Style Modify
The Style Modifying function is basically identical to the Programming a New Style function.
The main differences are the following:
1) once you have activated the
you want to modify (e.g. APPLICATION01) and press
2) the bottom line of STYLE NAME
reference name (APPLICATION01) instead of the default name (WINDINGFEEDER).
If you change the style currently loaded on particular Windingfeeder devices (indicated by the diskette
symbol) the changes will be automatically loaded on the relevant Windingfeeder devices.
Style Clearing
This function allows you to remove a style from the database.
STYLE EDIT window from Main menu, choose from the database the style
Execute all the steps described on Programming a New Style
sequence, to bring all the desired changes with respect to the
reference style: APPLICATION01.
screen that contains the style name setting keyboard, will show the
Once you have activated the
function from main menu, choose the style you
want to remove (e.g.: APPLICATION01)
Press CLR
Confirm the operation.
The
the database.
SMART MATRIX WINDINGFEEDER
MODIFY
Enter the name to be assigned to the modified
style.
To save the new style
APPLICATION01 style will be removed from
Style Programming
STYLE EDIT
