Datex-Ohmeda AS/3 Compact Monitor Technical Reference Manual page 74

Datex-Ohmeda AS/3 CM and CS/3 CMC
45.
?
EEG Module, M-EEG and EEG Headbox, N-EEG
46.
?
47.
?
Pressure/Pressure Temp Modules, M-P/-PT
48.
?
Invasive blood pressure measurement
49.
?
66
Document No. 896 623
Attach an adult NIBP cuff onto your arm and perform one NIBP measurement. Check the
module identifies the cuff, i.e. the text 'Adult' appears in the NIBP digit field for a short time.
Check that the module gives a reasonable measured result.
Enter the EEG module service menu:
Monitor Setup
- Install/Service (password 16-4-34) -
Service (password 26-23-8) - Parameters - More... - EEG & EP
Select Module.
Check that the 'Mod Mon Timeouts', 'Mod Mon Bad checksums' and 'Mon Mod Bad
checksums' values in the module view are not increasing faster than by 50 per second.
Check that the memories of the module have passed the internal memory test, i.e. 'RAM',
'ROM' and 'EEPROM' all state OK.
Plug in the earphones to the headbox. Be careful with load stimulation from the earphones
when starting AEP stimulation. Start AEP stimulation by pressing the
the module. Check that the clicking sound comes from the earphones in 1.1 Hz frequency.
Stop the stimulation by pressing again the
the clicking stopped.
Enter the P/PT module service menu:
Monitor Setup
- Install/Service (password 16-4-34) -
Service (password 26-23-8) - Parameters - P/PT
Check that the 'Timeouts', 'Bad checksums' and 'Bad c-s by mod' values are not increasing
faster than by 50 per second. Check that the PT board memories have passed the internal
memory test, i.e. 'RAM', 'ROM' and 'EEPROM' all show OK.
Check the module membrane
Press the key for at least one second. Check that the key being pressed is identified, i.e. the
text in the service menu for 'Button' changes from OFF to ON.
EP Start/Stop
Zero P3
key.
EP Start/Stop
key on the module. Check that
key on
