4.9 Pressure Temp Module, M-PT Output Signals

The signal output connector on the Pressure Temp Module, M-PT can be used to interface some
models of IABPs to the Anesthesia Monitor/Critical Care Monitor. The pin assignments are
illustrated in table 4-12. Please contact your local distributor for more information.
WARNING Always make sure that the combination complies with the international safety
standard IEC 60601-1-1 for medical electrical systems and with the
requirements of local authorities.
Table 4
Pin
1
2
3
4

4.9.1 Analog Outputs

The analog output signals are:
ECG (ECG1)
The ECG signal is 1 V/1 mV with a delay of approximately 10 ms. The signal requires an input
impedance of 100 kΩ.
NOTE: The ECG signal is based on the ECG measurement of the ESTPR Module, M-ESTPR (all
variations), and of the NESTPR Module, M-NESTPR (all variations). ECG signal from the module is
channel 1 (ECG1). The channels 2 and 3 (ECG2, ECG3) are not transmitted. Make sure that the
signal in channel 1 (ECG1) is good enough (extensive QRS for IABP synchronization). For further
information, please contact your authorized Datex-Ohmeda distributor.
Invasive Pressure (P3)
The Invasive pressure output signal is 1 V/100 mmHg originally ranging from 0 to 300 mmHg and
with a delay of approximately 25 ms. The signal requires an input impedance of 100 kΩ.
54
Document No. 896 623
Signal Output Connector Pin Assignments
Signal
ECG out, ECG1
Pressure out, P3
ECG out, ECG1
Ground
