Controller Box Dimensions

Dimension
Width
Length
Depth
Weight
Operating Temp. Range
Frequency
Supply Voltage
Max. Amps
Power Supply
IP Rating
Table 2-1. Tunnel Master Jr. Controller Dimensions, Measurements, and Ratings

Entry Keypad Dimensions

Dimension
Width
Height
Depth
Weight
Operating Temp. Range
Frequency
Supply Voltage
Max. Amps
Power Supply
IP Rating
Table 2-2. Tunnel Master Jr. Keypad Dimensions, Measurements, and Ratings
Page 4 - Tunnel Master® Jr. User Manual
Amount
27 3/8" —
15 3/8" —
6 3/8" Includes the plastic face.
48 lbs. Inclusive of the box, board, and door.
32 °F to 122 °F —
0 °C to 50 °C
50/60 Hz. —
120 VAC —
6.0 Amps. —
6.0 Amps. Power must come from a dedicated 6-Amp. breaker
IP40 The Tunnel Master® Jr. is rated for protection against
solid objects up to 1mm diameter and not protected
against liquid.
Amount
9 3/8" —
7" —
2 5/8" Includes the plastic face.
3 lbs. Inclusive of the box, board, and door.
32 °F to 122 °F —
0 °C to 50 °C
50/60 Hz. —
12 VAC —
.02 Amps —
.02 Amps Power must come from a dedicated ICS transformer.
IP65 The Tunnel Master® Jr. is rated for total protection
against dust and strong jets of water from all directions,
limited ingress permitted.
