Ambient conditions
Vibration (storage/transport)
Shock
Shock (operation)
Connection data
Designation
Connection method
Conductor cross section rigid/flexible
Conductor cross section [AWG]
Stripping length
Processor
Processor
Axioline F local bus interface
Number of interfaces
Connection method
Transmission speed
Electrical isolation
Number of supported devices
Ethernet interface
Number of interfaces
Connection method
Note on the connection method
Bus system
Transmission speed
Transmission length
Transmission physics
System limits
Number of supported devices
Number of local bus devices that can be connected
NOTE: Electronics may be damaged if overloaded
Note the logical current consumption of each device when configuring an Axioline F station. This is specified
in every module-specific data sheet. The current consumption can differ depending on the individual module.
The permissible number of devices that can be connected therefore depends on the specific station structure.
PROFINET
Device function
Number of supported devices
Specification
107708_en_08
5g
30g, 11 ms period, half-sine shock pulse, in accordance with
IEC 60068-2-27
10g (bump endurance test in accordance with
DIN EN 60068-2-27)
Axioline F connector
Push-in connection
0.2 mm² ... 1.5 mm²
24 ... 16
8 mm
®
Intel Atom™ x5-E3930 1.3 GHz Dual Core
1
Bus base module
100 Mbps
No
Max. 63
3
RJ45 jack
Auto-negotiation and auto-crossing
RJ45
10/100/1000 Mbps
100 m, max.
Ethernet in RJ45 twisted pair
Max. 63 (per station)
Max. 63 (observe current consumption)
PROFINET controller, PROFINET device
Max. 128 (on PROFINET controller)
Version 2.3
Ordering data and technical data
