Two Ways To Check For Free Play Gain - Rekluse CoreEXP 3.0 Installation Manual

Lever position
Lever with "slack"
around 4,000 RPM
removed
Free Play Gain
1/8"-1/4" (3 mm-6 mm)
lever movement
Optimal Free Play Gain yields 1/8"-1/4" (3 mm-6 mm) of
clutch lever movement, measured at the ball end of the lever.
This measurement at the lever correlates to achieving the ideal
installed gap.

Two Ways to Check for Free Play Gain

The following steps explain 2 ways to check Free Play Gain. One
way uses the rubber band Rekluse includes in the clutch kit, and
one uses your hand. You can use either method to check for Free
Play Gain.
Doc ID: 191-6206A
Pg. 30
Doc Rev: 062818
