Data I/O PSV5000 Owner's Manual page 97

Items to check Every Week are below
Every week
Programmers
Continued-
Every week
Every week General system
Every week Probe tips, on the
PNP head
PSV5000 Owner's Manual
Additional Features  Maintenance Schedule
To help ensure there are no problems with the
programmer hardware, run the programmers'
Self-test once a week at a minimum; more often is
even better. The Power-On-Self-test (POST), which
sets precision to a laser-trimmed reference, runs
when programmers are powered up. This insures
proper operation of the programmer's voltage
sources.
CAUTION: Possible damage to programmers
and devices! DO NOT TURN AIR OR POWER OFF to
the PSV5000 Machine while a job is running.
A job must be Finished before turning OFF
compressed air or electrical power. Wait for the
gantry to park before turning OFF.
Run the Self-test by either
A) turning the PSV5000 System power OFF properly
and then ON (Shutting Down the PSV5000 System
on page 38), or
B) turning OFF only power to the programmers, and
then ON, with the Programmer Power Switch on the
Power Panel. If there is a programmer issue, a
message will display when the next job is run.
—Refer to the Operator's Manual for switch
locations.
Clean surfaces of equipment and all areas in
workspace with a clean brush, cloth, or dry
compressed air.
• Inspect the Probe Tip to make certain it can
create a good vacuum seal on the device.
Replace if probe tip is worn, cut, or damaged.
•
Clean the PNP Probe tips with alcohol wipes
(Data I/O PN 570-0410-001) or a damp cloth.
Note: Do not touch the probe tip with bare
hands. Finger oils can cause small devices to
stick.
Page
102
Page
103
- 93 -
