Troubleshooting

This section contains solutions to problems that may arise during
operation of the PSV5000.
Troubleshooting for the Tape Output System is covered in a separate
heading; see Tape Output System Maintenance on page 140.
Also, see PSV5000 on-screen Help for a more detailed Troubleshooting
chart.
H
Common Error Messages
Collect all PSV5000 System Logs on page 133
Programming Problems on page 133
Pick and Place Problems on page 137
Air Pressure Problems on page 138
Tray Feeder Problems on page 139
Handler Computer Failure on page 139
Common Error Messages
Lamp Color
Red
Red
PSV5000 Owner's Manual
EADINGS BELOW COVER THESE TOPICS
Error Messages
• Cannot connect to the
motion controller.
• E-STOP
ACTIVATED but the
OK button is grayed
out (unavailable)
Troubleshooting  Common Error Messages
:
Possible Resolution
• Check that both Emergency Stop buttons are
OFF.
• Check that all safety doors are closed.
• Properly shut down the PSV5000 Machine if
possible, and restart the system.
• heck that both E-Stop buttons are
released.
• Check that all safety doors are closed.
• If a restart is necessary, press Ctrl + Alt + Del
on the keyboard
