Input 5
Input 6
Input 7
Input 8
Figure 2-16. Push Button Wiring First 8 Buttons
Chapter 2: Hardware Installation
TM Junior Push Button Wiring
First 8 buttons (4 Rows and 4 Columns)
Service 1
Service 2
Service 3
Service 4
24VAC
Inputs 1-8
Common
Service 5
Service 6
Service 7
Service 8
Tunnel Master® Jr. User Manual
- Page 19
