Memory Board, B-CMMEM/ Memory Module, M-MEM
72.
Monitor Setup
?
73.
?
74.
Check that 'Interface status' states Active continuously and the error counter values on the
?
75.
Insert the Memory card labeled 'Menu' in the left-hand side memory card slot. Check that the
?
76.
?
Enter the MemCards service menu:
- Install/Service (password 16-4-34) -
Service (password 26-23-8) - Frame - MemCards
Check that the module is recognized properly, i.e. 'Present' and 'Active' state YES.
Check that the Memory board memories and the PCMCIA controller have passed the tests.
The status for each should be OK.
Select Communication.
bottom part of the menu are stable.
Select Status.
message 'Menu Card inserted' appears onto the message field and the white menu card
symbol on the upper right hand corner of the screen appears within 1 minute.
Wait until the information regarding SLOT1 is fully updated in the service menu then check
that the 'Card type' states MENU and the 'File system' ATA.
Check that the rest of the information for SLOT1 is reliable and no errors have been
detected.
Insert the Memory card labeled 'Data' in the right-hand side memory card slot. Check that
the message 'Data Card inserted' appears onto the message field and the green menu card
symbol on the upper right-hand corner of the screen appears within 1 minute.
Wait until the information regarding SLOT2 is fully updated in the service menu then check
that the 'Card type' states DATA and the 'File system' ATA.
Check that the rest of the information for SLOT2 is reliable and no errors have been
detected.
