Summary of Contents for ICS Auto Passport
- Page 1 Auto Passport ® with the All-In-One RFID Reader/ Antenna for the Auto Sentry® flex Installation Guide - Version 3.0 November 8, 2019...
-
Page 2: Installation Overview
Auto Passport. A thorough understanding of electrical wiring, installation, codes, and safety protocols is required. No prior experience with the Auto Passport is necessary. By reading the information and performing the procedures in this installation guide, you should be able to install the Auto Passport system-level and communications wiring. - Page 3 High-voltage (AC) and low-voltage (DC) must not be combined in a common conduit, junction box, or wire trough. „ Power for the Auto Passport and any peripherals must come from the dedicated UPS, as supplied by ICS, and must be „...
- Page 4 If menu signs and other items are to be installed on the island, then it is the car wash owner’s responsibility to increase the length of the island to accommodate these additional items. See Figure 4. NOT #2E: ICS highly recommends that the width of the islands be a minimum of 4’ - 6” for the safety of the attendants „...
-
Page 5: System Wiring
Recommended and Accepted Grounding Methods The Auto Passport equipment must be properly grounded. Proper system grounding is an extremely important part of the system installation. Grounds for all devices should be wired to the main service electrical panel ground bus bar which, in turn, should be grounded to a ground rod. - Page 6 ATTACH WIRE MARKED RX TO THE YELLOW TERMINAL BLOCK (RX) ATTACH WIRE MARKED GROUND TO THE WHITE TERMINAL BLOCK (GD) Figure 6. Layout Triple Lane Example RFID Wiring Layout Copyright © Innovative Control Systems, Inc. Page 5 Auto Passport Installation Guide...
- Page 7 Truss and RFID System Installation NOTE: It is recommended to have 2 people perform the installation of the RFID system. Tools Required (not supplied by ICS) 1/8” Allen Wrench „ „ Small Flat Head Screw Driver „ Hammer Drill Diagonal Cutting Pliers „...
- Page 8 Auto Sentry flex Figure 7. Circuit Breaker Location Shut off the electricity by turning off the Auto Sentry flex breaker inside the ICS® power distribution box. Copyright © Innovative Control Systems, Inc. Page 7...
- Page 9 CONCRETE ISLAND MUST BE 6 INCHES 45 ½” ABOVE THE FINAL TRAFFIC LANE GRADE C L C L C L C L RFID AUTO SENTRY TRUSS Figure 9. Truss Base Location Side View Copyright © Innovative Control Systems, Inc. Page 8 Auto Passport Installation Guide...
- Page 10 WILL PASS. MINIMALL RECOMMENDED FOR NOTE #1 NOTE #1 2" 2" FRONT EDGE OF TRUSS-BASE DIRECTION OF VEHICLE TRAVEL IN RELATIONSHIP TO TRUSS BASE Figure 10. Truss Base Mounting Specifications Copyright © Innovative Control Systems, Inc. Page 9 Auto Passport Installation Guide...
- Page 11 The truss will be shipped with truss brackets and hex screws. (1/8” „ Allen key is needed to install but not supplied by ICS). Mount the center of the enclosure at 3’ 6-1/2” from the edge of the curb. See Figure 12.
- Page 12 Re-install the bill dispenser drawer and the bill dispenser. 10. Re-attach the cables for the bill dispenser. Figure 13. Terminal Block Inside Auto Sentry Base Figure 14. Wire Termination Copyright © Innovative Control Systems, Inc. Page 11 Auto Passport Installation Guide...
- Page 13 After the truss and enclosure are installed, and all the wires are connected as instructed on page 11, reconnect the power to the ICS power distribution box by turning on the Auto Sentry flex breaker inside the ICS® power distribution box.
- Page 14 If you have any questions or concerns, please contact ICS Technical Support: 800-246-3469. Corporate Office: 81 Highland Avenue, Suite 300, Bethlehem, PA 18017 | Sales: 800.642.9396 Email: sales@icscarwashsystems.com | icscarwashsystems.com...
