(5) Remove the four M2.6L6 binding head screws holding the main board and the remove the main board
from the bottom case assembly.
M2.6L6 binding
head screw
Main board
Re-assembly
(1) Re-assemble the main board in the reverse order in which it was disassembled.
(2) Set up the GL450/400/350 when you replace any of the boards.
GL400-UM-251-9370
3. DISASSEMBLY AND REASSEMBLY
3-5
Spacer for GL350
Insert this side first when
installing the main board to
the bottom case assembly.
