Setting Up the Laser Marking
Module
Preparation:
1.
2.
3.
4.
5.
6.
PSV5000 Owner's Manual
Make sure a USB dongle for the laser has been updated.
Upgrade CH700 to V2.3 by installer.
Copy CH700.exe (v2.3.2) from
1071\Software\CH700 v2.3.2
Update below values in the package file
5. #134 1500
6. #137 0
POWER OF CUP2 BASED ON CUP1
7. #138 0
CUP2 IN X DIRECTION
8.
#139 -42000
AND CUP2 IN Y DIRECTION
Start 'MarkingMate.exe.'
Click a blank space on work area, and then at the Property Table,
click Work Area tab, and click Lens Correction to open the Lens
Setup dialog.
■ Setting Up the Laser Marking Module □ Preparation:
\\sol\ProjDocs\PSV5000 -
to C:\CH700
MSEC, LASER SHUTTLE MOVING TIME
NUM, INCREASE OR DECREASE LASER
NUM, DISTANCE BETWEEN CUP1 AND
NUM, DISTANCE BETWEEN CUP1
to replace exe of v2.3.
