3 Product Description

3.1 Overview of the VLT® OneGearDrive®
VLT® OneGearDrive® comprises a high-efficiency permanent magnet (PM) motor coupled to an optimized bevel gearbox. As part of
the Danfoss VLT® FlexConcept®, the drive is an energy-efficient drive system that helps to optimize plant productivity and reduce
energy costs. The VLT® FlexConcept® comprises the VLT® OneGearDrive® combined with a VLT® Decentral Drive FCD 302 or VLT®
AutomationDrive FC 302.
The VLT® OneGearDrive® features a 3-phase synchronous non-salient PM motor with 3 available gear ratios. With an efficiency of
94.9%, the motor achieves the IE5 Ultra Premium Efficiency Class defined in IEC TS 60034-30-2.
The VLT® OneGearDrive® is available in 2 versions:
• Standard: For use in dry and wet production areas.
• Hygienic: For use in aseptic areas.
The VLT® OneGearDrive® is intended for commercial installations, unless otherwise expressly agreed. It complies with the standards
of the series EN 60034/DIN VDE 0530. Use in a potentially explosive atmosphere is forbidden if not expressly intended for this pur-
pose.
Increased safety precautions (for example, protection against access by children's fingers) are required in special cases, such as use
in non-commercial installations. Ensure these safety conditions when setting up the installation.
The VLT® OneGearDrive® is designed for ambient temperatures between –20 °C and 40 °C (68 °F and 104 °F) and for installation
heights up to 1000 m (3280 ft) above sea level. Any deviations found on the nameplate must be considered. Ensure that the condi-
tions at the place of work correspond to all the nameplate data.
3.2 VLT® OneGearDrive® Types
-
The Drive Configurator shows the valid configuration of drive variants. Only valid combinations are shown. Therefore, not all
variants detailed in the type code are visible.
Table 2: Type Code VLT® OneGearDrive®
1–3 4 5 6 7–11
OGD K 2
Table 3: Legend to Type Code
[01–03] Product group
[04] Product variant
[05] Gear type
[06] Size
[07–11] Gear ratio
[12] Output shaft design
[13–14] Output shaft size
Danfoss A/S © 2020.12
N O T I C E
12 13–14 15 16–18
1 L06
OGD VLT
®
S Standard
H Hygienic
K Bevel gear
2 Gear size 2
05K92 5.92
14K13 14.13
31K13 31.13
1 Hollow shaft
30 30 mm
35 35 mm
40 40 mm
I1 1 1/4 inch
19–20 21–22 23 24–25
RX 1
OneGearDrive®
Product Description
26 27–30 31–32 33–36
9010 H1
