF THE TERMS  CONTAINED IN THIS BINARY CODE LICENSE AGREEMENT AND  SUPPLEMENTAL LICENSE TERMS (COLLECTIVELY ʺAGREEMENTʺ).  PLEASE READ THE AGREEMENT CAREFULLY. BY SELECTING THE  ʺACCEPT LICENSE AGREEMENTʺ (OR THE EQUIVALENT) BUTTON  AND/OR BY USING THE SOFTWARE YOU ACKNOWLEDGE THAT  YOU HAVE READ THE TERMS AND AGREE TO THEM. IF YOU ARE  AGREEING TO THESE TERMS ON BEHALF OF A COMPANY OR  OTHER LEGAL ENTITY, YOU REPRESENT THAT YOU HAVE THE  LEGAL AUTHORITY TO BIND THE LEGAL ENTITY TO THESE TERMS.  IF YOU DO NOT HAVE SUCH AUTHORITY, OR IF YOU DO NOT WISH  TO BE BOUND BY THE TERMS, THEN SELECT THE ʺDECLINE  LICENSE AGREEMENTʺ (OR THE EQUIVALENT) BUTTON AND YOU  MUST NOT USE THE SOFTWARE ON THIS SITE OR ANY OTHER  MEDIA ON WHICH THE SOFTWARE IS CONTAINED. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 221 Agreement. ʺGeneral Purpose Desktop Computers and Serversʺ means  computers, including desktop and laptop computers, or servers, used for  general computing functions under end user control (such as but not  specifically limited to email, general purpose Internet browsing, and office  suite productivity tools). The use of Software in systems and solutions that  provide dedicated functionality (other than as mentioned above) or  designed for use in embedded or function‐specific software applications,  for example but not limited to: Software embedded in or bundled with  industrial control systems, wireless mobile telephones, wireless handheld  devices, kiosks, TV/STB, Blu‐ray Disc devices, telematics and network  control switching equipment, printers and storage management systems,  and other related systems are excluded from this definition and not  licensed under this Agreement. ʺProgramsʺ means (a) Java technology  applets and applications intended to run on the Java Platform, Standard  Edition platform on Java‐enabled General Purpose Desktop Computers  and Servers; and (b) JavaFX technology applications intended to run on the  JavaFX Runtime on JavaFX‐enabled General Purpose Desktop Computers  and Servers. “Commercial Features” means those features identified in  Table 1‐1 (Commercial Features In Java SE Product Editions) of the Java SE  documentation accessible at http://www.oracle.com/technetwork/java/ javase/documentation/index.html. “README File” means the README  file for the Software accessible at http://www.oracle.com/technetwork/java/ javase/documentation/index.html. 2. LICENSE TO USE. Subject to the terms and conditions of this Agreement  including, but not limited to, the Java Technology Restrictions of the  Supplemental License Terms, Oracle grants you a non‐exclusive, non‐ transferable, limited license without license fees to reproduce and use  internally the Software complete and unmodified for the sole purpose of  running Programs. THE LICENSE SET FORTH IN THIS SECTION 2 DOES  NOT EXTEND TO THE COMMERCIAL FEATURES. YOUR RIGHTS  AND OBLIGATIONS RELATED TO THE COMMERCIAL FEATURES  ARE AS SET FORTH IN THE SUPPLEMENTAL TERMS ALONG WITH  ADDITIONAL LICENSES FOR DEVELOPERS AND PUBLISHERS. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 222 License Terms. 4. DISCLAIMER OF WARRANTY. THE SOFTWARE IS PROVIDED ʺAS ISʺ  WITHOUT WARRANTY OF ANY KIND. ORACLE FURTHER  DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING  WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF  MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR  NONINFRINGEMENT. 5. LIMITATION OF LIABILITY. IN NO EVENT SHALL ORACLE BE  LIABLE FOR ANY INDIRECT, INCIDENTAL, SPECIAL, PUNITIVE OR  CONSEQUENTIAL DAMAGES, OR DAMAGES FOR LOSS OF PROFITS,  REVENUE, DATA OR DATA USE, INCURRED BY YOU OR ANY THIRD  PARTY, WHETHER IN AN ACTION IN CONTRACT OR TORT, EVEN IF  ORACLE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH  DAMAGES. ORACLEʹS ENTIRE LIABILITY FOR DAMAGES  HEREUNDER SHALL IN NO EVENT EXCEED ONE THOUSAND  DOLLARS (U.S. $1,000). 6. TERMINATION. This Agreement is effective until terminated. You may  terminate this Agreement at any time by destroying all copies of Software.  This Agreement will terminate immediately without notice from Oracle if  you fail to comply with any provision of this Agreement. Either party may  terminate this Agreement immediately should any Software become, or in  either partyʹs opinion be likely to become, the subject of a claim of  infringement of any intellectual property right. Upon termination, you  must destroy all copies of Software. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 223 8. TRADEMARKS AND LOGOS. You acknowledge and agree as between  you and Oracle that Oracle owns the ORACLE and JAVA trademarks and  all ORACLE‐ and JAVA‐related trademarks, service marks, logos and other  brand designations (ʺOracle Marksʺ), and you agree to comply with the  Third Party Usage Guidelines for Oracle Trademarks currently located at http://www.oracle.com/us/legal/third‐party‐trademarks/index.html . Any  use you make of the Oracle Marks inures to Oracleʹs benefit. 9. U.S. GOVERNMENT LICENSE RIGHTS. If Software is being acquired  by or on behalf of the U.S. Government or by a U.S. Government prime  contractor or subcontractor (at any tier), then the Governmentʹs rights in  Software and accompanying documentation shall be only those set forth in  this Agreement. 10. GOVERNING LAW. This agreement is governed by the substantive  and procedural laws of California. You and Oracle agree to submit to the  exclusive jurisdiction of, and venue in, the courts of San Francisco, or Santa  Clara counties in California in any dispute arising out of or relating to this  agreement. 11. SEVERABILITY. If any provision of this Agreement is held to be  unenforceable, this Agreement will remain in effect with the provision  omitted, unless omission would frustrate the intent of the parties, in which  case this Agreement will immediately terminate. 12. INTEGRATION. This Agreement is the entire agreement between you  and Oracle relating to its subject matter. It supersedes all prior or  contemporaneous oral or written communications, proposals,  representations and warranties and prevails over any conflicting or  additional terms of any quote, order, acknowledgment, or other  communication between the parties relating to its subject matter during  the term of this Agreement. No modification of this Agreement will be  binding, unless in writing and signed by an authorized representative of  each party. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 224 Java SUPPLEMENTAL LICENSE TERMS These Supplemental License Terms add to or modify the terms of the  Binary Code License Agreement. Capitalized terms not defined in these  Supplemental Terms shall have the same meanings ascribed to them in the  Binary Code License Agreement. These Supplemental Terms shall  supersede any inconsistent or conflicting terms in the Binary Code License  Agreement, or in any license contained within the Software. A. COMMERCIAL FEATURES. You may not use the Commercial Features  for running Programs, Java applets or applications in your internal  business operations or for any commercial or production purpose, or for  any purpose other than as set forth in Sections B, C, D and E of these  Supplemental Terms. If You want to use the Commercial Features for any  purpose other than as permitted in this Agreement, You must obtain a  separate license from Oracle. B. SOFTWARE INTERNAL USE FOR DEVELOPMENT LICENSE GRANT.  Subject to the terms and conditions of this Agreement and restrictions and  exceptions set forth in the README File incorporated herein by reference,  including, but not limited to the Java Technology Restrictions of these  Supplemental Terms, Oracle grants you a non‐exclusive, non‐transferable,  limited license without fees to reproduce internally and use internally the  Software complete and unmodified for the purpose of designing,  developing, and testing your Programs. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 225 Oracleʹs interests consistent with the terms contained in this Agreement  and that includes the notice set forth in Section H, and (vi) you agree to  defend and indemnify Oracle and its licensors from and against any  damages, costs, liabilities, settlement amounts and/or expenses (including  attorneysʹ fees) incurred in connection with any claim, lawsuit or action by  any third party that arises or results from the use or distribution of any and  all Programs and/or Software. The license set forth in this Section C does  not extend to the Software identified in Section G. D. LICENSE TO DISTRIBUTE REDISTRIBUTABLES. Subject to the terms  and conditions of this Agreement and restrictions and exceptions set forth  in the README File, including but not limited to the Java Technology  Restrictions and Limitations on Redistribution of these Supplemental  Terms, Oracle grants you a non‐exclusive, non‐transferable, limited license  without fees to reproduce and distribute those files specifically identified  as redistributable in the README File (ʺRedistributablesʺ) provided that:  (i) you distribute the Redistributables complete and unmodified, and only  bundled as part of Programs, (ii) the Programs add significant and primary  functionality to the Redistributables, (iii) you do not distribute additional  software intended to supersede any component(s) of the Redistributables  (unless otherwise specified in the applicable README File), (iv) you do  not remove or alter any proprietary legends or notices contained in or on  the Redistributables, (v) you only distribute the Redistributables pursuant  to a license agreement that: (a) is a complete, unmodified reproduction of  this Agreement; or (b) protects Oracleʹs interests consistent with the terms  contained in the Agreement and includes the notice set forth in Section H,  (vi) you agree to defend and indemnify Oracle and its licensors from and  against any damages, costs, liabilities, settlement amounts and/or expenses  (including attorneysʹ fees) incurred in connection with any claim, lawsuit  or action by any third party that arises or results from the use or  distribution of any and all Programs and/or Software. The license set forth  in this Section D does not extend to the Software identified in Section G. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 226 (including with respect to all proprietary notices) and distributed with  your Publication subject to a license agreement that is a complete,  unmodified reproduction of this Agreement; (v) The Media label shall  include the following information: “Copyright [YEAR], Oracle America,  Inc. All rights reserved. Use is subject to license terms. ORACLE and JAVA  trademarks and all ORACLE‐ and JAVA‐related trademarks, service  marks, logos and other brand designations are trademarks or registered  trademarks of Oracle in the U.S. and other countries.” [YEAR] is the year of  Oracleʹs release of the Software; the year information can typically be  found in the Software’s “About” box or screen. This information must be  placed on the Media label in such a manner as to only apply to the JDK; (vi)  You must clearly identify the JDK as Oracleʹs product on the Media holder  or Media label, and you may not state or imply that Oracle is responsible  for any third‐party software contained on the Media; (vii) You may not  include any third party software on the Media which is intended to be a  replacement or substitute for the JDK; (viii) You agree to defend and  indemnify Oracle and its licensors from and against any damages, costs,  liabilities, settlement amounts and/or expenses (including attorneysʹ fees)  incurred in connection with any claim, lawsuit or action by any third party  that arises or results from the use or distribution of the JDK and/or the  Publication; ; and (ix) You shall provide Oracle with a written notice for  each Publication; such notice shall include the following information: (1)  title of Publication, (2) author(s), (3) date of Publication, and (4) ISBN or  ISSN numbers. Such notice shall be sent to Oracle America, Inc., 500 Oracle  Parkway, Redwood Shores, California 94065 U.S.A , Attention: General  Counsel. F. JAVA TECHNOLOGY RESTRICTIONS. You may not create, modify, or  change the behavior of, or authorize your licensees to create, modify, or  change the behavior of, classes, interfaces, or subpackages that are in any  way identified as ʺjavaʺ, ʺjavaxʺ, ʺsunʺ, “oracle” or similar convention as  specified by Oracle in any naming convention designation. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 227 H. COMMERCIAL FEATURES NOTICE. For purpose of complying with  Supplemental Term Section C.(v)(b) and D.(v)(b), your license agreement  shall include the following notice, where the notice is displayed in a  manner that anyone using the Software will see the notice: Use of the Commercial Features for any commercial or production purpose  requires a separate license from Oracle. “Commercial Features” means  those features identified Table 1‐1 (Commercial Features In Java SE  Product Editions) of the Java SE documentation accessible at http:// www.oracle.com/technetwork/java/javase/documentation/index.html I. SOURCE CODE. Software may contain source code that, unless  expressly licensed for other purposes, is provided solely for reference  purposes pursuant to the terms of this Agreement. Source code may not be  redistributed unless expressly provided for in this Agreement. J. THIRD PARTY CODE. Additional copyright notices and license terms  applicable to portions of the Software are set forth in the  THIRDPARTYLICENSEREADME file accessible at http:// www.oracle.com/technetwork/java/javase/documentation/index.html. In  addition to any terms and conditions of any third party opensource/ freeware license identified in the THIRDPARTYLICENSEREADME file,  the disclaimer of warranty and limitation of liability provisions in  paragraphs 4 and 5 of the Binary Code License Agreement shall apply to  all Software in this distribution. K. TERMINATION FOR INFRINGEMENT. Either party may terminate  this Agreement immediately should any Software become, or in either  partyʹs opinion be likely to become, the subject of a claim of infringement  of any intellectual property right. L. INSTALLATION AND AUTO‐UPDATE. The Softwareʹs installation and  auto‐update processes transmit a limited amount of data to Oracle (or its  service provider) about those specific processes to help Oracle understand  and optimize them. Oracle does not associate the data with personally  identifiable information. You can find more information about the data  Oracle collects as a result of your Software download at http:// www.oracle.com/technetwork/java/javase/documentation/index.html. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 228: Samba

    (GPL version 3)  For more details and for the full text for each of these licenses, read the  LICENSES and COPYING files included with the source packaging of this  software. On Debian GNU/Linux systems, the complete text of the GNU General  Public License can be found in `/usr/share/common‐licenses/GPLʹ. GINX Copyright (C) 2002‐2019 Igor Sysoev Copyright (C) 2011‐2019 Nginx, Inc. All rights reserved. Redistribution and use in source and binary forms, with or without  modification, are permitted provided that the following conditions are  met:  1. Redistributions of source code must retain the above copyright notice,  this list of conditions and the following disclaimer.  2. Redistributions in binary form must reproduce the above copyright  notice, this list of conditions and the following disclaimer in the  documentation and/or other materials provided with the distribution. THIS SOFTWARE IS PROVIDED BY THE AUTHOR AND  CONTRIBUTORS ``AS ISʹʹ AND ANY EXPRESS OR IMPLIED  WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED  WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A  PARTICULAR PURPOSE ARE DISCLAIMED.  IN NO EVENT SHALL  THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT,  INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR  CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,  PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE,  DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER  CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN  CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE  OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS  SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH  DAMAGE. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 229: Ruby

    Ruby Ruby is copyrighted free software by Yukihiro Matsumoto  <matz@netlab.jp>. You can redistribute it and/or modify it under either the terms of the  2‐clause BSDL (see the file BSDL), or the conditions below: 1. You may make and give away verbatim copies of the source form of the  software without restriction, provided that you duplicate all of the  original copyright notices and associated disclaimers. 2. You may modify your copy of the software in any way, provided that  you do at least ONE of the following: a. place your modifications in the Public Domain or otherwise make  them Freely Available, such as by posting said modifications to  Usenet or an equivalent medium, or by allowing the author to  include your modifications in the software. b. use the modified software only within your corporation or  organization. c. give non‐standard binaries non‐standard names, with instructions  on where to get the original software distribution. d. make other distribution arrangements with the author. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 230: Ruby On Rails

    For the list of those files and their copying conditions, see the file  LEGAL. 5. The scripts and library files supplied as input to or produced as output  from the software do not automatically fall under the copyright of the  software, but belong to whomever generated them, and may be sold  commercially, and may be aggregated with this software. 6. THIS SOFTWARE IS PROVIDED “AS IS” AND WITHOUT ANY  EXPRESS OR IMPLIED WARRANTIES, INCLUDING, WITHOUT  LIMITATION, THE IMPLIED WARRANTIES OF  MERCHANTABILITY AND FITNESS FOR A PARTICULAR  PURPOSE. UBY ON AILS Permission is hereby granted, free of charge, to any person obtaining a  copy of this software and associated documentation files (the “Software”),  to deal in the Software without restriction, including without limitation the  rights to use, copy, modify, merge, publish, distribute, sublicense, and/or  sell copies of the Software, and to permit persons to whom the Software is  furnished to do so, subject to the following conditions: THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF  ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED  TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A  PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT  SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR  ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN  ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,  OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR  OTHER DEALINGS IN THE SOFTWARE. October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 231: Zfs

    COMMON DEVELOPMENT AND DISTRIBUTION LICENSE (CDDL)  Version 1.0 NCLUDED ACKAGES alsa‐lib‐1.1.2 apr‐1.6.2.1.6.0 atf‐0.21 avahi‐app‐0.7_2 bash‐4.4.12_2 black_pearl‐2.3_1 bluestorm_backend‐2.0 bluestorm_frontend‐2.1 bluestorm_gui‐2.0 bluestorm_mgmt‐2.0 bluestorm_tests‐2.0 bluestorm_workers‐2.0 boost‐libs‐1.64.0 c‐ares‐1.12.0_1 ca_root_nss‐3.31 cdbcmd‐0.0 cmocka‐1.1.1_1 compat10x‐amd64‐10.3.1003000.20170608 cscope‐15.8b ctags‐5.8 curl‐7.61.1 cyrus‐sasl‐2.1.26_12 dbus‐1.10.16_1 dbus‐glib‐0.108 dejavu‐2.37 dmidecode‐3.1_1 ds3‐3.2.0 e2fsprogs‐libuuid‐1.43.4 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 232 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 233 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 234 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 235 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 236 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 237 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 238 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 239 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 240 Included Packages tdb‐1.3.16,1 tevent‐0.9.37 tmux‐2.5 tomcat‐native‐1.2.12 tomcat85‐8.5.16_1 verde_hotpair‐2.1 vim‐8.0.0702 xproto‐7.0.31 zip‐3.0_1 zsh‐5.3.1_1 October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 241 NDEX certificates contacting Spectra Logic configure corporate headquarters, Spectra  Logic certifications Activation keys CIFS importing automatically about activation keys, enter create new share Active Directory, join edit share agency declarations dashboard remove sharing CE marking data drive set permissions certifications install new CIFS service conflict mineral policy remove configuring EU declaration of  data integrity verification command line interface conformity data ports, configure component OK icon DNS, configure components RoHS documentation front view safety standards and  typographical conventions rear panel...
  • Page 242 NFI service delete rear view 23, 28 configuring delete a schedule reboot edit download remote support emailing disabling about generate enabling create new share types edit share logical volume manager and file  remove sharing system, about NFS service configuring Nginx, open source  acknowledgement configuring October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 243 Spectra Logic software configuring contacting USB, support create new CIFS manuals, obtaining user create new NFS status icons configure delete storage pools edit 126, 126 edit about types manage create new view status delete shutdown expand 79, 79 SMTP options configuring protection levels requirements view status October 2019 User Guide—Spectra BlackPearl NAS Solution...
  • Page 244 Verde web interface about dashboard log in log out menus status icons supported browsers Visual Status Beacon configuring lights volumes about configure create new CIFS share create new NFS share create snapshot delete delete snapshot edit move options 61, 195, 196 remove sharing restore file from snapshot restore snapshot scheduled snapshots snapshot restore snapshots view status October 2019 User Guide—Spectra BlackPearl NAS Solution...

Table of Contents
