Change Service and/or Add Retract

To modify a car's service in the stack, follow these instructions:
1. On the keypad, press the AC button.
The flashing lights indicate how many cars are in the stack. The lights flash for 5 seconds. Number 1 being
closest to the tunnel entrance.
2. Press to select the numeric button that represents the car in the stack you would like to modify.
The service that is selected for that car will light up on the keypad.
3. If necessary, press to select the numeric button of the service you wish to clear.
4. If necessary, press to select the numeric button of the new wash service or retract you wish to select.
5. Press the $ (dollar) button to confirm the wash selection.
The lights will flash again displaying the cars on stack.
NOTE:
Setup for Retracts is on the Tunnel Master® Jr. services page.
†

Add a Car to Stack

To add a new car to the end of the stack, follow these steps:
1. On the keypad, press a numeric button to select a service.
2. Press the $ (dollar) button.
LED lights blink for five seconds displaying the cars currently in the stack. The newly added car with the
service is added to the end of the stack.

Remove a Car from Stack

1. On the keypad, press the AC button.
2. Press to select the numeric button that represents the car in the stack you would like to remove.
3. Press the numeric button of the service to deselect it.
The button's light should turn off.
4. Press to select the $ (dollar) button.
The stack will blink and you will no longer see the car you removed light up and the cars move
up in the stack. (i.e. if you had three cars on stack in position 1, 2 and 3 shown on the numeric
keypad, and you removed the 2nd car. Then only lights 1 and 2 will be lit.)
Chapter 6: Entrance Keypad Tunnel Master® Jr. User Manual - Page 54
