[15] Output shaft material
[16–18] Motor size
[19–20] Reserved
[21–22] Motor connection
[23] Connector position
[24–25] Installation position
[26] Surface coating
[27–30] RAL color code
[31–32] Lubricants
[33–36] Brake
[37] CSA/UL
1 Only OneGearDrive® standard
2 Standard for OneGearDrive® hygienic, optional for OneGearDrive® standard
3 Only OneGearDrive® hygienic
4 Use P2 also for P1
5 Option for OneGearDrive® standard only
10 | Danfoss A/S © 2020.12
I2 1 7/16 inch
I3 1 1/2 inch
1 Mild steel (1)
2 Stainless steel, AISI 316 Ti
L06 Max 2.3 kW (V210)
RX Reserved
TB With terminal box
S2 Motor with plug socket and motor connector, without cable
S3 Motor with plug socket and motor connector, with 5 m cable
S4 Motor with plug socket and motor connector, with 10 m cable
1 Top
P2 Horizontal, connections up or down
P3 Vertical, motor up
A Aseptic (2)
S Standard (1)
9010 Standard
H1 Food grade oil
BXXX Without brake
B180 180 V DC / 400 V AC
B220 220 V DC / 480 V AC
X Without
1 CSA/UL
(2)
(1)
(4)
(5)
(5)
