ICS Tunnel Master Jr. User Manual page 46

Step Action
Press the ENT button on the display
9
pad to advance to the next setting.
10 Repeat steps 8 and 9 until the
settings for Type, Part, Flash, Extend,
Look, and Wet are completed.
Press the ENT button on the display
11
pad to advance to the Panic setting.
12 From the 0 button on the numeric
keypad, advance to the desired
setting, either Y for yes or N for no.
13 Press the ENT button on the display
pad to advance to the second setting
in the Panic option.
14 From the numeric keypad, type the
number of seconds of delay for this
relay to turn on before the conveyor
will restart.
NOTE: If you do not wish this relay to
stagger start, enter 0.
15 Press the F4 button to save the
service.
16 Press the MENU button to return to
the previous menu screen.
Table 4-9. Outputs Menu
Chapter 4: Wash Configuration
Screen Displays
Output 01 Name Roller
Start 0084 Type _ Part _ _ Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Output 01 Name Roller
Start 0084 Type R Part AC Flash N Extend 000 Look 000 Wet N
Panic N - 0
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Output 01 Name Roller
Start 0084 Type R Part AC Flash N Extend 000 Look 000 Wet N
Panic N - 0
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Output 01 Name Roller
Start 0084 Type R Part AC Flash N Extend 000 Look 000 Wet N
Panic N - 0
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Output 01 Name Roller
Start 0084 Type R Part AC Flash N Extend 000 Look 000 Wet N
Panic N - 0
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Output 01 Name Roller
Start 0084 Type R Part AC Flash N Extend 000 Look 000 Wet N
Panic N - 0
F1=PREV F2=NEXT F3=ERASE F4=SAVE
Output _ _ Name _ _ _ _ _ _ _ _ _ _ Start _ _ Type _ Part _ _
Flash _
Extend _ _ _ _ Look _ _ _ Wet _ Panic _ - _ _
F1=PREV F2=NEXT F3=ERASE F4=SAVE
[1] Services [4] Wash Settings
[2] Outputs [5] Set Date Time
[3] Output Lists [6] Set Password
Tunnel Master® Jr. User Manual - Page 42
