VLT® OneGearDrive®
Operating Guide
V1
U1
U
U
Illustration 9: CAGE CLAMP Connection
®
Table 9: CAGE CLAMP connections
®
Description
Motor winding
Protective earth
Temperature protection (2) KTY 84-130
1 Do not use the maximum allowed cross-section with a cable lug.
2 When connected to VLT® AutomationDrive FC 302 and VLT® Decentral Drive FCD 302, use analog input terminal 54, KTY sensor 1. For information
about parameter setting and programming, refer to the corresponding Operating Guides.
Table 10: Connections T1 and T2
T1 KTY 84-130
T2
1
Only if connected.
Danfoss A/S © 2020.12
W1
V W PE T1 T2
V W
Inverter output
U
V
W
PE
T1
T2
VLT® AutomationDrive FC 302
Color Typical cross-section
2
Black 1.5 mm /AWG 16
Blue
Brown
2
Yellow/green 1.5 mm /AWG 16
2
White 0.75 mm /AWG 20
Brown
(1) VLT® AutomationDrive FCD 302
KTY sensor 1
Analog input 54
Electrical Installation
Maximum cross-section
2
4 mm /AWG 12
2
4 mm /AWG 12
2
1.5 mm /AWG 16
(1)
AQ347551551757en-000101 / 130R0239 | 19
(1)
