Maintenance ■ The Tray Feeder
NOTE: The Pocket-Empty Sensor must be reset for each new device type
to be taped.
The Tray Feeder
The Automatic Tray Feeder is optional equipment to the
PSV5000 System. It is a high-speed tray exchanger, delivering JEDEC
trays to pick and place positions.
Information not found here, but important, can be found in the Tray
Feeder Operation Manual, such as the location of possible pinch points.
Cleaning and Inspecting the Tray Feeder
[Tray Feeder only]
1. Stop or Pause a job if one is running.
2. Check the automatic Tray Feeder for damaged or broken parts and
3. Visually inspect the shuttle belts for dirt, nicks, or other signs of
4. If the shuttle belts are dirty, clean with dry, compressed air and wipe
5. Check that the shuttle/elevator is clean and that trays lay flat.
Electrical Equipment Disposal
Notice
be recycled or reused, or otherwise properly disposed of according to the
European Union's WEEE Directive. You may also dispose of it yourself in
accordance with the European Union's WEEE Directive.
Data I/O will collect this equipment at no cost to the equipment owner
and process it accordingly. (This includes auxiliary equipment that came
with your PSV5000 System such as Tape-Out Module, and Tray Feeder.)
- 148 -
9. Press and release the SET button again.
replace as necessary.
damage.
with a dry, lint-free cloth and isopropyl alcohol.
For customers in the European Union, this symbol displayed
on your Data I/O product indicates that the item must NOT
be discarded with general municipal waste. Either return
products displaying this symbol to Data I/O so that they may
Data I/O ■ 096-0465-001C
