btsr SMART MATRIX WINDINGFEEDER Operating Manual page 54

Parameters programmable on
Parameter Possible range
TENSION ERR. 0.1 to 50 or "A"
TIME ALARM 0.1 to 50, "A", OFF
K-PID 1 to 5
RAMP UP 1 to 250
RAMP DOWN 1 to 250
K FACTOR -20.0 to 20.0
AUTO OFFSET
disabled
EDITOR LOCKED
disabled
WINDINGFEEDER OFF disabled
YARN TYPE ALL YARNS, ELASTIC
APPLICATION REWIND 1/2, WARP 1/2
*
Corresponding parameter of WINDINGFEEDER device.
(**) Unlike the TARGET CALIBRATION, which can be set for each individual device, the K FACTOR
parameter is the same for all the involved devices. Setting a negative value, the TARGET value will be
decreased by the set percentage; otherwise, setting a positive value, the TARGET value will be increased by
the set percentage.
Parameters programmable on
Parameter Possible range
SENSOR TYPE 100 cN or 1000 cN
ROTATION CW or CCW
UNICO MODE AUTO or OFF
ALARM STOP NO or NC
TARGET STOP NO or NC
P1/P2 INPUT NO or NC
RESET INPUT NO or NC
EXC NO or NC
DISPLAY NORMAL or FLIP
*
Corresponding parameter of WINDINGFEEDER device.
For more detail about the indicated operation/control parameters, please refer to WINDINGFEEDER
manual.
Summary Tables of Style Programming Parameters
ADV window (STYLE EDIT
Default
0.5
2.0
3
40
40
0.0
, enabled
, enabled
, enabled
ALL YARNS
REWIND1
CONFIG window (STYLE EDIT
Default
100 cN
CW
AUTO
NO
NO
NO
NO
NO
NORMAL
SMART MATRIX WINDINGFEEDER
function)
Meaning
Tolerance beyond which an alarm will be generated
Time for which the tension may exceed the tolerance.
Constant value of the device reactivity
Tension increase ramp
Tension decrease ramp
TARGET correction factor compensating possible yarn slipping
(**)
Auto Offset function enabled/disabled
Parameter progr. on WINDINGFEEDER enabled/disabled
WINDINGFEEDER device enabled/disabled
Type of yarn used (normal or elastic)
Type of application used
function)
Meaning
Type of TS44 sensor
Motor rotation direction: CW or CCW
Automatic detection of option intelligent accessory
Stop Alarm Output polarity
Stor Target Output polarity
Polarity of P1 e P2 inputs
Polarity of Reset input
Polarity of EXC input
Image rotation of WINDINGFEEDER device
*
P1.2
P1.3
P2.4
P2.2
P2.3
-
P3.1
-
-
P4.5
P4.4
*
P4.2
P4.1
P4.8
P4.7
P4.7
P4.7
P4.7
P4.7
-
