4. After the basket has cooled, flip the basket over and install
the included Rekluse 35 mm retaining ring into the groove on
the Rekluse center hub.

INSTALL THE CLUTCH PACK

1. Install a Rekluse steel drive plate 1
then install an OE friction disk.
Note: Check that the OE frictions meet the minimum
specifications before installing them into the clutch pack. If OE
frictions do not meet specifications, replacements can be
purchased from your local dealer.
• Minimum allowable thickness = 0.0835" (2.12 mm)
2. Continue to alternate Rekluse steel drive plates with OE
friction disks.
Rekluse steel drive
st
plate – 1
Alternate Rekluse steel drive plates with OE frictions
OE friction disk
in
Doc ID: 191-6206A
Doc Rev: 062818
st
into the clutch basket,
Total Clutch Pack
9 steel drive plates
8 OE friction disks
