4.9 Dimensions of the Metric Shaft and Disk

Table 6: Dimensions of the Metric Shaft and Disk [mm]
Type
a b
min
OGD-30 30 120
OGD-35 35 120
OGD-40 40 120
1 Key length required for b . Adapt the key length according to the shaft length used (b).
min
-
The dimensions shown could differ from the customer conditions and must potentially be changed by the customer.
-
Use grease to mount the VLT® OneGearDrive® onto the shaft. For example, CASTROL Obeen Paste NH1, ARAL Noco Fluid, or
similar. Always use a stainless steel key with the VLT® OneGearDrive® and the stainless steel hollow shafts option.

4.10 Dimensions of the Imperial Shaft and Disk

Table 7: Dimensions of the Imperial Shaft
Type
a b
min
OGD-I1 1.250 4.724
OGD-I2 1.4375 4.724
OGD-I3 1.500 4.724
1 Key length required for b . Adapt the key length according to the shaft length used (b).
min
Table 8: Dimensions of the Imperial Disk
Type
OGD-I1
OGD-I2
OGD-I3
-
The dimensions shown could differ from the customer conditions and must potentially be changed by the customer.
-
Use grease to mount the VLT® OneGearDrive® onto the shaft. For example, CASTROL Obeen Paste NH1, ARAL Noco Fluid, or
similar. Always use a stainless steel key with the VLT® OneGearDrive® and the stainless steel hollow shafts option.

4.11 Torque Restraint

The VLT® OneGearDrive® requires a suitable torque restraint to resist the reaction torque. The torque arm with mounting set is avail-
able as an option (see 9.7.1 Torque Arm
due to the driven shaft running untrue. Excessive backlash can result in excessive shock torques in switching or reversing opera-
tions.
14 | Danfoss A/S © 2020.12
Shaft dimensions [mm]
b c d e f (1)
max
140 8 4 5 100
140 10 5 5 100
140 12 5 5 100
N O T I C E
b c d
max
5.512 0.250 0.138
5.512 0.375 0.214
5.512 0.375 0.211
Disk dimensions [inch]
n
0.1575
0.1575
0.1575
N O T I C E
Set). Ensure that the torque arm does not create excessive constraining forces, for example
g h i k
M10 22 30 3
M12 28 37 3
M16 36 45 3
Shaft dimensions [inch]
e f (1) g h
0.195 5.122 M12 0.866
0.195 5.122 M12 1.102
0.195 5.122 M16 1.417
o
1.236
1.425
1.488
Mechanical Installation
Disk dimensions [mm]
l m n o
1.5 38 4 29.8
1.5 43 4 34.8
2 48 4 39.8
i k l
1.181 0.118 0.059
1.457 0.118 0.059
1.772 0.118 0.079
p
0.512
0.512
0.669
AQ347551551757en-000101 / 130R0239
p
11
13
17
