ELCOM Euro-2000T Alpha Service Manual page 46

4.12. Peripherals to mainboard connection.
4.12.1. Euro-2000T Alpha peripherals to mainboard connection.
Note: Be sure the ECR is turned off.
1) Switch off the ECR and unplug the external adaptor.
2) Remove the top cabinet.
3) Remove the lead acid accumulator (see 4.2).
4) Connect, resp. check the connection according to table below. Be sure connectors contact well.
5) Replace lead acid accumulator and fasten it. (see 4.2).
6) Connect the accumulator connector to mainboard Battery connector.
7) Replace the top cabinet (see 4.1.)
8) Execute all the tests (chapter 6).
7
No. Quantity
1 1 Winding motor connector w ith cable
2 1 Multif unctional connector D-SUB 15F
3 1 Scanner connector and cable to D-SUB
4 1 Pow er sw itch connector w ith cable
5 1 PC connector and cable to D-SUB
6 1 Adaptor connector w ith cable
7 1 Printer motor LT-286 connector and cable
8 1 Printer LT-286 connector and cable
9 1 FM connector and cable
10 1 Paper end sensor connector and cable
11 1 Keyboard connector and cable
12 1 Accumulator connector and cable
13 1 External keyboard connector and cable
46
Euro-2000T Alpha/1000T
1
8
9
10
11
Part nam e
Service manual
2
3
13
Conne ctor
Code
on m ainboard
KON03F W-MOTOR
KON03F DRAWER
KON01F SCANNER
KON06F SW-POWER
KON01F PC
KON10F POWER
part of printer PRINTER 2
KON05F PRINTER 1
KON12F FISCAL MEMORY
KON13F PAP-PRES
KON05F KEY BOA RD
KON11F BATTERY
KON13F EXT KEY B
© Elcom s.r.o.
4
5
6
12
Code
KON03M
KON03M
KON01M
KON06M
KON01M
KON10M
KONMOLEX10
KON05M
KON12M
KON13M
KON05M
KON10M
KON13M
