Hardware Features

The Tunnel Master® Jr. hardware is designed to withstand the harsh environments and hard
use of a busy car wash. As an ICS customer, you benefit from a thoroughly researched and
developed car wash controller. This manual will enable the operator to have an active part in
the control and operation of your car wash facility with the many Tunnel Master® Jr. features:
24 programmable, fused outputs, upgradeable to 72, each with two independent circuits.
„
24 VAC and 120 VAC.
„
Programmable flashing relay.
„
Exclusive, patented anti-theft feature to prevent unauthorized processing of car washes.
„
Input for Pulse, Gate, Tire, Roller Locater, Entrance Management, and Panic circuits.
„
Auto Pulse feature allows pulse simulation in the event of pulse switch failure.
„
Auto Gate feature allows gate switch simulation in the event of gate switch failure.
„
Exterior indicators for easy troubleshooting.
„
16 programmable service buttons on the entry keypad, upgradeable to 32.
„
Automated wet down feature for easy startup.
„
Optional report and/or receipt printers.
„
