VLT® OneGearDrive®
Operating Guide

9.6.5.5 I2 Shaft

92.5
[3.64]
37.5
[1.48]
1.3 H13
[0.05]
73.5 73.5
[2.89] [2.89]
185
[7.28]
Illustration 27: Steel/Stainless Steel I2 Shaft

9.6.5.6 I3 Shaft

92.5
[3.64]
37.5
[1.48]
1.422 H13
1.85 H13
[0.07]
73.5 73.5
[2.89] [2.89]
185
[7.28]
Illustration 28: Steel/Stainless Steel I1 Shaft

9.7 Options

9.7.1 Torque Arm Set

Ordering number: 178H5006
The torque arm set consists of the torque arm (see
207.5
[8.17]
185+0.2
[7.28]
A
[0.99]
[0.43]
Illustration 29: Torque Arm
Danfoss A/S © 2020.12
37.5 40.77 +0.2
[1.48]
[1.6051 +0.0078 ]
1.422 H13
[0.056]
37.5
42.393 +0.2
[1.48]
[1.669 +0.0078 ]
[0.056]
Illustration
15
[0.59]
Ø11
A - A
29) and the mounting set (see
A
Specifications
Illustration 30).
AQ347551551757en-000101 / 130R0239 | 35
