Microsd Connector Cn13; Usb Otg1_Hs Micro-Ab Connector Cn14; Table 29. Microsd Connector Cn13; Figure 13. Microsd ™ Connector (Top View) - ST STM32H757I-EVAL User Manual

7.11 ™
microSD
Pin number
1
2
3
4
5
7.12

USB OTG1_HS Micro-AB connector CN14

UM2525 - Rev 3
connector CN13
Figure 13.
Table 29.
Description
SD_DATA2
SD_DATA3
SD_CMD
+2.9V_SD
SD_CLK
Figure 14. USB OTG1_HS Micro-AB connector CN14 (front view)
™
microSD connector (top view)

microSD connector CN13

Pin number
6
7
8
9
10
UM2525
microSD™ connector CN13
Description
Vss/GND
SD_DATA0
SD_DATA1
GND
MicroSDcard_detect
(MFX GPIO15)
page 32/69
