Maintenance ■ Tape Output System Maintenance
Lamp Color
None
None
None
T
The Track Jam sensor detects when a
device is not properly seated in the pocket.
This sensor is located on the Adjustable
Loading Track immediately before the
carrier tape enters the cover taping area.
C
The Cover Tape sensor detects when there
is no cover tape on the reel. When the Cover Tape sensor is triggered, a
red LED is illuminated in the Cover Tape Sensor Controller.
- 146 -
Error Messages
T J S
RACK AM ENSOR
Tape Out Unit error message
displays and a red LED
lights in the Device Jam
Sensor.
C T S
OVER APE ENSOR
A
AND MPLIFIER
Error message on the Tape
Out Unit displays and a red
LED is illuminated in the
Cover Tape Sensor amplifier
(left amplifier).
P E S
OCKET MPTY
A
AND MPLIFIER
A Tape Out Unit error
message displays and a red
LED is illuminated on the
Pocket Empty Sensor
amplifier.
J S
RACK AM ENSOR AND
T S
OVER APE ENSOR AND
Possible Resolution
• Use a vacuum tool to seat the device in
the device tape pocket.
• Re-seat the device tape in the Adjustable
Loading Track.
• Use air to blow any debris out of the
Device Jam sensor path.
• Adjust the Device Jam Sensor Controller.
See Track Jam Sensor and Controller
on page 146.
• Replace the empty cover tape reel with a
full one.
• If the reel still contains cover tape, adjust
the Cover Tape Sensor Controller. See
Track Jam Sensor and Controller
• on page 146.
• Adjust the pocket-Empty Sensor. See
ENSOR
"Adjust the Pocket-Empty Sensor as
follows:" on the next page
C
ONTROLLER
A
MPLIFIER
The Track Jam sensor
