VLT® OneGearDrive®
Operating Guide

4.7.3 Dimensions of Assembly Kit for Imperial Shafts

Table 5: Dimensions of Assembly Kit Items for Imperial Shafts [inch]
Type Stainless steel retaining ring
OGD-I1 1.250 x 0.050
OGD-I2 1.4375 x 0.050
OGD-I3 1.500 x 0.050
1 Not included
2 Key length required for b is shown in
min
The dimensions shown could differ from the customer conditions and must potentially be changed by the customer.

4.8 Mounting Instructions

Procedure
1.
Rotate the disk and fit it against the retaining ring. Both items are included in every delivery.
2.
Attach the fixing screw and lock washer (not included).
-
-
The fixing screw and washer required depend on the length and size of the shaft. For further information, refer
to the mounting arrangement (see
e
Illustration 2: Axial Fastening
Illustration 3: Maximum Eccentricity of the Conveyor Shaft
Danfoss A/S © 2020.12
Lock washer
0.375
0.500
0.625
4.10 Dimensions of the Imperial Shaft and
4.6 Mounting
Shaft
b
l
f e
i
h
Fixing screw
(1) (1)
0.500–13 x 1.1875 [M12 x 30]
0.500–13 x 1.3750 [M12 x 35]
0.625–11 x 1.6250 [M16 x 35]
Disk. Adapt the key length according to the shaft length used.
N O T I C E
Arrangement).
d+0.2
[d+0.0078]
x
edges cut
Mechanical Installation
Key
(1)
0.2500 x 0.2500 x 3.937
0.3750 x 0.3750 x 3.937
0.3750 x 0.3750 x 3.937
Disc
n
b max
b min
AQ347551551757en-000101 / 130R0239 | 13
(2)
(2)
(2)
