Removing Cables; Removing The Connector - Phoenix Contact AXC F 1152 Installing, Starting Up, And Operating

Removing the supply
connector
AXC F 1152 and AXC F 2152
Removing the Ethernet
connector
107708_en_08
10.2

Removing cables

• Disconnect the Axioline F station from the power supply.
The cables should only be removed from the supply connector if you wish to change the ter-
minal point assignment or no longer wish to use the supply connector.
• Open the spring by pressing on the spring lever with a screwdriver (A in
• Remove the cable (B in
A
B
Figure 10-2 Removing the cable
10.3

Removing the connector

• Release the locking latch (A in
Figure 10-3), and remove it from the controller (C in
Figure 10-3 Removing the supply connector
• Release the RJ45 connector by pressing on the snap-in latch and remove the connec-
tor.
Figure 10-2).
Figure 10-3), tilt the connector upwards slightly (B in
Removing hardware
Figure
Figure 10-3).
C
B
A
AXC F 3152
PHOENIX CONTACT
10-2).
83 / 112
