5. Set switch to NORMAL position.
6. Using a D4BY (single-ended) modular cord, connect D-181321 kit of
parts (Figure 2-56) to a KS-22911, L2 power supply (-48V dc).
7. Connect terminals -V and GRD on 278A adapter to D-kit.
If background music is desired, connect terminals Ml and M2 on the
8.
278A Adapter to the customer-provided music source.
Connect the 278A adapter to a 103A connecting block, using 4-pair
9.
inside wiring cable. Make the following connections:
10. Using a D4BU cord, connect the paging system to the connecting
b l o c k .
11. If you are installing a PagePac system, connect the speakers to the
receptacle on the back of the PagePac system.
278A Term. 103A Term.
CT 1
CR 2
5
C1
C2 6
INSTALLATION
2-125
