Data I/O PSV5000 Owner's Manual page 49

Figure 22:
4. Loosen the lower right screw.
5. Rotate the shield up 90° clockwise and fasten in place at the extra
6. Get the Tray Feeder fasteners ready, and a 5 mm hex key.
fasteners. Use caution.
7. With two people lifting the Tray Feeder, slide the nose into the shield
PSV5000 Owner's Manual
■ Setting Up Input and Output Media □ Setting Up an Automatic Tray Feeder
The safety shield for the Tray Feeder has been rotated
out of the way and fastened in the 'storage' position with the two
screws (arrows).
hole with the screw removed earlier.
CAUTION: Heavy equipment! The Tray Feeder weighs 30 kg (66 lb.).
Two people are required to lift it. A third person is needed to attach
opening and far enough in to accommodate the mounting holes on
the machine base plate.
- 45 -
