GRAPHTEC midi LOGGER GL350 Service Manual page 41

Setting procedure
(1) Load the condition settings files from the PCMCIA card.
Condition settings files
Measurement procedure (
(1) Load the condition settings file for type T as described above.
(2) Connect to the zero controller with the (T) compensation leads.
(3) Use the voltage generator to successively input the reference voltage signal for each range to the 0˚C
reference temperature device (zero controller) according to the table below, then check that the level of
measurement is within the rating.
Input voltage precision ratings (Type T)
Temperature
0 ˚C
200 ˚C
390 ˚C
-200 ˚C
(4) Connect (K) compensation leads to each amp.
(5) Load the condition settings file for type K as described above.
(6) Input the reference voltage signal for each range to the 0˚C reference temperature device (zero
controller) according to the table below, then check that the level of measurement is within the rating.
Input voltage precision ratings (Type K)
Temperature
0 ˚C
1200 ˚C
-190 ˚C
GL400-UM-251-9370
:CondT.CND
:CondT50-1.CND
:CondT50-2.CND
:CondK.CND
:CondK50-1.CND
:CondK50-2.CND
temperature accuracy)
Input voltage
0.000 mV
9.288 mV 198.8 ˚C to 201.2 ˚C
20.255 mV 388.7 ˚C to 391.3 ˚C
-5.603 mV -197.8 ˚C to -202.2 ˚C
Input voltage
0.000 mV
48.838 mV 1197.9 ˚C to 1202.1 ˚C
-5.730 mV -187.5 ˚C to -192.5 ˚C
5-8
5. INSPECTION AND CHECK PROCEDURES
← Condition settings for the T range accuracy
(for the 10-Ch and 20-Ch terminal unit)
← Condition settings for the T range accuracy
(for ch3, 8, ,13, 18, 23 of the 50-Ch terminal unit)
← Condition settings for the T range accuracy
(for ch23, 28, 33, 38, 48 of the 50-Ch terminal unit)
← Condition settings for the K range accuracy
(for the 10-Ch and 20-Ch terminal unit)
← Condition settings for the K range accuracy
(for ch3, 8, ,13, 18, 23 of the 50-Ch terminal unit)
← Condition settings for the K range accuracy
(for ch23, 28, 33, 38, 48 of the 50-Ch terminal unit)
Standard
-1.0 ˚C to +1.0 ˚C
Standard
-1.5 ˚C to +1.5 ˚C
