Table 8-10

System variables of the diagnostic parameter register

System variable
AXIO_DIAG_PARAM_REG_HI
AXIO_DIAG_PARAM_REG_LOW
AXIO_DIAG_PARAM_2_REG_HI
AXIO_DIAG_PARAM_2_REG_LOW
107708_en_08
8.11

Axioline F: diagnostic parameter register

The diagnostic parameter register provides additional information on the error indicated in
the diagnostic status register. The error code is stored in the diagnostic parameter register,
and the error location is stored in the extended diagnostic parameter register. The error lo-
cation is stored as a slot number. This starts at 1 and corresponds to the sequential number
of the Axioline F modules that are installed one after another.
Special case: If an interface error cannot be located, the value 128 is displayed in the di-
agnostic parameter register (bit 7 is set).
The diagnostic parameter register is rewritten whenever a malfunction occurs. If no mal-
function has been detected, the diagnostic parameter register contains the value 0.
Type Description
BYTE Diagnostic parameter register (high byte)
BYTE Diagnostic parameter register (low byte)
BYTE Extended diagnostic parameter register (high byte)
BYTE Extended diagnostic parameter register (low byte)
System variables and status information
PHOENIX CONTACT
75 / 112
