Output Settings

Follow these procedures to set or change the settings for the Outputs in the Tunnel Master® Jr.
Controller software.
Step Action
1 Press the MENU button from the
main screen display.
2 Press the number 3 key to select the
Configure Wash menu option.
3 Press the number 2 key to select the
Outputs menu option.
4 From the numeric keypad, type the
desired number for the output.
NOTE: Review button functions on
page 31.
Press the ENT button on the display
5
keypad to advance to the next
setting.
6 From the numeric buttons, type the
number of the Output.
7 Press the ENT button on the display
pad to advance to the next setting.
8 Using the numeric buttons enter
the Start time in inches or pulses
depending on the wash setting
selection.
Page 41 - Tunnel Master® Jr. User Manual
Screen Displays
[1] Bump Shift [4] View Counts
[2] Wet Down Wash [5] Print Reports
[3] Configure Wash
[1] Services [4] Wash Settings
[2] Outputs [5] Set Date Time
[3] Output Lists [6] Set Password
Output _ _ Name _ _ _ _ _ _ _ _ _ _ Start _ _ Type _ Part _ _
Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Service 01 Name Price Type Rate
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Output 01 Name
Start _ _ Type _ Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Output 01 Name Roller
Start _ _ Type _ Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Output 01 Name Roller
Start _ _ Type _ Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Output 01 Name Roller
Start 0084 Type _ Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Chapter 4: Wash Configuration
