11 Device replacement, device defects, and repairs

86 / 112
PHOENIX CONTACT
11.1

Device replacement

The controller can be replaced, if necessary.
If you want to replace a controller in an Axioline F station, follow the steps described in
Section 10, "Removing hardware"
• Disconnect the Axioline F station from the power supply.
• Remove the SD card of the controller to be replaced.
• Replace the controller in your application with an identical controller (same order
number).
Please note:
If the new controller firmware is of a later version than the firmware of the controller to be
replaced, you may have to recompile the project in the PLCnext Engineer software and/or
in the integrated development environment. This procedure is only necessary for certain
firmware versions. For additional information, please refer to the "Change notes for the
controller" application note.
The application note can be downloaded at phoenixcontact.net/product/2404267.
• To adopt the settings stored on the SD card, insert the SD card into the new controller.
• Once the controller is replaced, restore all the necessary connections.
In case you operate the controller with PROFICLOUD connection:
• Delete the controller from PROFICLOUD, as described in the "Startup and operation of
hardware and software components of the PROFICLOUD" user manual.
• Then reregister the controller in PROFICLOUD and add it as a PROFICLOUD device,
as described in Section "Transferring variable values to PROFICLOUD" on page
and Section 4, "Mounting hardware".
107708_en_08
64.
