AXC F X152
Table 8-4 DEVICE_STATE system variable (DEVICE_STATE_X152_TYPE data structure) and the system variables
it contains
System variable
DEVICE_STATE
BOARD_TEMPERATURE
reserved1
reserved2
CPU_LOAD_ALL_CORES
CPU_LOAD_PER_CORE
[1]
[2]
68 / 112
PHOENIX CONTACT
8.6

Device status

The DEVICE_STATE system variable is a system variable organized as a data structure.
The DEVICE_STATE system variable can be used to retrieve various information on the de-
vice status of the controller.
Type
DEVICE_STATE_X152_TYPE
SINT
BOOL
USINT
USINT
CPU_LOAD_PER_CORE_
ARRAY
USINT
USINT
Description
Data structure
Temperature inside the housing (in °C)
Reserved
Reserved
Average current utilization of all processor cores (in %)
Information on the utilization per processor core
Current utilization of processor core 1 (in %)
Current utilization of processor core 2 (in %)
107708_en_08
