ICS Tunnel Master Jr. User Manual page 43

Menu
Type Use the "0" button to advance to select the option desired.
M = Mandatory, relay will activate for any service sold that is set as a Base.
S = Selective, relay will activate only when a service set as an Extra Service is sold along with a
Base service.
D = Deselective, relay will NOT activate when a service with this output is selected.
C = Conveyor, relay is activating the motor starter solenoid for the conveyor motor when a Panic
circuit is wired to the designated relay.
R = Roller, relay activates the roller up solenoid. Start time entered on Roller output will be
how long the roller up cylinder is activated. If you enter an extend time, the system will fire the
roller up relay for the start time, then pause for the extend time and then fire for the start time a
second time. This is known as an up down up.
A = Auto Stop, relay is tied to a stop circuit for shutting down the car wash after the last vehicle
exits the wash or there is no wash activity. In order for this to work, you must set the Auto Stop
Period in the Wash Settings.
O = This output is used to start the conveyor once you have a base service selected.
H = This output will fire your Horn. The start time for this output is how long, in seconds, that the
horn will blow for. The extend time is how long, in seconds, the system will delay starting the
conveyor.
NOTE: YOU MUST HAVE A HORN RELAY SETUP WITH A START TIME IN ORDER FOR THIS RELAY TO
FIRE.
Part Use the "0" button to advance to the part of car selection that the piece of equipment turns on.
AC = All of the Car
FH = Front Half of the Vehicle
FB = Front Bumper On
RH = Rear Half of Vehicle
RB = Rear Bumper Only
TA = Activate from a tire switch for tires or wheels. On a Tire Output, the Start Time is where the
equipment in the tunnel is located and the Extend Time is the length of time the output will stay
on.
ES = Entrance sign, relay will activate after vehicle is "Loaded" and shut off as vehicle reaches gate
switch. An entrance sign can only be a Selective output and cannot be a Mandatory service.
EM = Entrance Management relay will activate after the second tire hits the entrance
management treadle which is wired into Input 10. This relay will stay activated until Min Car
Length is reached.
Enter Y for yes, or N for no if the relay is to flash on and off when it is activated.
Flash
Page 39 - Tunnel Master® Jr. User Manual
Function
Chapter 4: Wash Configuration
