Summary Tables of Style Programming Parameters

Parameters programmable on
Parameter Possible range
TENSION MODE PROFILER or P1/P2
START METER 1 to 50,000 or OFF
START TENS 0.2 to 99.5 or OFF
WORK TENS 0.2 to 99.5
INC/DEC METER 1 to 100.000 or OFF
INC/DEC TENS -99.5 to 99.5 or OFF
TARGET METER 1 to 1.000.000 or OFF (**)
TARGET TENS 0.2 to 99.5 or OFF
*
Corresponding parameter of WINDINGFEEDER device.
Notes:
In the PROFILE window you may either enable or disable the TENSION PROFILER function, i.e. the
dynamic trend of the yarn feeding tension from the machine Startup
If you enable the PROFILE
to the remaining parameters.
If, on the contrary, you set
and the WINDINGFEEDER devices will work only with the tension values
WORK TENS P2 (P2.1).
For more details about the TENSION PROFILER function, please refer to the examples shown on next
pages.
(**)The value set on "TARGET METER" can be modified by the user (device by device), in such a way as to
compensate possible slipping between yarn and WINDINGFEEDER device wheel.
During the style saving, the question: "EDIT TARGET CALIBRATION?" will appear; by answering "YES" you
can introduce a correction factor (%) for each device.
Summary Tables of Style Programming Parameters
PROFILE window
Default
PROFILER
OFF
20.0
10.0
OFF
0.1
50,000
OFF
option in TENSION MODE, then the tension trend will depend on the values set
P1/P2 in TENSION MODE, then some parameters will automatically be disabled,
SMART MATRIX WINDINGFEEDER
(STYLE EDIT function)
Meaning
Choice between PROFILER or P1/P2 operating modes
No meters for which the START TENS will be applied.
Yarn tension at the position Startup
Yarn tension after the No meters defined in START METER
Increment/decrement steps of "WORK TENS"
Amount of increment/decrement of "WORK TENS"
Total number of yarn meters to wind.
Yarn tension when reaching the TARGET
(START
WORK TENS P1
TENS) up to the Target.
(P1.1) and
*
-
-
-
P1.1
-
-
-
-
- 41 -
