PSV5000 Owner's Manual
Preface•- 1 -
Using this Manual•- 1 -
Warnings and Cautions•- 1 -
Safety Symbols•- 2 -
Symbols for Specific Models & Options•- 3 -
Precautions for Safe Operation•- 4 -
Contacting Data I/O•- 6 -
Repair Service•- 7 -
C O
HAPTER NE
Introduction•9
Snapshot of PSV5000•10
System Description•12
Machine Components•19
Software•25
Room Consideration•29
C T
HAPTER WO
Setup•33
Machine Installation•33
Applying Power for the First Time•37
Setting Up Input and Output Media•40
Setting Up the Laser Marking Module•55
C T
HAPTER HREE
Administrative Functions•60
Safety Message and Precautions•62
Administrator Functions•63
Maximizing Programming Yields•77
(Optional) Creating a Data File from a Master Device•80
Marking Option•80
Additional Features•89
C F
HAPTER OUR
Maintenance•91
Self-Service Spares Kit•97
Workspace, Head and Gantry•98
Pick and Place Probe•103
Programmers•119
The Laser Module and Shuttle•124
