Datex-Ohmeda AS/3 Compact Monitor, CS/3 Compact Monitor

3.14 Troubleshooting

If a problem occurs during the functional examination, check the components of the monitor
according to the following troubleshooting chart. If the problem persists, please refer to the part II.
TROUBLE
Nothing functions
A plug-in module does
not function
The airway module does
not function
44
Document No. 896 623
TREATMENT
Unplug and replug Remote Controller Cable. Also confirm that the cable is intact.
Unplug and replug the Power Cord. Also confirm that the cable is intact.
Confirm that the fuses are intact.
Remove and replace the module.
Confirm that the desired parameters are configured to be displayed.
Confirm that "Occlusion" or "Calibrating Gas Sensor" messages are not displayed.
Confirm that a D-fend water trap and a sample tube are attached.
Confirm that the desired parameters are configured to be displayed.
Remove and replace the module.
