Datex-Ohmeda AS/3 Compact Monitor, CS/3 Compact Monitor
Ni-Cd
Other Symbols
4
Document No. 896 623
This battery contains Ni-Cd and it can be recycled.
Dangerous voltage
When using the ARK Barcode Reader, N-SCAN, do not stare into beam. The N-SCAN
Barcode Reader is a Class 2 laser product.
Attention, consult accompanying documents.
When displayed beside the O
%.
When displayed next to the HR value, indicates that the pacer is set on R or a wide QRS
is selected.
On the Interface Module M-INT, indicates that it is for connecting external devices. Do
not connect patient cables to the module.
On the rear panel of the monitor indicates the following warnings and cautions:
• Electric shock hazard. Do not open the cover or the back.
Refer servicing to qualified personnel.
• For continued protection against fire hazard, replace only with same type
and rating of fuse.
• Disconnect power supply before servicing.
Type BF (IEC-601-1) protection against electric shock
Type BF (IEC-601-1) defibrillator-proof protection against electric shock
Type CF (IEC-601-1) protection against
electric shock
Type CF (IEC-601-1) defibrillator-proof protection against electric shock
Gas outlet (in airway gas models only)
Ethernet connectors
When displayed on the upper left corner of the screen, indicates that the alarms
are silenced. When in the menu or digit fields, indicates that the alarm source has
been turned off.
Equipotentiality. Monitor can be connected to potential equalization conductor.
value, indicates that FiO
2
low alarm limit is set below 21
2
