Chapter 1: Introduction

This document was written for the installation of the Tunnel Master® Jr. (also known as the

TMJ) to assist technicians, electricians, and operators. A thorough understanding of electrical

wiring, installation, codes, and safety protocols is required. Additionally, some familiarity with

car wash tunnel equipment and installation is recommended. No prior experience with the

Tunnel Master® Jr. This guide should be supplied to the electrician prior to the installation of

conduit and wiring to ensure the TMJ is installed properly. Faulty installations are the major

cause of system malfunctions. The Tunnel Master® Jr. system must be installed exactly as

described in this manual to ensure its reliability and proper operation.

WARNING: Failure to properly install the Tunnel Master Jr. system will void the warranty.

Innovative Control Systems provides technical support for customers and installers:

Many of the TMJ system features were integrated at the request of current car wash operators.

We welcome your feedback and want to assure you that ICS will always remain committed to

being the industry leader in car wash controller and management systems.

By following the procedures in this manual, you should be able to perform the following:

Install the Tunnel Master® Jr. system-level wiring

„

Install the Tunnel Master® Jr. communications wiring

„

Configure your wash settings and features

„

Process vehicles through your wash

„

View car counts

„

View historical information

„

Track sales

„

Print reports

„

Troubleshoot problems if they occur

„

Provide a comprehensive, easy-to-use system reference guide

„

Enable operators and their employees to obtain the maximum value from the system

„

Furnish operators with a tool for training their employees on the Car Wash Controller

„
