Maintenance ■ The Laser Module and Shuttle
9. Remove four screws (3 mm hex key) from the bottom side of the
Figure 76:
10. Open the front or back safety door to access the workspace.
11. Lift up on the target programmer being cautious of the cables that will
Replacement is in the reverse order of removal.
The Laser Module and Shuttle
[Laser Marking only] Laser Marker System is optional equipment on
your PSV5000 Programming System. The Laser Module employs a laser
shuttle (except when using Tape Output) and includes a fume extractor.

The Laser Module

The Laser shuttle transports devices to and from the lasing area.
R
- 124 -
programmer (two nearside, two farside). One screw might also hold a
cable tie which must be cut first. Save the cable tie mount for reuse
(as well as the screws).
Inside the machine looking up at the programmers.
There are four attachment screws (circled) per programmer.
FlashCORE shown,
farther apart.
come out with it.
EQUIREMENTS
• Disposable gloves and protective goggles
• Sealable Plastic bags
but LumenX is similar, with screws
