VLT® OneGearDrive®
Operating Guide
With certain layouts (for example unventilated machines), temperatures on the surface may exceed the limits of DIN EN 563, but still
be within the specified limits for the VLT® OneGearDrive®. If the VLT® OneGearDrive® is installed in a place where it is subject to
intensive contact, the installer or operator must provide protective shielding.
Take care when fitting the shaft with keyway onto the hollow shaft of the VLT® OneGearDrive®. Use the tapped end hole (according
to DIN 332) for axial fixing of the OGD to the conveyor shaft.

4.6.1 Mounting Procedure

Procedure
1.
Fasten the VLT® OneGearDrive® by its flange using the torque arm (see
2.
Attach the VLT® OneGearDrive® to the driven shaft using the means provided.

4.7 Assembly Kit

4.7.1 Overview

1 2
Holding
Illustration 1: Assembly Kit
1 Key, DIN 6885 (not included)
2 Shaft
3 Stainless steel retaining ring, DIN 472

4.7.2 Dimensions of Assembly Kit for Metric Shafts

Table 4: Dimensions of Assembly Kit Items for Metric Shafts [mm]
Type Stainless steel retaining ring
OGD-30 30 x 1.2 mm
OGD-35 35 x 1.5 mm
OGD-40 40 x 1.75 mm
1 Not included
2 Key length required for b is shown in
min
The dimensions shown could differ from the customer conditions and must potentially be changed by the customer.
12 | Danfoss A/S © 2020.12
3 4 5
4.9 Dimensions of the Metric Shaft and
9.7.1 Torque Arm
6
4 Disk
5 Lock washer, DIN 7980 (not included)
6 Fixing screw, fillister head, DIN 912-8.8 (not inclu-
ded)
Lock washer Fixing screw
(1)
10 mm M10 x 30
12 mm M12 x 35
16 mm M16 x 35
Disk. Adapt the key length according to the shaft length used.
Mechanical Installation
Set).
Key
(1) (1)
(2)
A 8 x 7 x 100 mm
A 10 x 8 x 100 mm (2)
A 12 x 8 x 100 mm (2)
