3.10.4 Returning Gas to Patient Circuit

The sampling gas can also be returned to the patient circuit. If you use the Datex-OhmedaAS/3
Anesthesia Delivery Unit (ADU), you need an optional adapter connected to the patient breathing
tubes.
Figure 13

3.11 AS/3 Anesthesia Keyboard, K-ARK

To connect AS/3 Anesthesia Keyboard, K-ARK to the Compact Monitor:
1.
2.

3.12 Remote Controller, K-REMCO

To connect a Remote Controller, K-REMCO to your Compact Monitor you need a Remote Controller-
Compact Monitor Cable. For further information, please contact your authorized Datex-Ohmeda
distributor.
Sample Gas Return to Patient Circuit in ADU
Make sure that the power is turned off on the Compact Monitor.
Connect the Keyboard-LCD Display Cable to the K-ARK connector on the display and to the
connector on the rear of the keyboard. Secure the connection with the thumb screw and slip
the cable beneath the fasteners.
